- Page 1 DIGITAL TRANSMITTER OPT-563B Quick Instruction Manual Minebea Co., Ltd. Measuring Components Business Unit EN294-1723...
-
Page 3: Pictograms And Conventions Used In This Manual
This instruction manual is a [quick] instruction manual primarily intended to describe the procedure for calibration by inputting numerical torque values. For detailed instructions on how to use the OPT-563B, refer to Instruction Manual EN294-1596*. Note that handling or operating the device incorrectly may result in malfunctions. Read the instruction manual EN294-1596* thoroughly before use for safety and optimal results. -
Page 4: Revision History
Revision History Date Manual No. Revision reason (details) 2015/12 DRW. No.EN294-1723 1st issue... -
Page 5: Table Of Contents
Contents INTRODUCTION ..............................I PICTOGRAMS AND CONVENTIONS USED IN THIS MANUAL ................I REVISION HISTORY ............................... II CONTENTS ................................III PART NAMES AND FUNCTIONS ........................5 1-1. Front Panel ......................................5 1-2. Rear Panel ......................................7 OPERATING INSTRUCTIONS ........................8 2-1. - Page 6 3-2. Settings to be Altered As Necessary After Calibration ....................10 3-3. Calibration Procedure ................................... 11 3-3-1. Calibration in Measurement Mode ....................11 3-3-2. Selecting Calibration Mode ......................12 3-3-3. Minimum Scale Division Setting ..................... 12 3-3-4. Torque Setting ..........................13 3-3-5.
-
Page 7: Part Names And Functions
(2) Torque display Displays the torque reading and [OL] (for over limit). (3) Status display Indicates the OPT-563B status. : Illuminates when the torque meter light level is normal. : Illuminates when the torque meter light level is low. Note that [M] does not illuminate if used in conjunction with the DBX-001 power supply box. - Page 8 (5) Rotation speed display Displays the rotation speed and [OS] (for overspeed). Turns on the A/Z function. Also moves the setting digit to the left when setting numerical values. Turns off the A/Z function. Also moves the setting digit to the right when setting numerical values. Increments the digit selected when setting numerical values.
-
Page 9: Rear Panel
1-2. Rear Panel (3) External control input/output connector (6) Optional part mounting section (4) Torque transducer/rotation speed detector connector (1) Power supply terminal board (5) Analog output connector (2) Protective ground terminal (1) Power supply terminal board Connected to the AC power supply and grounding wire. (2) Protective ground terminal Connect this to ground to eliminate noise effects such as static electricity. -
Page 10: Operating Instructions
2. Operating Instructions This section describes how to operate the equipment using the keys on the front panel. CAUTION Stop measuring before operating the keys. There is a risk of malfunctioning if the keys are operated while measurement is in progress. Key operations in measurement mode are enabled by depressing for approximately 1 second. -
Page 11: When Operated In Other Modes
2-4-2. When Operated in Other Modes Setting increment Pressing the key when a setting is displayed increments the value in sequence from 0 to 9, and then back to 0. Fine adjustment increment Pressing the key for fine adjustment of the zero point, span point, asymmetry correction, linearization correction, or analog output increments the corresponding value. -
Page 12: Calibration
Calibration Data 1 to 4 before calibrating using F-59. If the equipment is jointly calibrated at Minebea, the calibration data will be stored to [Calibration Data 1]. 3-2. Settings to be Altered As Necessary After Calibration For details of the setting instructions, refer to Instruction Manual EN294-1596*. -
Page 13: Calibration Procedure
3-3. Calibration Procedure 3-3-1. Calibration in Measurement Mode Step 1 Connect the torque transducer to the equipment. Torque transducer connection Step 2 Turn on and wait for approximately 10 minutes for the torque After turning on power transducer and equipment to stabilize. Step 3 Select calibration mode. -
Page 14: Selecting Calibration Mode
3-3-2. Selecting Calibration Mode Calibration mode can be selected from measurement mode as follows. Measurement appears in the upper part when the mode is depressed for approximately 2 seconds in measurement mode. The upper display reads when the is pressed. The upper display reads flashes on the lower display, indicating calibration mode has been selected when the... -
Page 15: Torque Setting
