Specifications

Monitor Specifications
LCD Module
Viewable Image Size: 55.9 cm/22.0 inches
Native Resolution (Pixel Count): 1680 x 1050
Input Signal
Display Colours
Synchronization Range
Viewing Angle
Image Formation Time
Resolutions Supported
Active Landscape: Horiz.: 474 mm/18.7 inches
Display Area
Portrait: Horiz.: 296 mm/11.7 inches
Power Supply
Current Rating
Dimensions
Height Adjustment: 150 mm / 5.9 inches (Landscape)
Weight Net (with stand): 8.5 kg (18.7 lbs)
Gross (with carton box): 10.7 kg (23.6 lbs)
Environmental Considerations
Operating Temperature: 5°C to 35°C/41°F to 95°F
Storage Temperature: -10°C to 60°C/14°F to 140°F
*1 Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This is
normal and necessary for all current flat panel technologies when displaying non-native resolutions full screen. In flat panel technologies, each dot on
the screen is actually one pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
NOTE: Technical specifications are subject to change without notice.
MultiSync P221W Monitor
Diagonal: 55.9 cm/22.0 inches
Video: ANALOG 0.7 Vp-p/75 Ohms
Sync: Separate sync.TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Composite sync. Positive/Negative
Sync on Green (Video 0.7 Vp-p and Sync Negative 0.3 Vp-p)
16,777,216
Horizontal: 31.5 kHz to 81.1 kHz
Vertical: 56 Hz to 75 Hz
Left/Right: ±89° (CR > 10)
Up/Down: ±89° (CR > 10)
16 ms (Typ.)
720 x 400*
640 x 480*
800 x 600*
832 x 624*
1024 x 768*
1152 x 864*
1152 x 870*
1280 x 960*
1280 x 1024*
1360 x 768*
1440 x 900*
1440 x 1050*
1680 x 1050 at 60 Hz....................... optimal display performance.
Vert.: 296 mm/11.7 inches
Vert.: 474 mm/18.7 inches
AC 100-240 V ~ 50/60 Hz
0.95 - 0.40 A (with Option)
Landscape: 506.4 mm (W) x 410 - 560 mm (H) x 247.3 mm (D)
19.9 inches (W) x 16.1 - 22.0 inches (H) x 9.7 inches (D)
Portrait: 328.7 mm (W) x 517.9 - 648.9 mm (H) x 247.3 mm (D)
12.9 inches (W) x 20.4 - 25.5 inches (H) x 9.7 inches (D)
131 mm / 5.1 inches (Portrait)
Humidity: 20% to 80%
Altitude: 0 to 6,562 Feet/0 to 2,000 m
Humidity: 10% to 85%
Altitude: 0 to 6,562 Feet/0 to 2,000 m
1
at 70 Hz
1
at 60 Hz to 75 Hz
1 at 56 Hz to 75 Hz
1 at 75 Hz
1 at 60 Hz to 75 Hz
1
at 75 Hz
1
at 75 Hz
1 at 60 Hz to 75 Hz
1 at 60 Hz to 75 Hz
1
at 60 Hz
1
at 60 Hz to 75 Hz
1 at 60 Hz to 75 Hz
English-14
Notes
Active matrix; thin film transistor (TFT) liquid
crystal display (LCD); 0.282 mm dot pitch;
300 cd/m 2 white luminence; 1000:1 contrast
ratio, typical.
Digital Input: DVI
Depends on display card used.
Automatically
Automatically
Some systems may not support all modes listed.
NEC DISPLAY SOLUTIONS cites
recommended resolution at 60 Hz for
