Summary of Contents for Speed Queen LWS11
- Page 1 Automatic Washers Home Laundry Keep These Instructions for Future Reference. (If this machine changes ownership, this manual must accompany machine.) Part No. 38899R7 www.comlaundry.com August 2007...
- Page 3 KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE. (If the washer changes ownership, be sure this manual accompanies the washer.) WARNING For your safety and to reduce the risk of fire or an explosion, do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. W022 IMPORTANT: Read the complete Installation and Operation Instructions before using the washer.
-
Page 4: Table Of Contents
Table of Safety Information................Explanation of Safety Messages............Important Safety Instructions ............... Contents Operation..................... Loading the Washer................Load Articles..................Load Sizes..................... Water Level ..................Water..................... Water Hardness ................Wash Temperature ................Laundry Tips..................Washing Temperature Guide..............Optional Features.................. 10 Bleach Dispenser ................10 Fabric Softener Dispenser.............. -
Page 5: Safety Information
Safety Information Explanation of Safety Messages Important Safety Instructions Throughout this manual and on machine decals, you Save These Instructions will find precautionary statements (“DANGER,” “WARNING,” and “CAUTION”) followed by specific WARNING instructions. These precautions are intended for the personal safety of the operator, user, servicer, and To reduce the risk of fire, electric shock, those maintaining the machine. - Page 6 Safety Information 7. Before the washer is removed from service or 19. If the supply cord is damaged, it must be replaced discarded, remove the lid to the washing with a special cord or assembly available from compartment. the manufacturer or its service agent. 8.
-
Page 7: Operation
Operation Loading the Washer Load Sizes Small NOTE: Always add detergent first. Refer to instructions for use on detergent packaging. 3-4 perm. press dress shirts Load Articles 1 twin sheet, 1 pillow case Load items by the amount of space they take up, not by 1-2 lightweight dresses their weight. -
Page 8: Water Level
Operation Water Level Water Water Hardness Hard water will not remove soil as well as soft water and can result in gray, dingy laundry. To get clothes clean in hard water, use a phosphate detergent or use more detergent if using a non-phosphate detergent. Do not use soap. - Page 9 Operation Energy You can save energy when washing by following a few guidelines: 1. Heating water accounts for the greatest energy expense when washing. Save on heating water by using warm or cold washes as well as cold rinses. 2. Wash full loads, but do not overload. 3.
-
Page 10: Laundry Tips
Operation Laundry Tips Laundry Comments Aids Soak/Pretreat • • Use a soaking agent and follow steps under To Do not use a soaking agent with Products Wash Clothes section or soak overnight to remove chlorine bleach. • stains and soils. Do not use pretreaters around the •... -
Page 11: Washing Temperature Guide
Operation Washing Temperature Guide Water Temperature Comments • • Sturdy whites and colorfast items. Best cleaning for heavily soiled • Work clothes. items. (approx. 60° C • • Soiled items. Best for sanitizing. [140° F]) • Diapers. • • Rinsing of some items (OPTIONAL). Reduces wrinkling in permanent •... -
Page 12: Optional Features
Operation Optional Features Bleach Dispenser The bleach dispenser is located in the left front corner, under the lid. Use liquid bleach in the dispenser. Powdered bleach must not be used in the dispenser. Add powdered bleach to the wash water. Use no more than one cup chlorine bleach for large loads, three-quarters cup for medium and one-half cup for small loads. -
Page 13: Determine Proper Cycle
Operation Determine Proper Cycle To Wash Clothes IMPORTANT: Before using your new washer, WARNING make sure the washer cord is plugged into an electrical outlet that has the proper grounding and To reduce the risk of fire, electric shock, polarity. Make sure the washer hoses are connected serious injury or death to persons, read the to the hot and cold water faucets, and that the Safety Information section before operating... -
Page 14: Timer
Operation 3. Add clothes loosely into the washtub. IMPORTANT: Holding the LOAD SIZE (WATER LEVEL) control in the RESET position can cause flooding of the washer. 7. Select the cycle according to the type of fabric being washed. Push the timer knob in and turn clockwise to the desired cycle and wash time. -
Page 15: Maintenance
Maintenance User-Maintenance Instructions Replacing Hoses Hoses and other natural rubber parts deteriorate after Cold Weather Care extended use. Hoses may develop cracks, blisters or If the washer is delivered on a cold day (below material wear from the temperature and constant high freezing), or is stored in an unheated room or area pressure they are subjected to. -
Page 16: Reinstallation Of Shipping Materials
Maintenance Reinstallation of Shipping Materials Motor Overload Protector Shipping Brace This internal overload protector will stop the motor automatically in the event of an overload. The The shipping brace in the lid opening should be saved overload protector will reset itself in two or three and reinstalled whenever the washer is moved. -
Page 17: Before You Call For Service
Maintenance Before You Call for Service If the Washer: Won’t Won’t Won’t Won’t Possible Reason – Do This to Correct Fill Start Agitate Spin Be sure power cord is plugged all the way into the electrical • • • • outlet. -
Page 18: If Service Is Required
Maintenance If Service Is Required When calling or writing about your washer, PLEASE GIVE THE MODEL AND SERIAL NUMBERS. The If service is required, contact the nearest Factory model and serial numbers are located on the Authorized Service Center. nameplate. The nameplate will be in the location shown in Figure 11. -
Page 19: Information For Handy Reference
Maintenance Information for Handy Reference Alliance Laundry Systems Shepard Street P.O. Box 990 Ripon, WI 54971-0990 U.S.A. Date Purchased Model Number Serial Number Dealer’s Name Dealer’s Address Phone Number Service Agency Service Agency Address Phone Number NOTE: Record the above information and keep your sales slip. Model and serial numbers are located on the nameplate.
