CONTENTS
POINTS OF ATTENTION................................1-3
OPERATION INTERFACE...............................4-7
BASIC PLAYBACK.........................................8-17
SYSTEM SETUP.............................................18-20
TROUBLE SHOOTING....................................21
SPECIFICATIONS..........................................22
ADDITIONAL INFORMATION.........................23
Thank you for choosing this AIRIS DVD-player. We strongly recommend that you carefully study the
instruction manual before attempting to operate the unit and keep it well for reference.
As the best source of signals, DVD player is much better than any former audio-video product at any
aspect. This latest digital technology condenses high quality video & audio on a disc, which is the
same size of a normal CD disc in size, providing clear picture and 5.1 channel Dolby digital decoder,
which can provide you a feeling of enjoying more distinct and stirring family theatre.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LW108A and is the answer not in the manual?

Questions and answers

Related Manuals for AIRIS LW108A

Summary of Contents for AIRIS LW108A

  • Page 1: Table Of Contents

    SPECIFICATIONS..........22 ADDITIONAL INFORMATION......23 Thank you for choosing this AIRIS DVD-player. We strongly recommend that you carefully study the instruction manual before attempting to operate the unit and keep it well for reference. As the best source of signals, DVD player is much better than any former audio-video product at any aspect.

  • Page 2: Points Of Attention

    Points of Attention WARNING: To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture. The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus. CLASSILASER PRODUCT The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”...

  • Page 3: Important Safety Instructions

    Points of Attention Important Safety Instructions: Read these instructions. Keep these instructions. Heed all warning. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings, Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

  • Page 4: Points Of Attention

    Points of Attention REMOTE CONTROL OPERATION: 1.remove battery cover 2.insert batteries 3.close the battery cover CARE OF REMOTE CONTROL: Aim remote control at remote sensor of DVD. Do not drop the unit from a high position or cause high imct Do not place the remote control in hot or moist environments Do not splash water or any other liquid on remote control Do not pull disassemble the remote control...

  • Page 5: Operation Interface

    OPERATION INTERFACE FRONT PANEL: Skip backward Skip forward Play/pause REAR PANEL: 1 2 3 8 9 10 11 12 13 1. Component Video (Y) output (ORANGE) 2. Component Video (PbCb) output (GREEN) 3. Component Video (PrCr) output (RED) 4. Composite Video Output (BLUE) 5.
  • Page 6 OPERATION INTERFACE REMOTE CONTROL: Standby:power on or off. ANGLE Angle: select different viewing angles. RANDOM Random: random playback. STEP Step: play in a single frame. ZOOM ZOOM: zoom in the picture. VIDEO Video: select different video mode output (this kind of unit do not hold this function). PBC: open/close PBC playback.
  • Page 7 OPERATION INTERFACE Illustration of system connection is only for reference. NOTICE:Before connecting the cables, please turn off the unit power Component Video Connecting Wire WHITE ORANGE GREEN Green Blue PURPLE BLUE Digital decoder amplifier Coaxial connection cable Stereo amplifier If connected to Digital Decode amplifier , please connect Coaxial output on the unit to Coaxial input on the amplifier correspondingly.

