Air Hogs Jackal Instruction Manual

®
Key Features
Jackal™:
- Durable, pre-coloured plastic body
- On/Off switch and charging jack
- Counter-rotating rotor blades for stable flight
- Built-in LiPo (lithium-polymer) rechargeable
battery
- Realistic left/right, up/down and
forward/backward helicopter like movement
Controller/Charger:
- Trim wheel to adjust flight orientation
- Charge status and power-on LEDs
- Easy helicopter battery recharging using the
controller/charger
Jackal™
JACKAL™
CAUTION:
Tail rotor to be replaced by adult only.
NOTE: If hair or debris gets caught
in rotor and prevents rotor from
turning, remove as above and clean.
CONTROLLER/CHARGER
Charging Indicator
Throttle Stick
(Up/Down)
OFF/ON/CHG
Switch
Charge Plug
INSTRUCTION GUIDE
WARNING:
CHOKING HAZARD
Not for Children under 3 years.
CAUTION:
Do not touch the running propeller!
Do not play above someone's head!
Adult supervision is required!
CONTENTS LIST AND PARTS IDENTIFICATION
IR (infrared) Controller/Charger
GETTING TO KNOW YOUR JACKAL™
Main Rotor Blades
(Counter-rotating)
Tail Rotor
IR Receiver
Small parts.
DANGER!
NEVER INSERT ANY SHARP OBJECTS, PINS
OR SCREWS INTO THE HELICOPTER AS THIS
MAY PUNCTURE THE INTERNAL BATTERY!
Spare
Tail Rotors Removal Tool
Landing Gear
1
TM
10 - 12
Rotor
Instruction Guide
Flybars
Charge Port
ON/OFF
Power Switch
Power
Indicator
Directional Stick
(Left/Right)
(Forward/Backward)
F
L R
B
YRS
ADVANCED
Trim Wheel
(Left/Right)
