Misc Parts - HP Compaq 8300 Elite Illustrated Parts & Service Map

Boards
Standard and Optional Boards
System boards (include replacement thermal material)
1 System board for use in models without Windows 8
* System board for use in models with Windows 8 Standard
* System board for use in models with Windows 8 Professional
Memory modules (PC3-12800, CL11)
* 8-GB
* 4-GB
2 2-GB
PCI expansion cards
* nVidia Quadro NVS310 PCIe x16 graphics card, 512 MB
* nVidia Quadro NVS300 PCIe x16 graphics card, 512 MB
* AMD Radeon HD7450 PCIe x16 graphics card, 1 GB
* AMD Radeon HD6350 PCIe x16 graphics card, 512 MB
* AMD FirePro 2270 PCIe x16 graphics card, 512-MB
* Intel PRO/1000CT2 NIC, includes bracket
* HP FireWire / IEEE 1394a PCIe x1 Card
* HP WLAN 802.11 g/n 1x2 PCIe NIC
Processors (include thermal material)
Intel Core i7 processors (8-MB L3 cache)
3770, 3.4 GHz
Intel Core i5 processors (6-MB L3 cache)
3570, 3.4 GHz
3470, 3.2 GHz
Intel Core i3 processors (3-MB L3 cache)
2130, 3.4 GHz
2120, 3.3 GHz
Intel Pentium processors (3-MB L3 cache)
G870, 3.1 GHz
G860, 3.0 GHz
G640, 2.8 GHz,
HP Compaq 8300 Elite, CMT Chassis

Misc Parts

Miscellaneous Parts
1 Fan sink
2 Chassis fan, 92mm x 92mm
3 Printer port, PCI card
4 Solenoid lock
657096-001
5 Hood sensor
657096-501
6 Speaker, 40mm x 70mm
657096-601
7 Clamp Lock Kit, includes universal cable (plate not included)
* Serial port, PCI card
689375-001
* eSATA port assembly
671613-001
* 2.5-in drive adapter
671612-001
* Grommet, hard drive isolation, blue
* Card reader, 22-in-1
680653-001
* USB powered speakers
632486-001
* Mouse, PS2, optical, jack black
682411-001
* Mouse, USB, HP Elite
637995-001
* Mouse, washable
637213-001
* Mouse, wireless, HP Elite
635523-001 * Mouse, USB, optical, jack black
* HP Business Digital Headset
637591-001
* External USB webcam
538048-001
* Foot kit
* Hard drive conversion bracket
* Antenna for use with 538048-001
*Not shown
688164-001
688162-001
687943-001
665120-001
638629-001
691936-001
665123-001
691935-001
690357-002
643907-001
643908-001
638817-001
641498-001
638816-001
645330-001
508987-001
638815-001
645558-001
586721-001
594220-001
636166-001
636917-001
537748-001
674318-001
619580-001
674317-001
537749-001
642738-001
609252-001
370708-001
397117-001
583345-001
