nanoosi WQP6-3603A S Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

WQP6-3603A S

Advertisement

Table of Contents
loading

Related Manuals for nanoosi WQP6-3603A S

Summary of Contents for nanoosi WQP6-3603A S

  • Page 1 WQP6-3603A S...
  • Page 2 For detailed operating method read the corresponding content on the instruction manual. Switch on the appliance Press the Power switch button to switch on the appliance, Open the door. Compartment A: For each wash cycle. Compartment B: Fill the detergent dispenser For programs with pre-wash only.

  • Page 3: Table Of Contents

    Dear Customer, Please carefully read this manual before using the dishwasher, it will help you to use and maintain the Control Panel............3 dishwasher properly. Dishwasher Features........3 Keep it for reference in future. Pass it on to any subsequent owner of the appliance. This manual contains sections on safety Instructions, A.
  • Page 4 When using your dishwasher, follow the precautions listed below: This appliance is intended to be used in household and similar applications such as: -staff kitchen areas in shops, offices and other working environments; -farm houses; -by clients in hotels, motels and other residential type environments; -bed and breakfast type environments.
  • Page 5 Do not abuse, sit on, or stand on the door or dish rack of the dishwasher. Do not operate your dishwasher unless all enclosure panels are properly in place. Open the door very carefully if the dishwasher is operating, there is a risk of water squirting out.

  • Page 6: Control Panel

    Dispose of the dishwasher packaging material correctly. All packaging materials can be recycled. Plastic parts are marked with the standard international abbreviations: for polyethylene, e.g. sheet wrapping material for polystyrene, e.g. padding material polyoxymethylene, e.g. plastic clips polypropylene, e.g. Salt filler Acrylonitrile Butadiene Styrene, e.g.
  • Page 7 To get the best performance from your dishwasher, read all operating instructions before using it for the first time. Power Button: To turn On/Off the power supply. Delay Button: To press the button to delay the washing time. Display screen: To show the washing time, Washing Program Selector: Press the button remaining time, error codes and the state etc.

  • Page 8: Rinse Aid Dispenser

    Rinse Aid Dispenser The rinse aid is released during the final rinse to prevent water forming droplets on your dishes, which can leave spots and streaks. It also improves drying by allowing water to roll off the dishes. Your dishwasher is designed to use liquid rinse aids.

  • Page 9: Detergent

    Adjusting Rinse Aid Dispenser The rinse aid dispenser has six or four settings. Always start with the dispenser set on "4". If spots and poor drying are a problem, increase the amount of rinse aid dispensed by removing the dispenser lid and rotating the dial to "5". If the dishes still are not drying properly or are spotted, adjust the dial to the next higher number until your dishes are spot-free.

  • Page 10: Proper Use Of Detergent

    Adding detergent to dispenser If the lid is closed: push the latch to open. Always add the detergent just before starting each wash cycle. Only use branded detergent and rinse aid for dishwasher. Dishwasher detergent is poisonous! Take care to keep it out of reach of children. Proper Use of Detergent Use only detergent specifically made for use in dishwashers.
  • Page 11 Consider buying utensils which are identified as dishwasher-proof. Use a mild detergent that is described as 'kind of dishes'. If necessary, seek further information from detergent manufacturers. For particular items, select a programme with as low a temperature. To prevent damage, do not take glass and cutlery out of the dishwasher immediately after the programme has ended.

  • Page 12: Cutlery Basket

    Position the dishes and cookware so that they do not get moved by the spray of water. Cups Saucers Glasses Dessert dishes Dinner plates Soup plates Cutlery basket Cutlery should be placed into the cutlery basket with handles at the bottom. Soup spoons 2 Forks Knives...
  • Page 13 ℃ Pre-wash(50 ) For the heaviest soiled ℃ Wash (55 loads, such as pots, pans, Rinse Intensive casserole dishes and dishes 0.85 5/17.5g Rinse that have been sitting with (1or2 pieces) ℃ Rinse(70 ) dried food on them for a Drying while.

  • Page 14: Unloading The Dishwasher

    You can modify the washing program, If the dishwasher just worked for a short time. Otherwise, the detergent may have already been released, and the appliance may have already drained the wash water. In this case, the detergent dispenser must be refilled (see the section entitled "Detergent " ). Press Start/Pause Button more than three seconds the machine will be in stand by state, then you can change the program to the desired cycle setting(see the section entitled "...

  • Page 15: Filter Assembly

    The filter prevent larger remnants of food or other objects from getting inside the pump. The filter system consists of a coarse filter, a flat (Main filter) and a micro filter (fine filter). Main filter Food and soil particles trapped by this filter are pulverized by a special jet on the spray arm and washed down to drain.

  • Page 16: Cleaning The Filter

    Notes: - Inspect the filters for blocking after every time the dishwasher has been used. - By unscrewing the coarse filter, you can remove the filter system.Remove any food remnants and clean the filters under running water. The entire filter assembly should be cleaned once a week. Cleaning The Filter To clean the coarse filter and the fine filter, use a cleaning brush.
  • Page 17 Cleaning the Spray Arms The spray arms can be easily removed for periodic cleaning of the nozzles to prevent possible clogging. Wash them under running water and carefully replace them in their seats, checking that their rotary movement is in no way impeded. Grasp the middle of the spray arm, pull it upwards to remove it.
  • Page 18 Position the appliance in the desired location. The back should rest against the wall behind it, and the sides, along the adjacent cabinets or wall. The dishwasher is equipped with water supply and drain hoses that can be positioned to the right or the left to facilitate proper installation. For personal safety: Do not use an extension cord or an adapter plug with this appliance.
  • Page 19 Insert the drain hose into a drain pipe with a minimum diameter of 4cm, or let it run into the sink, making sure to avoid bending or crimping it. The free end of the hose must be at a height lower than 30 cm and must not be immersed into water to avoid the backflow of it.

  • Page 20: Water Outlet

    How to Drain Excess Water From Hoses If the sink is more than 1000mm higher than the floor, the excess water in hoses cannot be drained directly into the sink. It will be necessary to drain excess water from hoses into a bowl or suitable container that is held outside and lower than the sink.

  • Page 21: Technical Problems

    Fuse blown, or the Replace fuse or reset circuit breaker. Remove any other circuit breaker tripped. appliances sharing the same circuit with the dishwasher Make sure the dishwasher is turned on and the door is Power supply is not turned on. closed securely.

  • Page 22: Wash Cycle Table

    The dishes were not See notes in " Loading the Dishwasher Baskets ". loaded correctly. The program was Select a more intensive programme. not powerful enough. See" Wash Cycle Table . " Not enough detergent Use more detergent, or change your detergent. was dispensed.
  • Page 23 Height: 438mm Width: 550mm Depth: 500mm Voltage connected Load: see rating label Water pressure: 0.04-1.0MPa Power supply: see rating label Capacity: 6 Place settings...
