Doorbell and Phone Ring Alerting system
AM20
PLEASE READ THIS USER GUIDE BEFORE INITIAL USE.
Keep this user guide for future reference. Always retain your proof of purchase in case of warranty
service and register your product on line at AUSTRALIA: www.oricom.com.au
Please visit www.oricom.com.au for the latest copy of the user manual.
Oricom Customer Support: 1300 889 785 or (02) 4574 8888
Advertisement
Table of Contents
Summary of Contents for Oricom AM20
-
Page 1: User Manual
Keep this user guide for future reference. Always retain your proof of purchase in case of warranty service and register your product on line at AUSTRALIA: www.oricom.com.au Please visit www.oricom.com.au for the latest copy of the user manual. Oricom Customer Support: 1300 889 785 or (02) 4574 8888... - Page 2 (4 X AA Alkaline- Batteries not supplied) Wall mounting screw holes LINE PHONE REAR Shaker jack AC adaptor jack Socket for Telephone connection or to connect to a Pairing/Test button second AM20 (not Supplied) Socket for Telephone line connection...
- Page 3 Installation This Pack Contains One AM20 Main Unit One Wireless doorbell One Desk Stand One Energy efficient MEPS AC Adaptor One Telephone Line cord Four screws and raw plugs for wall mounting Warning The product is designed for indoor use only.
- Page 4 Installation • T his product has been designed for individuals who are hard of hearing and has volume which is louder than a standard product. • D o not connect this product to an extension of a Digital Telephone system (PBX). Damage to this product or the phone system may occur. Notes for operation in New Zealand The grant of a Telepermit for any item of terminal equipment indicates only that Telecom has accepted...
- Page 5 Installation REN (RN for New Zealand) The REN (Ringer Equivalence Number) or (RN) is of significance only if you wish to connect more than 1 telephone to your telephone line. A standard telephone line has a maximum REN capacity of 5 (RN of 5). It is possible to connect 5 devices with a REN of 1 (RN of 1) with no degradation to the product’s performance.
-
Page 6: How To Connect
AM20 and the other end to the wall socket. 3) Connect the telephone cable between the AM20 and your telephone. 4) Plug the power cable into the power AC adaptor jack of the AM20. Plug the AC adaptor into the mains power point. - Page 7 2. Hang the base onto the two screws (supplied) and pull the base down to lock it on. Table Mounting If you want to mount the AM20 on a table, simply clip it into the base stand and place on a table.
- Page 8 The three position switch allows you to set a different tone when the doorbell rings. Fitting Batteries in the AM20 For battery back up in case of power failure or for portable use when no mains power is available the main...
- Page 9 . Adding a second AM20 If required a second AM20 can be added to the system contact Oricom 1300 889 785 for details. Change the Battery in the Doorbell...
- Page 10 The Pairing Procedure 1. Press and hold the Pairing/Test button until the AM20 makes a beep sound, then release the Pairing/Test button. The LED lights to indicate that the pairing mode has been entered.
-
Page 11: Operation
Installation 4. Repeat the above, all 3 LEDS flashing together for the remote pairing. Un- Register The Pairing: 1. Press and hold the Pairing/Test button for 5 seconds to enter un-register mode, 3 LEDs flash together. 2. If user wants to un-register the 1 doorbell, press the Pairing/Test button once, the 1 LED will be flashing (the... -
Page 12: Troubleshooting
(depending on the Alarm mode setting) Trouble shooting Symptom Solution No incoming call 1) Check the batteries are inserted yet the AM20 rings correctly. automatically or rings 2) Check the power adaptor is continuously. connected correctly. The shaker vibrates... - Page 13 2) Check the shaker socket to see if it has been damaged. 3) Check the alarm mode selection switch position is correct. The AM20 does not 1) Check that the red light on ring when the doorbell the doorbell flashes when it is is pressed pressed.
-
Page 14: Customer Support
Troubleshooting section of this user guide as well as “Frequently Asked Questions” on our website www.oricom.com.au. If you have further questions about using the product after reviewing the resources above or would like to purchase replacement parts or accessories please call our Customer Support Team. - Page 15 Please note that if a Customer Support Team member advises that your product does not qualify for return, this warranty does not apply to your product. Products that are authorised to be returned to Oricom in Australia must include all of the following: • A completed Return Authorisation form • A copy of your Proof of Purchase (please keep your...
-
Page 16: Repair Notice
Warranty Please note that this warranty excludes expenses incurred by you in returning any faulty product to us. You must arrange and pay any expenses incurred (including postage, delivery, freight, transportation or insurance of the product) to return the faulty product to us, however, we will arrange delivery of the repaired or replaced faulty product to you. -
Page 17: Warranty Information (Australia)
Warranty Warranty information (Australia) This Warranty is provided by Oricom International Pty Ltd ABN 46 086 116 369, Unit 1, 4 Sovereign Place, South Windsor NSW 2756, herein after referred to as “Oricom”. Oricom makes no other warranties or conditions, express or implied, including as to acceptable quality and fitness for a particular purpose, except as stated in this Warranty. - Page 18 Oricom. Oricom will not be in breach of a warranty expressly set out in this User Guide or under the Competition and Consumer Act 2010 and excludes any liability for damages or any other remedy arising under any other legislation or the common law if the damage occurs as a result of: 1.
- Page 19 Oricom or Oricom’s authorised service provider. Oricom will not be liable for any damages caused by the product or the failure of the product to perform, including any lost profits or savings or special, incidental or consequential damages. Oricom is not liable for any claim made by a third party or made by you on behalf of a third party.
- Page 20 Contact details for Oricom support and warranty claims in Australia Oricom International Pty Ltd Locked Bag 658 South Windsor, NSW 2756 Australia Email: support@oricom.com.au Phone: 1300 889 785 or (02) 4574 8888 (Monday to Friday 8am to 6pm AEST) Web: www.oricom.com.au...
