HIGH-EFFICIENCY DOWNFLOW / HORIZONTAL FURNACE
INSTALLER'S INFORMATION MANUAL
ATTENTION, INSTALLER!
furnace, show the user how to turn off gas and electricity to
the furnace. Point out control and switch locations for
turning off gas and electricity.
Information Manual and Section 23, "Maintaining Furnace
In Good Working Order" in this manual with the user. Make
sure the user understands the importance of following all
safety precautions, including what could happen if they do
not.
Attach the following documents to or adjacent to the
furnace. Tell the user where these documents are located.
•
User's Information Manual
•
Installer's Information Manual
•
Parts List
•
Warranty Information
While these instructions have been written as accurately
and thoroughly as possible, they can not cover every
system
variation
or
contingency.
interpretation may arise. For more information, solutions to
particular problems or clarification, contact your local
distributor or the manufacturer.
DOWNFLOW POSITION SHOWN
After installing the
Go over the User's
Questions
ATTENTION, USER!
give you the documents l i sted on opposite side. You
should immediately read the User's Information Manual for
important safety information to keep you and your family
safe. Keep these as long as you keep your furnace. Pass
them on to future furnace purchasers or users. If any of the
documents are missing or illegible, contact your installer or
furnace manufacturer for replacement. Throughout this
manual, when we use the word "you" we refer to the
qualified service technician who is responsible for
application, installation and service of your furnace.
? ? Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
? ? WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch.
•
Do not use any phone in your building.
•
Immediately call your gas supplier from a neighbor's
of
phone. Follow the gas supplier's instructions.
•
If you cannot reach gas supplier, call the fire
department.
Your furnace installer should
431570 G
