Introduction Table of Contents Thank you for choosing this Sony product. Before operating the TV, please read this manual thoroughly and retain it for future reference. Note • Before operating the TV, please read “Safety information” (page 2). • Instructions about “Installing the TV to the Wall” are included within this TV’s instructions manual.
Page 3
8 mm - 12 mm cabinet. • Leave space around the TV set as shown below. • It is strongly recommended that you use a Sony Wall-Mount Bracket in order to provide adequate air-circulation. Screw (supplied with the Installed on the wall...
Disconnect the TV set from AC power outlet (mains socket) and Use only Sony supplied AC power cords (mains lead), not those antenna (aerial) during lightning storms. of other brands.
• Do not use, store, or leave the 3D Glasses or battery near a fire, or in places with a high temperature, e.g., in direct sunlight, or Attaching the Table-Top Stand in sun-heated cars. • When using the simulated 3D function, please note that the displayed image is modified from the original due to the (Alternative) conversion done by this television.
Page 6
KD-65X9500B Note • Two or more people are needed to carry out this installation. • Ensure that there are no objects in front of the TV. Middle position 3D Sync Transmitter (KD-65X9500B, KD-65/55X9000B only) IR Sensor To bundle the cables KD-79/65/55X9000B Thick cushion...
Note • To detach the cable clamper from the TV, press the top of the clamper 1, then pinch 2 as illustrated. Hiding the camera If you do not wish to use the camera, hide it as illustrated.
Launching the Touchpad Tutorial Using the Remote Control Press HOME. You can operate the TV by using the supplied Touchpad Remote Control or IR (infrared) Remote Control. Touchpad Remote Control Remote Control Slide to select [Help], then press the touchpad. Note •...
To connect with AV composite cables Connecting Other Devices For more information on connections, refer to the i-Manual. Note • For connection with Port Replicator, refer to the installation guide supplied with the Port Replicator. To connect with an HDMI cable Note •...
Page 10
The TV simultaneously charges the MHL- compatible connected device while playing photo/music/video files. You can use the TV remote control to control the connected MHL- compatible device. Note • If [Auto Input Change (MHL)] is set to [On], the TV automatically switches to HDMI IN 2/MHL or HDMI IN 4/MHL from other input when MHL-compatible device is connected to HDMI IN 2/MHL or HDMI IN 4/...
Sufficient expertise is required for installing this product, especially to determine the strength of the wall for withstanding the TV’s weight. Be sure to entrust the attachment of this product to the wall to Sony dealers or licensed contractors and pay adequate attention to safety during the installation. Sony is not liable for any damage or injury caused by mishandling or improper installation.
Page 12
Attach the Mounting Hook using the four screws supplied with the Wall-Mount Bracket. Mounting Hook Screw (+PSW 6 × 16) Make sure that the wall has enough space for the TV and is capable of supporting a weight of at least four times that of the TV. Refer to the following table on installing the TV to the wall.
Page 13
Connect necessary cables to the TV. Detach the Table-Top Stand from the TV. Note • When attaching the Table-Top Stand again, be sure to fasten the screws (previously removed) to the original holes on the rear of the TV.. Install the TV on the wall. Model Name Screw location Hook location...
SU-WL450 (KD-65X9500B, KD-65/55X9000B only) Remove the screws from the rear of the TV. KD-65X9500B KD-65/55X9000B * Do not remove for Super Slim mounting. Attach Wall-Mount Attachment I (supplied with the TV) to the rear of the TV (to make it parallel with the wall).
Page 15
Make sure that the wall has enough space for the TV and is capable of supporting a weight of at least four times that of the TV. Refer to the following table on installing the TV to the wall. See page 19-21 (Specifications) for the TV’s weight. KD-65X9500B Standard mounting Screen centre point...
Page 16
Attach the Attachment parts for Wall-Mount Bracket. Check the Attachment parts by referring to “1” of the Wall-Mount Bracket Installation Guide. Note • If using an electric screwdriver, set the torque at approximately 1.5 N·m {15 kgf·cm}. • Be sure to store the unused parts in a safe place for future use. Retain this manual for future reference. Standard mounting KD-65X9500B KD-65/55X9000B...
Page 17
Detach the Table-Top Stand from the TV. KD-65X9500B KD-65/55X9000B Install the TV to the Base. Refer to “5” of Installation Guide and “Installing the TV to the Wall” of Operating Instructions supplied with the Wall-Mount Bracket. Model Name KD- Hook location 65X9500B/65X9000B 55X9000B Refer to the instructions supplied with the Wall-Mount Bracket for your model to install the TV on the wall.
See below illustration for location of the buttons If the problem persists, contact your dealer or on the TV. Sony service centre with the number of times Rear of TV the Illumination LED flashes red (interval time is three seconds). Press / on the TV to turn it off, disconnect the mains lead, and inform your dealer or Sony service centre.
• Wi-Fi, Wi-Fi Direct and Miracast are KD-55X9000B: 573 mm trademarks or registered trademarks of Mass (Approx.) Wi-Fi Alliance. • “Sony Entertainment Network logo” and with Table-Top Stand “Sony Entertainment Network” are KD-79X9000B: 60.9 kg trademarks of Sony Corporation. KD-65X9500B: 43.9 kg KD-65X9000B: 46.6 kg...
Page 23
KD-79X9000B 牆壁 牆壁 AC 電源線 為了避免火災、觸電或損壞及 / 或受傷等危險,請遵照下列指示來處 理 AC 電源線和插座 : 請僅使用 Sony 隨附的 AC 電源線,不要使用其它品牌的電源線。 KD-65X9500B 將插頭完全插入 AC 電源插座。 僅可在 220-240 V AC 電源上使用電視機。 連接訊號線時,為了安全起見請務必拔下 AC 電源線,以免被訊號線 絆到腳。 在進行作業或移動電視機之前, 請從 AC 電源插座上斷開 AC 電源線的...
請參閲下圖有關電視機上按鈕的位置。 當照明 LED 閃紅燈時,計算閃爍次數 (間隔時間 電視機背面 為三秒) 。 如果照明 LED 閃紅燈,從電視機拔下 AC 電源線, 待兩分鐘之後再打開電視機,以進行電視機重設。 如果問題仍然存在,請聯繫您的經銷商或 Sony 服 務中心並告知照明 LED 閃紅燈的次數 (間隔時間 為三秒) 。按電視機上的 / 將其關閉,拔掉 AC 電源線,然後告訴您的經銷商或 Sony 服務中心。 照明 LED 開啓。 當發光 LED 沒有閃爍,檢查以下列表中的項目。 如果您不要發光 LED 亮起,您可將之關閉。...
Page 40
• Bluetooth® 字標和標誌乃 Bluetooth SIG, Inc. 所有,Sony Corporation 在授權下使 用這些標記。其他的商標和商品名稱屬於其 各自的所有者。 • N Mark 是 NFC Forum, Inc. 在美國和其他國 家的商標或註冊商標。 2014 RealNetworks, Inc. 專利申請中。版 • 權所有。RealNetworks 標誌是 RealNetworks, Inc. 的商標。...
