TTS Tuff-Scope 2 User Manual

100x 200x 400x microscope
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual
Warranty & Support
This product is provided with a one year warranty for problems found during
normal usage. Mistreating the Tuff-Scope 2 or opening the unit will invalidate this
warranty.
All out of warranty repairs will be subject to a replacement fee.
Technical Support
Please visit www.tts-group.co.uk for the latest product information.
Email feedback@tts-group.co.uk for technical support.
TTS Group Ltd.
Park Lane Business Park
Kirkby-in-Ashfield
Nottinghamshire,
NG17 9GU, UK.
Freephone: 0800 318686 Freefax: 0800 137525
Tuff-Scope
WARNING: Do not dispose of this product in
household waste. Hand it over to a collection point
for recycling electronic appliances.
WARNING! Not suitable for children under 36
months due to small parts – choking hazard. Made
in China, on behalf of the TTS Group Ltd.
TTS is proud to be part of
N448
Nxxxxx
plc
2
TM
TTS Product Code:
EL00165

Advertisement

loading

Related Manuals for TTS Tuff-Scope 2

Summary of Contents for TTS Tuff-Scope 2

  • Page 1 Warranty & Support This product is provided with a one year warranty for problems found during normal usage. Mistreating the Tuff-Scope 2 or opening the unit will invalidate this warranty. All out of warranty repairs will be subject to a replacement fee.
  • Page 2 Tuff-Scope 1OOx 200x 400x microscope USER GUIDE...
  • Page 3 1. Tuff-Cam Adapter 8. Specimen Stage 2. Handheld Microscope 9. Microscope Base 3. Zoom Dial 10. Microscope Arm 4. Turret 11. Focusing Dial 5. Objective Lens 12. Reflective LED 6. Specimen Slide Clips 13. Mini Storage Drawer 7. Transmissive LED Cover 14.

  • Page 4: Battery Installation

    Tuff-Scope 2 BATTERY INSTALLATION 1. Open the Battery Compartment Door at the bottom of the Microscope Base (9) by lifting it up while pushing the Compartment Door Latch in the direction shown in the diagram below 2. Install 3 fresh AA batteries with their plus(+) and minus(-) poles correctly positioned.

  • Page 5: Using The Microscope

    USING THE MICROSCOPE 1. Place the Specimen Slide on the Specimen Stage (8) and secure with the Specimen Slide Clips (6). 2. Turn the Turret (4) to the desired magnification. (lt is recommended to start with SOX and increase the magnification when needed).
  • Page 6 Tuff-Scope 2 3. Illumination a) Turn the LED ON/OFF. Switch (14) to the left to turn on the Transmissive LED to illuminate transparent specimens. b) Turn the LED ON/OFF Switch to the middle to turn off all LEDs. c) Turn the LED ON/OFF Switch to...
  • Page 7 4. Focusing Turn the Focusing Dial (11) clockwise to raise the Specimen Stage (8) to the highest posi tion towards the Objective Lens (5). Take care to ensure that the Specimen Slide does not touch the Objective Lens. View through the eyepiece and lower the Specimen Stage gradually by turning the Focusing Dial anti-clockwise until the...
  • Page 8 Tuff-Scope 2 7. Remove the Handheld Microscope (2) for portable use. Sufficient Lighting is required to view the image using the Handheld Microscope (Not recommended for indoor use). Always start at SOX magnification before zooming in or turning to higher magnification 8.
