Quick Start
If your computer is equipped with USB and uses the Windows
you want to operate the monitor's user controls using your system, you can install USB
support by using the following procedure. To attach the USB port on your MultiSync FP
Series monitor to a USB port on your system:
1. Using the supplied USB cable, connect the USB Series B connector end to the USB
upstream port on the monitor (Figure 1).
2. Connect the other end of the supplied cable to the USB downstream port on the
computer (or to a USB Hub attached to the computer (Figure 1).
3. Install the supplied Monitor Control Software.
USB downstream port
78134171
cont.Start
Figure 1
5
7
98 operating system and
®
USB upstream port
USB Series B
connector end
