LED Color
Indicator
Power/ Orange/
Status Green
Solid Green
Fan Green/ Solid Green The fan is operat-
Red
Solid Red
USB Green Solid Green
Tx/Rx Green Solid Green
Status
of RJ-45
Port
Link Green/ Solid Green
Speed Orange
of RJ-45
Port
Link and Green/ Solid Green
TX/RX of Orange
SFP Port
Default Interface Settings
Ethernet Interface
Interface Type
LAN (1-4) Static IP 192.168.10.1/24

Installation and Connection

This section describes how to install a
DWC-2000 in a standard 19-inch equipment
rack and how to connect cables and power to
the device.
Status Description
Solid Power-on pro-
Orange cess in progress.
Power-on pro-
cess complete.
Blinking Device has
Orange crashed and is in
recovery mode.
Light Off The device is
powered off.
ing normally.
The fan has
failed.
The link is good.
Blinking There is activity
Green on this port.
Light Off No link.
Link is present.
Blinking Port is sending or
Green receiving data.
Link Off No link.
Port is operating
at 100 Mbps.
Solid Port is operating
Orange at 1000 Mbps.
Light Off Port is operating
at 10 Mbps.
Port is operating
at 100 Mbps.
Blinking Port is sending or
Green receiving data at
100 Mbps.
Solid Port is operating
Orange at 1000 Mbps.
Blinking Port is sending or
Orange receiving data at
1000 Mbps.
IP Address Web-Based
Management
Enabled

Before You Begin

Observe the following precautions to help
prevent shutdowns, equipment failures, and
injuries:
• Before installation, always check that the
power supply is disconnected.
• Ensure that the room in which you are
operating the device has adequate air
circulation and that the room temperature
does not exceed 40 °C (104 °F).
• Ensure there is at least one meter (three
feet) of clear space in front and back of the
device.
• Do not place the device in an equipment
rack frame that blocks the air vents on the
sides of the chassis. Ensure that enclosed
racks have fans and louvred sides.
• Ensure that none of these hazardous
conditions exist before installation: moist
or wet floors, leaks, ungrounded or frayed
power cables, or missing safety grounds.
Step 1 – Unpacking
Open the shipping carton and carefully unpack
its contents. Please consult the following
packing list to make sure that all items are
present and undamaged. If any item is missing
or damaged, please contact your local D-Link
reseller for a replacement.
Package Contents
DWC-2000 Wireless Controller
Power Cord
Console Cable
(RJ-45 to DB-9 Cable)
Ethernet Cable
(CAT5 UTP/Straight Through)
Reference CD
Rack Mounting Brackets
Screws Pack
QIG
1
1
1
1
1
2
1
1
3
