Vax Dynamo Power Total Home User Manual page 11

24hr
Leave for 24 hours
or until fully dry
before replacing.
Post-motor filter maintenance
IMPORTANT: The post motor filter is designed to offer long life with no maintenance. The filter should
be checked periodically and when heavily discoloured it should be replaced. Please do not wash,
scrub or brush the filter as this will damage the filter
Push the post-motor filter
cover release clip to the right
to remove the post motor
filter cover.
Cleaning the separator, shroud and separator plate
After emptying the dirt container, twist the separator
clockwise to unlock and lift to remove.
Taking care of your machine
Refit the pre-motor filter
into the dirt container
with the tab being visible.
Pull the post motor
filter to the left and
remove the post
motor filter.
click!
In a hinge like manner
close the dirt bin lid until
it clicks into place.
Check the post motor filter for discolouration.
Do not wash the post motor filter.
!
40˚C
MAX
24h
