MOTOR DIAGRAM AND SCHEMATIC

NOTE
When checking Component, be sure to turn Power off, then do voltage discharge sufficiently.
■
Contact On / Off by Centrifugal Switch
Terminal No
Mode
Motor
STOP
Motor
RUN
■
STOP MODE
(When Motor does not operate)
Centrifugal switch
Resistance
2 ~ 3Ω
3 ~ 5Ω
< 1Ω
< 1Ω
■
.RUN MODE
(Motor operates)
Centrifugal switch
(Pull Drive forward)
13
Remark
Motor
Heater (Electric Models)
Gas Valve (Gas Models)
Motor
Heater (Electric Models)
Gas Valve (Gas Models)
