Harris DX 25U Technical Manual page 127

HARRIS P/N DESCRIPTION
335 0262 000 DF137A INSULATING WASHER
380 0126 000 XSTR, PNP 2N4403 ESD
380 0481 000 XSTR, NJFET 2N4092 ESD
380 0672 000 XSTR, D45H8 ESD
380 0673 000 XSTR, NPN D44H8 ESD
382 0472 000 IC, LM318 ESD
382 0711 000 PRECISION IC MULTIPLIER ESD
382 0718 000 IC, AD7525KN ESD
382 0721 000 IC, MC14504BCP ESD
382 0749 000 IC NE5532A ESD
382 0757 000 IC OP-27 ESD
382 0774 000 IC 74HC14 ESD
382 1048 000 * IC, UC3834N ESD
382 1065 000 IC 74HCT273 ESD
384 0205 000 DIODE SILICON 1N914/4148 ESD
384 0321 000 DIODE 5082-2800/1N5711 ESD
384 0431 000 RECT. 1N4001 ESD
384 0612 000 DIODE 1N3070 ESD
384 0720 000 TRANSZORB 1N6377 15V 5W ESD
384 0799 000 DIODE, BIPOLAR ESD
386 0135 000 ZENER, 1N4733A 5.1V ESD
398 0015 000 FUSE,FAST CART .500A 250V
402 0129 000 CLIP, 1/4 DIA FUSE
404 0303 000 SOCKET IC 10 PIN
404 0507 000 SOCKET IC 18 PIN
404 0673 000 SOCKET 8 PIN DIP (DL)
404 0674 000 SOCKET 14 PIN DIP (D-L)
404 0675 000 SOCKET IC 16 CONT
404 0704 000 SOCKET IC 20 PIN
404 0758 000 HEAT SINK FOR TO-220
410 0405 000 INSULATOR XSTR TO220
494 0395 000 CHOKE 40UH 2 AMP
494 0415 000 CHOKE RF 470.0UH
494 0418 000 CHOKE RF 820.0UH
500 0759 000 CAP, MICA, 100PF 500V 5%
500 1064 000 CAP, MICA, 5100PF 500V 5%
506 0232 000 CAP .01UF 100V 5%
506 0240 000 CAP .033UF 100/63V 5%
506 0243 000 CAP .15UF 63V 5%
506 0246 000 CAP .47UF 63V 5%
506 0262 000 CAP .047UF 100V 5%
508 0547 000 CAP .01UF 160V 1%
516 0375 000 CAP .01UF 50V -20/+80% Z5U
516 0453 000 CAP .1UF 100V 20% X7R
516 0765 000 CAP 10PF 5% 100V C0G
Rev.Y1: 5/24/1999
Table 7-12. ANALOG INPUT - 992 8077 001
WARNING: Disconnect primary power prior to servicing.
QTY/UM REF. SYMBOLS/EXPLANATIONS
2.0 EA #Q005 #Q006
2.0 EA Q001 Q002
2.0 EA Q007 Q008
1.0 EA Q006
1.0 EA Q005
2.0 EA U003 U019
1.0 EA U010
1.0 EA U008
2.0 EA U014 U016
6.0 EA U004 U005 U006 U007 U009 U012
1.0 EA U011
1.0 EA U013
2.0 EA U001 U002
2.0 EA U017 U018
2.0 EA CR009 CR010
3.0 EA CR003 CR021 CR022
2.0 EA CR017 CR019
1.0 EA CR020
2.0 EA CR016 CR018
3.0 EA CR001 CR002 CR007
4.0 EA CR006 CR011 CR012 CR015
2.0 EA F002 F003
4.0 EA XF002 XF003
1.0 EA XU010
1.0 EA XU008
9.0 EA XU003 XU004 XU005 XU006 XU007 XU009
XU011 XU012 XU019
1.0 EA XU013
4.0 EA XU001 XU002 XU014 XU016
2.0 EA XU017 XU018
1.0 EA #Q005 #Q006
2.0 EA #Q005 #Q006
2.0 EA L006 L007
2.0 EA L001 L003
2.0 EA L002 L004
2.0 EA C077 C080
2.0 EA C001 C002
1.0 EA C052
2.0 EA C003 C004
1.0 EA C076
7.0 EA C005 C006 C007 C008 C046 C051 C053
1.0 EA C083
1.0 EA C062
20.0 EA C010 C012 C016 C019 C023 C024 C028 C030
C031 C033 C035 C037 C040 C043 C049 C056
C059 C074 C082 C085
28.0 EA C009 C011 C017 C018 C022 C025 C027 C029
C032 C036 C038 C041 C044 C047 C050 C057
C058 C060 C061 C063 C064 C066 C067 C068
C069 C070 C071 C087
6.0 EA C021 C026
888-2297-002
Section VII - Parts List
7-21
