Monitor Specification; Lcd Monitor Description - AOC 2236Vwh Service Manual

21.5" LCD Color Monitor

1. Monitor Specification

Model name
Driving system
Viewable Image Size
Pixel pitch
LCD Panel
Video
Separate Sync.
Display Color
Dot Clock
Horizontal scan range
Horizontal scan Size(Maximum)
Vertical scan range
Vertical scan Size(Maximum)
Optimal preset resolution
Highest preset resolution
Plug & Play
Input Connector
Resolution
Input Video Signal
Power Source
Power Consumption
USB Downstream port (A type )
off timer
Speakers
Connector Type
Signal Cable Type
Physical
Characteristics
Dimensions & Weight:
Temperature:
Environmental Humidity:
Altitude:
2236Vwh
TFT Color LCD
54.7cm diagonal
0.248mm(H) x 0.248mm(V)
R, G, B Analog lnterface & HDMI
H/V TTL
16.7M Colors
148.5 MHz
30 kHz - 80 kHz
476.64mm
55 Hz - 75 Hz
268.11mm
1920 x 1080 (60 Hz)
1920 x 1080 (60 Hz)
VESA DDC2B/CI
D-Sub 15pin & HDMI
Analog: 0.7Vp-p(standard), 75 OHM, HDMI
100-240V～, 50/60Hz
Typical < 42 W
Standby < 1 W
To USB device, loading < 100mA
0~24hours
2W x 2
15-pin Mini D-Sub & HDMI
Detachable
Height (with base)
Width
Depth
Weight (monitor only)
Weight (with packaging)
Operating
Non-Operating
Operating
Non-Operating
Operating
Non-Operating
4
AOC 2236Vwh
Select timing to turn off the monitor.
396.6 mm
531.3mm
206mm
4.35 kg
5.8 kg
0° to 40°
-20°to 60°
10% to 85% (non-condensing)
5% to 80% (non-condensing)
0~ 3000m (0~ 10000 ft )
0~ 5000m (0~ 15000 ft )
