NEC MultiSync LCD2000 User Manual page 11

Monitor
Specifications
LCD Module
Viewable Image Size:
Native Resolution (Pixel Count):
Input Signal
Display Colors
Synchronization
Range
Resolutions Supported
Resolution based on horizontal and
vertical frequencies only
Active Display Area
Power Supply
Current Rating
Dimensions
Weight
Environmental Considerations
Operating Temperature:
Storage Temperature:
*
Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may
appear choppy or lines may appear to be bold. This is normal and necessary for all current flat panel technologies when
displaying non-native resolutions full screen. In flat panel technologies, each dot on the screen is actually one pixel, so to
expand resolutions to full screen, an interpolation of the resolution must be done. When the interpolated resolution is not
an exact multiple of the native resolution, the mathematical interpolation necessary may cause some lines to appear thicker
than others.
NOTE: Technical specifications are subject to change without notice.
78132391
MultiSync
Monitor
Diagonal: 20.1 inch
20.1 inch
1280 x 1024
Video: ANALOG 0.7 Vp-p/75 Ohms
Sync: Separate sync. TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Composite sync. (Positive/Negative) (TTL Level)
Sync on Green video (Positve) 0.7 Vp-p and sync.
Negative 0.3 Vp-p
Analog input: Unlimited number of Colors
Horizontal: 24.0 kHz to 80 kHz
Vertical: 56.0 Hz to 76 Hz
720 x 400*: VGA text
640 x 480 at 60Hz to 76Hz
800 x 600* at 56Hz to 76Hz
832 x 624* at 75Hz
1024 x 768* at 60Hz to 76Hz
1280 x 960 at 60Hz to 76Hz
1280 x 1024 at 60Hz to 76Hz .................. NEC cites recommended resolution at
Horizontal: 399 mm/15.7 inches
Vertical: 319 mm/12.6 inches
AC 100 – 120 V/ 220 – 240 V @ 50/60 Hz
1.0A @ 100 – 120 V/0.5A @ 220 – 240 V
500 mm (W) x 483 mm (H) x 220 mm (D)
19.7 inches (W) x 19.0 inches (H) x 8.7 inches (D)
10.0 kg
22.0 lbs
5 C to +30 C/41 F to 86 F
Humidity: 30% to 80%
Feet: 0 to 10,000 Feet
-10 C to +60 C/14 F to 140 F
Humidity: 10% to 85%
Feet: 0 to 45,000 Feet
