L50A(L50C)
Multiscanning Color Monitor
TECHNICAL SERVICE MANUAL

Advertisement

Table of Contents
loading

Related Manuals for Hyundai ImageQuest L50A

Summary of Contents for Hyundai ImageQuest L50A

  • Page 1 L50A(L50C) Multiscanning Color Monitor TECHNICAL SERVICE MANUAL...

  • Page 2: Safety Precaution

    L50A(L50C) Technical Service Manual Safety Precaution WARNING Service should not be attempted by anyone unfamiliar with the necessary precautions on this monitor. The followings are the necessary precautions to be observed before servicing. 1. When managing this monitor , cover with shield plate to avoid to scrach on LCD surface. 2.

  • Page 3: Control Description

    Control Description Front View LED Indicator Soft Power Switch Support Modes V Frequency H Frequency Resolution Refresh rate (Hz) (kHz) Polarity Polarity Polarity 720 x 400 70.0 70.087 28.322 31.5 640 x 480 59.9 59.940 25.175 31.5 640 x 480 72.8 72.809 31.500...

  • Page 4: Video Input Signal

    L50A(L50C) Technical Service Manual Video Input Signal Recommended signal are shown below •Video Signal Video level : 0 to 700mV Polarity : positive Video Input : RGB separated Analog level Sync input : H-Sync(TTL level) V-Sync (TTL level) •Waveform Video input(R.G.B) 700mV •...

  • Page 5: Video Input Terminal

    Video Input Terminal A 15 Pin D-sub connector is used as the input signal connector Pin and input signals are shown in the table below. Pin Description SEPARATE SYNC/ SIGNAL PIN NO. DDC 1/2B GREEN BLUE RETURN RED GROUND GREEN GROUND BLUE GROUND LOGIC GROUND GROUND...

  • Page 6: Connecting With External Equipment

    L50A(L50C) Technical Service Manual Connecting with External Equipment Cautions Be sure to turn off the power of your computer before connecting the monitor. --5--...

  • Page 7: Theory Of Operation

    Theory of Operation 1. AC/DC Adapter Input voltage : 90 ~ 264 Vac, 50/60 Hz Input current : Max 1A (Vin : 90Vac , 50Hz) Inrush current : 15A peak (At 115Vac Max . Load) 30A peak (At 230Vac Max. Load) 2.
  • Page 8 L50A(L50C) Technical Service Manual On Screen Controls & LED Indicator The menu for screen setting adjustment is located in the OSD and can be viewed in one of five languages OSD feature andmain funcrions are as follows: The OSD adjustments available to you are listed below. BRIGHTNESS Adjust the brightness of the screen.
  • Page 9 CLOCK PHASE PHASE Adjust the noise of the screen image. CLOCK Adjust the horizontal size of the entire screen image. AUTO ADJUST You can adjust the shape of screen automatically at the full screen pattern. MISCELLANEOUS RECALL Recall the saved color data. OSD TIMER You can set the displayed time of OSD Menu window on the screen by using this adjustment.
  • Page 10 L50A(L50C) Technical Service Manual Getting Fine Picture Step 1. At first Display, a full screen, such as, Window's background or "H" character should be achieved by using Editor (ex: Notepad. exe) Step 2. Adjust the screen to the center of the Display(LCD), by using the top and bottom display controls.

  • Page 11: Specification

    Specification SIZE 15” Viewable diagonal Dot Pitch 0.297mm LCD Module 180 cd/m 2 (MIN), 250 cd/m 2 (TYP) Brightness Response Time 20m- sec (Typ) Signal R.G.B Analog Input Connector 15 pin D-SUB Connector H-Freq 31.0kHz ~ 60.0kHz SYNC V-Freq 56.0Hz ~ 75Hz Area 304(H)X228(V)mm Display...

  • Page 12: Critical Parts Specification

    L50A(L50C) Technical Service Manual Critical Parts Specification 1. LCD Module HT-15X13(LTM150XH-L01 is a a-si TFT active matrix color liquid crystal comprising amorphous silicon TFT attached to each signal electrode, a driving circuit and a backlight. HT-15X13(LTM150XH-L01 has a built-in backlight display area contains 1024X768 pixels and can display full color (16.2M colors) Display area 304(H)X228(V)mm...
  • Page 13 2) INTERFACE CONNEXTION 2-1) Electrical Interface Interface connector : DF14H-20P-1.25H(HIROSE) or equivalent User side connector : DF14-20S-1.25C(HIROSE)or equivalent Symbol Pin No Pin No Remark VDD1 Power Supply : +3.3V VDD2 Power Supply : +3.3V Ground Ground RIN0- Tx pin #48 LVDS Negative data signal (-) RIN0+ Tx pin #47...
  • Page 14 L50A(L50C) Technical Service Manual 2-2) LVDS Infcrface LVDS Transmitter : THC63LVDM83A or equivalent. Transmitter Interface Input DF14H-20P-1.25H Remark signal System (Tx) Pin No Pin No TFT-LCD (Rx) Pin No OUT 0- IN0- OUT + IN0+ OUT1+ IN1- OUT1+ IN1+ OUT2- IN2- OUT2+ IN2+...
  • Page 15 gmZAN1 The gmZAN1 device utilizes Genesisí patented third- • • • • Output Format generation Advanced Image Magnification technology as • • • • Support for 8 or 6-bit panels (with high quality well as a proven integrated ADC/PLL to provide excellent dithering) image quality within a cost-effective SVGA / XGA LCD •...
  • Page 16 L50A(L50C) Technical Service Manual Pin Out Diagram Figure 1. gmZAN1 Pin Diagram OSD_DATA3 ADC_GND1 OSD_FSW ADC_VDD1 MFB11 ADC_GND2 MFB10 ADC_VDD2 DVDD PPWR gmZAN1 (160-Pin PQFP) DVSS PBIAS DAC_DGNDA NOTE: For all power pads: DAC_DVDDA PLL_DVDDA C: Core CVSS3 Reserved R: Ring PLL_DGNDA S: From pad 125 to 132, S represents Sclk DDS (source clk) SUB_DGNDA...

