Technical Specifications - Johnson Controls T2000 series Installation Instructions

Technical Specifications

Product
Power Requirements
Thermostat Switch
System Switch
Fan Switch
Low Voltage Control
Ratings
Ambient Operating
Conditions*
Ambient Storage
Conditions*
Dimensions
Shipping Weight
* Operating or storing this thermostat at temperatures outside the stated limits can result in damage to the bellows.
The performance specifications are nominal and conform to acceptable industry standards. For application at conditions beyond these
specifications, consult the local Johnson Controls office. Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or
misuse of its products.
Controls Group
507 E. Michigan Street
P.O. Box 423
Milwaukee, WI 53201
4 T2000 Series Low Voltage Fan Coil Thermostats Installation Instructions
T2000ACC-0C0
T2000ACF-0C0
T2000ECC-0C0
T2000ECF-0C0
24 VAC at 50/60 Hz, Class 2
Setpoint Range
ACx Models:
ECx Models:
All Models:
Current:
Power:
44 to 85°F; (7 to 30°C) 85% Noncondensing RH
-40 to 122°F; (-40 to 50°C) 85% Noncondensing RH
3.46 x 5.24 x 1.91 in. (88 x 133 x 49 mm)
0.55 lb (0.26 kg)
Low Voltage Heat-Off-Cool Wallbox Fan Coil
Thermostat with Celsius Temperature Setpoint Scale
Low Voltage Heat-Off-Cool Wallbox Fan Coil
Thermostat with Fahrenheit Temperature Setpoint Scale
Low Voltage On-Off Wallbox Fan Coil Thermostat
with Celsius Temperature Setpoint Scale
Low Voltage On-Off Wallbox Fan Coil Thermostat
with Fahrenheit Temperature Setpoint Scale
50 to 85°F; (10 to 30°C)
Double-Pole, Triple Throw (DP3T)
Double-Pole, Double Throw (DPDT)
Double-Pole, Triple Throw (DP3T)
2 A 2 A, Non-Inductive
48 VA, Class 2
Published in U.S.A.