  • Page 8: Basic Playback

    BASIC PLAYBACK Play CD disc 1. Place the CD disc in. 2.Show the contents of the disc play auto matically. 3.Choose the number key to play directly. For example : when you want the No.8 track, you can just press the number key "8".
  • Page 9 BASIC PLAYBACK Play MP3 disc 1.Place the MP3 disc in. 2.After the unit reading the contents of the MP3 disc, the TV screen will show the menu as follows: 00:00 00:00 001/008 folder 01 folder 01 folder 01 folder 01 folder 01 folder 01 1.Choose the desired file you want by direction cursor, press “enter”...
  • Page 10 BASIC PLAYBACK Play MPEG4 disc What is MPEG-4? MPEG-4 refers to a kind of signal which authorized due to MPEG-4 compressed standard, it can magnify the low bit rate to high quality image or recover the low bit rate, then decrease the memory.
  • Page 11 BASIC PLAYBACK [STANDBY] Press this key in working status to turn the unit into standby status, or to wakeup the unit from standby status. When in standby status, pressing OPEN/CLOSE, PLAY/PAUSE buttons on the front panel also can turn on the unit. [OPEN/CLOSE] Press OPEN/CLOSE to open the tray, and then place the disc on it ,press this button again to close the tray.
  • Page 12 BASIC PLAYBACK [PREV/NEXT] When play DVD, VCD, CD, MP3, Press skipbackward to play last chapter. To play DVD, press skipbackward to last chapter or title.press skipforward to next chapter or title. [REW/FF] When play DVD, SVCD, VCD, CD, MP3, press this key to play forward or backward speedily. The class as bellows: [TITLE] Press this button to return to the first title playback.
  • Page 13 BASIC PLAYBACK [PLAY/ENTER] press to play or confirm all kinds operation and selection. [P/N] press this key can select PAL or NTSC mode. [SLOW] when playing VCD, SVCD, DVD, CD disc, press “SLOW”continuously to play forward with different speed. [MUTE] Press “...
  • Page 14 BASIC PLAYBACK [DISPLAY] Press DISPLAY to display the information referring to the disc on the TV screen. playback DVD disc state play super VCD,VCD2.0 in the state of closeing PBC play super VCD,VCD2.0 in the state of opening PBC [VIDEO] Press this key repeatedly to convert among I chromatism YCbCr, nterleaving Scan...
  • Page 15 BASIC PLAYBACK [SEARCH] MENU MENU 01/20 Title 01/16 Track 01/01 Chapter 1•16•28 Disc Time AC-3 5.1CH Audio Track Time 0•03•58 Subtitle CHINESE Repeat Angle Time Display Total Elapsed 0•06•58 Title Time 0•06•58 Chapter Time SVCD Repeat Elapsed Time Display Bit rate Bit rate 28 III Title Elapsed 0•03•28 28 III Total Elapsed 0•03•28...
  • Page 16 BASIC PLAYBACK Play MP3 disc: After the unit reads the contents of the MP3 disc, the TV screen will show as follows: Play time Track time Volume Working Dynamic modulation state frequency 03•18 05•28 Playing track 058/158 Tracks of disc - - - - - - - - - - - - - - - - - - - - -...
  • Page 17 BASIC PLAYBACK Play JPEG disc: After the unit reading the content of e-album disc, the TV screen display shows as follows: Working state 00•00 00•00 Playing track 058/158 Tracks of disc JPEG - - - - - - - - - - - - - - JPEG - - - - - - - JPEG...

  • Page 18: System Setup

    SYSTEM SETUP When the unit is working, press the select key to enter setup menu (following picture): * Please note that the instruction manual only for basic operation, that you can setup the menu according to the real demand. General Audio Video Preference...
  • Page 19 SYSTEM SETUP DownMix: In LT/RT or stereo output mode, the center speaker Audio Setup Page: HDCD and rear speaker on this page cannot setup, only can if in 5.1 channel output mode. Downmix Stereo LT/RT Stereo 5.1Ch SPDIF output: Front speaker Large (SPDIF/RAW): when the unit and the amplifier are Small...
  • Page 20 SYSTEM SETUP TV TYPE: Setup Preference Page: The unit can correspond with erery type of TV all over the world, Select your TV type on this item: Tv Type Auto: Select TV type according to the color system of Auto the playing disc automatically.

  • Page 21: Trouble Shooting

    TROUBLE SHOOTING SYMPTOM AND SOLUTION: Symptom Reason(s) Solution(s) No power Do not connect power cord to the wall outlet Connect them well Do not set up TV in correct setting Set up TV in correct mode No picture Do not connect video cable securely Connect them well Do not connect audio cable securely Connect them well...

  • Page 22: Specifications

    SPECIFICATIONS DVD PLAYER/OUTPUT: DVD Player ~ 110 -240V 50/60Hz Power Supply Power Consumption 2.5Kg Weight 360x232x33mm(L/W/H) Dimension NTSC/PAL Video System Semiconductor AIGaAs Weam, wave length: 650nm,780nm Optical read-out system DVD audio: Fs 48KHz PCM 4 Hz~22KHz Audio Frequency Response Fs 96KHz PCM 4Hz~44KHz Audio CD Fs 44.1Hz 4Hz~20KHz >80dB S/N Ratio...

  • Page 23: Additional Information

    ADDITIONAL INFORMATION Care of disc: Do not touch the signal surface. Do not add labels or adhesive tapes on the discs. Cleaning of discs: Finger prints or stains on the surface of the disc will directly affect signal recording and result in a poorer picture quality. Therefore, please use a soft cloth and wipe in a radiating manner from the centre to the outer rims when cleaning the disc.