  • Page 17: General Descriptions

    FEATURES MTV312M64 • 8051 core, 12MHz operating frequency with double CPU clock option • 0.35uM process; 5V/3.3V power supply and I/O; 3.3V core operating • 1024-byte RAM; 64K-byte program Flash-ROM support In System Programming (ISP) • Maximum 14 channels of PWM DAC •...

  • Page 18: Pin Connection

    L50A(L50C) Technical Service Manual PIN CONNECTION DA2/P5.2 VSYNC DA2/P5.2 VSYNC DA1/P5.1 HSYNC DA1/P5.1 HSYNC DA0/P5.0 DA3/P5.3 DA0/P5.0 DA3/P5.3 VDD3 DA4/P5.4 VDD3 DA4/P5.4 DA5/P5.5 DA5/P5.5 DA8/HLFHO DA8/HLFHO DA9/HALFV DA9/HALFV MTV312M HBLANK/P4.1 MTV312M HBLANK/P4.1 40 Pin 42 Pin ISDA/P3.4/T0 VBLANK/P4.0 VBLANK/P4.0 PDIP SDIP ISCL/P3.5/T1 DA7/HCLAMP...

  • Page 19: Pin Configuration

    PIN CONFIGURATION A ìCMOS output pinî means it can sink and drive at least 4mA current. It is not recommended to use such pin as input function. A ìopen drain pinî means it can sink at least 4mA current but only drive 10~20uA to VDD. It can be used as input or output function and needs an external pull up resistor.
  • Page 20 L50A(L50C) Technical Service Manual CS5828 GENERAL DESCRIPTION FEATURES • The CS5828 receives four sets of 7-bit data in Four 7-bit serial and one clock LVDS channels. • CMOS logic level and converts them into four low- Compatible with ANSI TIA/EIA-644 LVDS stan- voltage differential signaling (LVDS) serial channels.
  • Page 21 PIN CONNECTION DIAGRAM LVDS_VSS LVDS_VDD LVDS_VSS CS5828 CKOM CKOP LVDS_VSS PLL_VSS PLL_VDD PLL_VSS SHTDN CKIN Figure-1 56-pin TSSOP --20--...
  • Page 23      #  #  #  # $ %   $ %   $ %   $ %                                     ...
  • Page 24  #  #  #  # $ %   $ %   $ %   $ %                     "&   "&                 ...
  • Page 25  #  #  #  # $ %   $ %   $ %   $ %                                 $%# %    %'   %'  ...
  • Page 26  #  #  #  # $ %   $ %   $ %   $ %                    " " % '"  " " % '"  " " % '"  " " % '"  " " % '"  " " % '"  " " % '"  " "...
  • Page 27             !  !    !    !        !  !    !    !                       ! "  #   #    #!       #$!   %...
  • Page 28 !  !    !    !              !  !    !    !       ! *$,  !    !  *$,         ! %       !    !   $! * ,  .. % ! $    !     ...
  • Page 29 L50C(S527B/L550B/L1510B) Schematic CONTENTS REVISION HISTORY SCHEMATIC SHEET Date Author Comments 01.09.04 G.H.NAM 1. Contents, Revision History Initial release ver A 2. gmZAN1/2 01.09.20 W.S.IM L50C VP 3. MCU(MTV312M) 01.10.10 W.S.IM L50C VP-A 4. LVDS & Power 01.10.23 E.J.NAM L50C VP-B 5.
  • Page 30 +3.3V DIGITAL DVDDA SUPPLY +3.3V DECOUPLING C201 C203 C204 22uF/16V 0.1uF 0.1uF C210 C211 C213 C214 C216 C218 C221 SVDDA 22uF/16V 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF C206 C207 C208 22uF/16V 0.1uF 0.1uF ZAN1_3.3V/ ZAN2_2.5V RVDDA C223 C224 22uF/16V 0.1uF DIGITAL C202 C205...
  • Page 31 R321 R322 R312 R315 R313 C313 R323 0.1UF R324 CN301 R319 LED_ORANGE_EN R314 LED_GRN_EN KEY_UP SHEET 2 KEY_UP KEY_DOWN SHEET 2 KEY_DOWN SELECT SHEET 2 SELECT SHEET 2 MENU C305 C314 C315 C316 C317 C318 C319 HEADER 8 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF...
  • Page 32 1pxl/clk PD36 SHEET 2 PD36 PD37 SHEET 2 PD37 PD[0..5] SHEET 2 PD[0..5] LVDS_3.3V U403 PD38 SHEET 2 PD38 PD39 SHEET 2 PD39 C401 C402 C400 C404 C403 PD[6..11] SHEET 2 PD[6..11] GND3 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF PD10 LVDSGND PD11 RX0- GREEN...
  • Page 33               !"  # $%...
  • Page 34   & &'!   ( %    & '       !
  • Page 35 ! " ! #!!       !   )'   %! %...
  • Page 36 ! *   ! & ' ! & '*!...
  • Page 38 8 3 3 6261042202 RUBBER STAND CR RUBBER 30 30 30 30 30 6242027801 SHEET PROTECT PET T=0.1 5004000203 SCREW TT 2*6 6220084000 6220084000 6220084000 6220084000 6220084000 LENS LED LENS LED LENS LED LENS LED LENS LED PMMA PMMA PMMA PMMA PMMA 1 1 1 1 1...
