hArDwArE SEtUP

please follow the diagram below to connect the kVm switch to your workstation computers
using the kVm cables.
PC3 PC4
Monitor
Mouse
Keyboard
PC1 PC2
Note:
this kVm switch will not detect whether a computer is on or off if the "power on" function is set in
the BIos. If you switch to a computer that is turned off, nothing will be displayed on the monitor.
