GAS OPEN FIRE INDOOR MANUAL CONTROL MODELS 930-730-630 APRIL 2008 INSTALLATION OPERATION, MAINTENANCE & WARRANTY INFORMATION These instructions should be stored in a convenient safe place for ready reference. Revised 04/04/08 ALLURE MANUAL Control -Indoor Install Apr08 Page 1 of 20...
These instructions cover only the INDOOR MANUAL CONTROL models. Please fill out the warranty on the last page, and return the registration form promptly. The YUNCA ALLURE INDOOR MANUAL CONTROL FLUED GAS FIRE is a gas-fired, conventionally vented room heater. It is manufactured to New Zealand standards.
CAUTIONS The Yunca Allure Indoor Manual Control requires 240v power only to operate the fan boost as a means of more effective heating. ENSURE THAT THE POWER SWITCH IS READILY ACCESSIBLE (DO NOT install the switch inside any cavity area).
Diagrams on the following pages are not to scale. All measurements are in millimetres. The Yunca Allure flued gas fire is to be installed with clearances equal to, or greater than, those recommended on the following pages, and must comply with NZS 5261:2003/AG601...
100mm x 50mm Air vents must be of a bird & vermin proof design and able to prevent rain penetration into the chase. Revised 04/04/08 ALLURE MANUAL Control -Indoor Install Apr08 Page 5 of 20...
ZERO CLEARANCE GAS FLUE KIT (3.6m): INSTALLATION INSTRUCTIONS Yunca Gas ALLURE OPEN FIRE 630, 730 (150mm dia flue), 930 (200mm flue) This flue kit has been manufactured in accordance with NZS 5261:1996. To ensure safety this flue kit must be installed as outlined in these instructions. Appliance and flue clearances from combustible walls must be in accordance with heater manufacturers specifications and NZS 5261:1996.
Page 7
4. Any Lateral run in a Flue shall be: a) No more than 1.0 metre in the horizontal plane b) Not be less than 45 degrees above the horizontal plane. Revised 04/04/08 ALLURE MANUAL Control -Indoor Install Apr08 Page 7 of 20...
Grate Test Point Bolt Points (Fig 1.) Cowl Back 15 mm 30 mm (Fig 2.) Gas Pipe 15 mm Electrical Cable 80 mm Hole – indoor only Revised 04/04/08 ALLURE MANUAL Control -Indoor Install Apr08 Page 8 of 20...
CAUTION: Do not use this appliance if any part has been water damaged or exposed to moisture causing corrosion. A Qualified service technician should inspect the appliance and replace any part of the gas system that has been water damaged. Revised 04/04/08 ALLURE MANUAL Control -Indoor Install Apr08 Page 9 of 20...
BM 733 control. Operating pressure is adjusted at either the LPG or NG in line regulator. Gas Type, Pressures and jet sizes appear on data plate. The Allure Heater uses the BM733 control valve, a functional view of this is shown below. Legend to functional diagram 1. Valve body, top section 6.
Remove 2 screws and lift out. 7) COWL TOP FRONT Remove 2 screws and slide out. This will give access to flue spigot (visible when fascia is removed). Revised 04/04/08 ALLURE MANUAL Control -Indoor Install Apr08 Page 11 of 20...
Page 12
2) Check for Gas Ignition, operation of flame and fan before setting the fire. 3) Follow layout (see following pages) for setting of the fire. 4) Re-check gas ignition, control operation, etc as in #2 above. Revised 04/04/08 ALLURE MANUAL Control -Indoor Install Apr08 Page 12 of 20...
730 = 20 x No1 Coals 20 x No2 Coals (4 rows of 10) 630 = 16 x No1 Coals 16 x No2 Coals (4 rows of 8) Revised 04/04/08 ALLURE MANUAL Control -Indoor Install Apr08 Page 13 of 20...
Page 14
Refer photos below 1 x B 1 x C 1 x D 1 x B 2 x C 1 x D 2 x B 2 x C 2 x D Revised 04/04/08 ALLURE MANUAL Control -Indoor Install Apr08 Page 14 of 20...
Commissioning and Operating When installed the installer should operate the YUNCA ALLURE to ensure that all features are operating correctly, refer below. Turning on your manual control YUNCA ALLURE The markings mentioned below are imprinted on the Control Panel Grill and are visible when the hearth panel is lifted out (NB. You do not need to remove the hearth panel to light the fire).
Page 16
Ensure a recommended flue cowl has been draught. fitted and is still in place. Pilot burning, no Burner injectors Clean out injector orifice. gas to burners may be blocked. Revised 04/04/08 ALLURE MANUAL Control -Indoor Install Apr08 Page 16 of 20...
930 Grate - Traditional 6904GO7T 730 Grate - Traditional 6904GO6T 630 Grate - Traditional 6904GO9C 930Grate - Contemporary 6904GO7C 730 Grate - Contemporary 6904GO6C 630 Grate - Contemporary Revised 04/04/08 ALLURE MANUAL Control -Indoor Install Apr08 Page 17 of 20...
Page 18
Appendix B: Yunca Allure – Spare parts continued: 630 model LPG MAIN JETS: 630 Model Natural Main Jets: ALL 1.3 mm dia. 730 model LPG MAIN JETS: 730 model Natural Main Jets: ALL 1.2 mm dia. 930 model LPG MAIN JETS: 0.7 0.7...
The Yunca Allure Manual Control – INDOOR series is intended for INDOOR USE ONLY. The warranty will not cover use in outdoor situations. If you are in any doubt please contact the manufacturer: Yunca Gas, Dunedin 03 488 4342 This warranty is void if the recommended service schedule is not implemented as suggested in this manual and carried out by a suitably qualified person.