3-3-4. Torque Setting Set the maximum torque displayed. Use the keys to change the torque Registered torque on the lower display to the required value. value * Enter value (2) on the calibration certificate sheet. (No decimal point) For example, if the maximum indication is 100.00 N·m, set to [10000]. -
Page 16: Actual Torque Setting
3-3-5. Actual Torque Setting Set actual torque acting on the torque transducer (or torque transducer output). When calibrating by entering numerical values, set the same value as set in "3-3-4 Torque Setting". * Enter value (3) on the calibration certificate sheet. (No decimal point) For example, if the maximum indication is 100.00 N·m, set to [10000]. -
Page 17: Zero Calibration
3-3-6. Zero Calibration Register the input at the zero point. To calibrate by entering the torque value for the torque transducer, press the key and then press key. Calibrate zero by entering the zero point torque (frequency) for the torque transducer. Calibration by entering the torque value for the torque transducer Press the... -
Page 18: Span Calibration
3-3-7. Span Calibration Register the input at the span point. To calibrate by entering the torque value for the torque transducer, press the key and then press key. Calibrate span by entering the span point torque (frequency) for the torque transducer. Calibration by entering the torque value for the torque transducer Press the... -
Page 19: Calibration End
3-3-8. Calibration End Displays after span calibration ends. Press the key to exit calibration mode. The system switches to measurement mode and the data set is registered. Measurement mode The calibration values (zero point and span) will not be entered unless the procedure is performed in sequence up to this step. -
Page 20: Zero/Span Fine Adjustment Function
3-4. Zero/Span Fine Adjustment Function This function fine-adjusts the zero point and span point if there are discrepancies between the actual torque and the reading displayed. 3-4-1. Selecting Zero Point Fine-adjustment Mode Zero point fine-adjustment mode can be selected from measurement mode as follows. Measurement mode appears in the upper part when the... -
Page 21: Selecting Span Point Fine-Adjustment Mode
3-4-2. Selecting Span Point Fine-adjustment Mode Span point fine-adjustment mode can be selected from measurement mode as follows. Measurement appears in the upper part when the mode is depressed for approximately 2 seconds in measurement mode. The upper display reads when the (3 times) is pressed three times. -
Page 22: Function Mode
4. Function Mode 4-1. Selecting Function Mode Function mode can be selected from measurement mode as follows. Measurement mode appears in the upper part when the key is depressed for approximately 2 seconds in measurement mode. The upper display reads when the key is pressed. -
Page 23: Function List
4-2. Function List Setting Function No. Item Details value ●0 No decimal point 1000.0 F-01 Decimal place 100.00 10.000 1.0000 ●0 N·m F-02 Torque display units kN·m 4 cycles/s F-04 Display cycles ●1 20 cycles/s 1 Hz 10 Hz 30 Hz 50 Hz F-05 Torque analog filter... - Page 24 Setting Function No. Item Details value No. of moving-average samples: 1 No. of moving-average samples: 2 No. of moving-average samples: 4 No. of moving-average samples: 8 Rotation speed stabilization F-15 filter No. of moving-average samples: 10 No. of averaging No. of moving-average samples: 12 ●6 No.
- Page 25 Setting Function No. Item Details value ●0 F-25 No. of rotation detection gears ●0 Selecting A/Z data save F-26 destination EEPROM ●0 Command mode F-30 RS-232C operating mode Stream mode ●0 Torque display data Input torque A/D data F-31 RS-232C stream output target Rotation speed display data Frequency data 1,200 bps...
- Page 26 Setting Function No. Item Details value 000~125 PROFIBUS F-41 Station No. ●000 001~127 CANopen F-42 Node ID ●001 10 kbps 20 kbps 50 kbps 100 kbps CANopen F-43 125 kbps Baud rate 250 kbps 500 kbps 800 kbps ●8 1 Mbps 0~100 CANopen 0: Off...
- Page 27 Setting Function No. Item Details value F-70 Calibration 2 Increment Datum value (initial value) Calibration 2 Maximum display F-71 10000 Datum value (initial value) value Calibration 2 Actual torque F-72 10000 Datum value (initial value) value F-73 Calibration 2 ZERO A/D 0x1FFFF Datum value (initial value) F-74...
- Page 28 SAMPLE (2)(3)
- Page 30 The contents of this manual may subject to change without notice. MINEBEA CO., LTD. HEAD QUARTER : 4106−73 Miyota, Miyota−machi, Kitasakugun, Nagano−ken 389−0293, Japan 0267−32−2200 .0267−31−1350 Measuring Components Business Unit FUJISAWA PLANT 1−1−1, Katase, Fujisawa−shi Kanagawa−ken, 251−8531 Japan ...
