Controls cont.
• To deactivate the LOCK OUT mode, simultaneously press the PROCEED
and button.
Auto Adjust
AUTO
MultiSync
Automatically adjusts the Image Position, H. Size and Fine settings.
MultiSync LCD
Automatically adjusts the Image Position and H. Size settings.
Position Controls
H. POSITION
Controls Horizontal Image Position within the display area of the LCD.
V. POSITION
Controls Vertical Image Position within the display area of the LCD.
AUTO
AUTO
Automatically sets the Horizontal and Vertical Image Position within
the display area of the LCD.
Image Adjust Controls
H. SIZE
Adjusts the horizontal size by increasing or decreasing this setting.
FINE
Improves focus, clarity and image stability by increasing or decreas-
ing this setting.
NOTE: The Image Adjust Fine control must be used to complete the
setup of your MultiSync LCD
MultiSync LCD
Automatically adjusts the H Size and Fine settings.
MultiSync LCD
Automatically adjusts the H Size setting.
AccuColor
´®
Five color presets select the desired color setting. Each color setting is
adjusted at the factory.
R,G,B: Increases or decreases Red, Green or Blue color depending
upon which is selected. The change in color will appear on screen
and the direction (increase or decrease) will be shown by the bars.
Tools
OSM H POS.
OSM V POS.
You can choose where you would like the OSM
appear on your screen. Selecting OSM Location allows you to manually
adjust the position of the OSM control menu left, right, up or down.
