E - 16
Problem
Display image is not centered, too
smaIl, or too large
Color looks blotchy

Specifications

Picture Tube
Input Signal
Display Colours
Synchronisation
Range
Resolutions
Video Band Width
Active Display
Area (Factory
Setting)
43 cm (17 inch) flat square CRT, 39.6 cm (15.6 inch)
viewable image size, 0.28 mm dot pitch, Medium-Short
persistence phosphor, semi tint screen, multi-layered,
anti-static OptiClear coating
Video Analog 0.7 Vp-p 75
Sync Separate sync.
Horizontal sync.
Vertical sync.
Composite sync.
Analog Input: Unlimited colours
(Depends on the graphics board)
Horizontal 31 kHz to 82 kHz (Automatically)
Vertical 55 Hz to 100 Hz (Automatically)
Maximum 1280 x 1024 (75 Hz non interlaced)**
Recommended 1024 x 768 (75 Hz non interlaced)*
85 MHz (Typ.)
Horizontal 306 mm (Active display area is
dependent upon the signal timing)
Check These Items
Use the OSM Size and Position
controls to adjust the image.
Adjust the Brightness, then Contrast
Controls. Access the Degauss Control
through OSM. Activate the Degauss
Control. CAUTION: A minimum
interval of 20 minutes should exist
before the Degauss Function is used a
second time.
TTL Level
Positive/Negative
Positive/Negative
TTL Level
Positive/Negative
Specifications
Positive
