ELITE IC7
ASSEMBLY GUIDE
GUIDE DE MONTAGE
GUÍA DE ENSAMBLAJE
HZ14_AG_Elite_IC7_Rev1_2.indd 1
8/11/14 10:08 AM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IC7 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Elite IC7

  • Page 1 ELITE IC7 ASSEMBLY GUIDE GUIDE DE MONTAGE GUÍA DE ENSAMBLAJE HZ14_AG_Elite_IC7_Rev1_2.indd 1 8/11/14 10:08 AM...
  • Page 2 ENTER YOUR SERIAL NUMBER IN THE BOX BELOW: SERIAL NUMBER: HORIZON IC7 INDOOR CYCLE MODEL NAME: » Refer to the SERIAL NUMBER and MODEL NAME when calling for service.
  • Page 3: Pre-Assembly

    PRE ASSEMBLY ASSEMBLY PARTS LIST: UNPACKING Due to the weight of the indoor cycle, it is ITEM DESCRIPTION SPECIFICATION recommended that two persons perform the Rear Stabilizer Without 2 transportation wheels assembly. Set the indoor cycle in a cleared area and remove all packing materials; do not Carriage Bolt dispose of the packing materials until assembly is Flange Nut...
  • Page 4: Assembly Step 1

    ASSEMBLY STEP 1 & 2 ASSEMBLY STEP 3 & 4 Thread the left pedal (8) that has “L” on the spindle to the left side arm of the cycle using the adjustable wrench (5). Attach the rear stabilizer (1) to the frame using 2 flange Attach the front stabilizer (6) to the frame using 2 flange Please note that the L pedal is left-hand threaded which nuts (3), 2 washers (4) and two carriage bolts (2), and...
  • Page 5: Assembly Step 5

    NUMÉRO DE SÉRIE : Attach the console bracket (10) to the handlebar Attach the console (13) to the console bracket (10) using VÉLO D'INTÉRIEUR IC7 HORIZON NOM DE MODÈLE : using 1 screw (11), and secure firmly using the allen 4 screws (14), and secure firmly using the allen wrench (12).
  • Page 6: Liste Des Pièces

    PRÉMONTAGE LISTE DES PIÈCES : DÉBALLAGE À cause de son poids, il est recommandé que PIÈCE DESCRIPTION QTÉ INDICATION PARTICULIÈRE deux personnes assemblent le vélo d'intérieur. Pied d'appui arrière Sans roulettes de transport Disposez le vélo d'intérieur dans un lieu dégagé et retirez tous les matériaux d'emballage;...
  • Page 7 MONTAGE ÉTAPE 1 ET 2 MONTAGE ÉTAPE 3 ET 4 Avec la clé mixte (5), fixez la pédale gauche (8) marquée d'un « L » à la manivelle du bras gauche du pédalier. La Fixez le pied d'appui arrière (1) au cadre à l'aide de Fixez le pied d'appui avant (6) au cadre à...
  • Page 8 (11) et serrez solidement à l'aide de la clé à 4 vis (14) et serrez solidement à l'aide de la clé à molette (12). HORIZON IC7 molette (12). Fixez le câble de la console (A) au câble de la console (B).
  • Page 9 PREENSAMBLAJE LISTA DE PIEZAS DE ENSAMBLAJE: DESEMPAQUE Debido al peso de la bicicleta de interiores, se ELEMENTO DESCRIPCIÓN CANT. ESPECIFICACIÓN recomienda que dos personas realicen el Estabilizador trasero Sin 2 ruedas de transporte ensamblaje. Coloque la bicicleta de interiores en un área despejada y retire todos los materiales de Perno de transporte embalaje;...
  • Page 10 ENSAMBLAJE PASOS 1 y 2 ENSAMBLAJE PASOS 3 y 4 Enrosque el pedal izquierdo (8) que tiene la “L” en el husillo en el brazo del lado izquierdo de la bicicleta usando Sujete el estabilizador trasero (1) al marco usando Sujete el estabilizador delantero (6) al marco usando la llave ajustable (5).
  • Page 11 ENSAMBLAJE PASOS 5 y 6 Conecte el soporte de la consola (10) a la barra de Conecte la consola (13) al soporte de la consola (10) sujeción usando 1 tornillo (11) y sujete firmemente con usando 4 tornillos (14) y sujete firmemente con la llave la llave Allen (12).
  • Page 12 HZ14_AG_Elite_IC7_Rev1_2.indd 22-23 8/11/14 10:09 AM...
  • Page 13 FICHE DE RENSEIGNEMENTS INFORMACIÓN para obtener la pour obtenir les coordonnées. información de contacto. Elite IC7 Assembly Guide Rev. 1.2 | © 2014 Johnson Health Tech Made in China | Fabriqué en Chine | Fabricado en China HZ14_AG_Elite_IC7_Rev1_2.indd 24 8/11/14 10:09 AM...
