i. NORMAL( visual)
Press to reset all the stored adjustment visual data and recall the factory
preset data. When a specific control is selected, this key resets the selected
visual adjustments.

Accessing OSM

Press the PROCEED key on the remote control or front bezel.
To turn off OSM
Press the EXIT key on the remote control or front bezel.
VIDEO 1 VIDEO 2 RGB 1 RGB 2
POSITION / CONTROL PROCEED
EXIT

OSM Menus

On-Screen Manager' s menu of Controls gives you an overview of the
selection of controls available.
PROCEED VIDEO 1
¥
EXIT
PROCEED
EXIT
j. MUTE
Press to turn off the sound for a short period of time; press again to restore the
sound.
k. VOLUME
Press to increase the sound: press
When pressing a key that does not correspond to the function currently
use, the following message will be displayed on the monitor.

Visual Controls Group

The visual controls allow you to adjust the picture controls such as
brightness, contrast, color, tint, and sharpness.
VIDEO 2
¥
BRIGHTNESS : Pressing + or - increases or decreases the image brightness level.
CONTRAST : Pressing + or - increases or decreases the image contrast level.
SHARPNESS : Pressing + or - increases or decreases the image sharpness level.
COLOR : Pressing + or - increases or decreases the image color saturation level
TINT : Pressing + or - increases or decreases the green and red values.
NOTE: The color, tint and sharpness controls are not available for RGB
input, and the tint is not available for PAL input.
NOTE: Pressing the visual NORMAL key resets all the visual controls to the
factory settings when only the visual controls group icon is highlighted.
31
to decrease the sound.
