Gearbox display

The display which gives information on dual clutch transmission
(DCT) is found to the bottom right of the rev counter; with the
ignition key in position II, it displays the following information:
- Gear engaged;
- Indication of "Automatic gearbox" mode;
- Indication of "Auto easy exit" mode;
- Indication of gearbox in "Parking" mode;
- Indication of Launch Control activated;
- Indication of AVH system activated.
About your Vehicle
116
Gear engaged
The gearbox display shows the number or letter indicating the
engaged gear in the centre.
N Neutral
R Reverse
1 1 gear
st
2 2 gear
nd
3 3 gear
rd
4 etc.
When the key is turned to off, the display remains on for at least
3 seconds and displays the engaged gear. If the control panel reads
N (Neutral), the letter N is displayed and a buzzer will sound.
