Connecting external audio/video devices

Connecting a DVD, VCR, STB or audio/video equipment

Connect your DVD player, VCR or audio/video equipment using the SCART port located at the rear of your LCD TV as shown
below.
Source-IN
Yellow
Y
Red
R
White
W
Blue
B
Green
G
* Acer recommends the following priority for connection types:
HDMI -> COMPONENT -> SCART -> Composite.
TV-OUT
*SCART-out only works with analog broadcasts.
Acer.TV.EU.UK.indb 7
R W
R
COMPONENT
AV3
D-Sub
HDMI
R B G
D-Sub
or
VCR
DVD
Recorder
Y
B G
AV3
SCART
Y
W
R
or
STB
SCART
*
AV
7
6/23/2006 9:37:07 AM
