Page 2: Safety Warning
SAFETY WARNING Disregarding any of the safety precautions and instructions con- tained in this Operator’s Guide, Safety Handbook, Safety Video or on-product warnings may result in injury, including the possibility of death. This Operator’s Guide, Safety Handbook and Safety Video should remain with the unit at time of resale. - Page 3 Dear 2002 MX Z X 440 owner, all informations on MX Z 600 in the 2002 ZX Series Operator’s Guide (P/N 484 100 044) also applies to your MX Z X 440 except for the fol- lowing. 484 100 044 LIMITED WARRANTY VALIDATION The 2002 MX Z X 440 is shipped from the factory with high compres- sion ratio (CR) combustion chamber inserts installed.
-
Page 4: Tether Cut-Out Switch
11) Tether Cut-Out Switch Attach tether cord to clothing then snap tether cut-out cap over re- ceptacle before starting engine. To stop engine, completely pull cap from safety switch. 53) Primer Button Pull and push button. It is not necessary when engine is warm. To prime, activate button until a pumping resistance is felt. -
Page 5: Fuel And Oil
FUEL AND OIL Recommended Fuel Vehicles with Valid Warranty (Octane Level Switch Disabled) Use super unleaded gasoline, available from most service stations or oxygenated fuel containing less than 10% of ethanol or 5% of meth- anol. The gasoline used must have an octane number (R + M)/2 of 91 or higher. -
Page 6: Recommended Oil
CAUTION: Use only oil that flows at - 40°C (- 40°F). Oil must be mixed with fuel in proper ratio in a jerrycan then, be poured in the fuel tank. Use only two-stroke engine injection oil sold by authorized SKI-DOO dealers. MODEL... - Page 7 BOMBARDIER injection oil is a special blend of basic oil and additives especially selected to ensure unequalled lubrication, engine cleanliness and minimum spark plug fouling. The BOMBARDIER Formula XP-S synthetic injection oil provides su- perior lubrication, reduced engine component wear and oil deposit, thus maintaining maximum-level performance and antifriction prop- erties.
- Page 8 OIL/FUEL 33/1 A32I09A METRIC (SI) 1 L of oil + 33 L of fuel = 33/1 IMPERIAL 35 imp. oz of oil + 7.2 imp. gal of fuel = 33/1 1 L of oil + 7.2 imp. gal of fuel = 33/1 UNITED STATES 34 U.S.
-
Page 9: Starting Procedure
STARTING PROCEDURE • Re-check throttle control lever operation. • Ensure that the emergency cut-out switch is in the ON position. • Ensure the tether cut-out cap is in position and that the cord is attached to your clothing. • If applicable use the octane level switch to select proper octane number according to fuel used. -
Page 10: Fluid Level
FLUID LEVEL Coolant Pump Shaft Oil Reservoir Use BOMBARDIER injection oil (P/N 413 802 900) (12 x 1 L). Fill up to mark. Coolant Reservoir Use a blend of 50/50 distilled water and ethylene-glycol. That blend will protect the system from freezing as low as - 37°C (- 35°F). Fill up to mark when engine is cold. -
Page 11: Maintenance
MAINTENANCE Track Tension and Alignment Loosen lock nut on both adjustment screws before adjusting track tension and/or alignment. Retighten after adjustments are done. A32F0WA LEFT SIDE SHOWN 1. Lock nut on adjustment screw... -
Page 12: Specifications
SPECIFICATIONS GENERAL MX Z X 440 Engine – Maximum power engine speed ± 50 RPM 8450 Drive belt – Number 414 860 700 – New belt width mm (in) 34.9 (1-3/8) – Wear limit width mm (in) 32.5 (1-1/4) Spark plug –...
