Harris DX 25U Technical Manual page 123

548 2400 366 RES 4.75K OHM 1/2W 1%
548 2400 369 RES 5.11K OHM 1/2W 1%
548 2400 377 RES 6.19K OHM 1/2W 1%
548 2400 385 RES 7.5K OHM 1/2W 1%
548 2400 401 RES 10K OHM 1/2W 1%
548 2400 418 RES 15K OHM 1/2W 1%
548 2400 446 RES 29.4K OHM 1/2W 1%
548 2400 447 RES 30.1K OHM 1/2W 1%
548 2400 468 RES 49.9K OHM 1/2W 1%
548 2400 469 RES 51.1K OHM 1/2W 1%
548 2400 477 RES 61.9K OHM 1/2W 1%
548 2400 488 RES 80.6K OHM 1/2W 1%
548 2400 489 RES 82.5K OHM 1/2W 1%
548 2400 501 RES 100K OHM 1/2W 1%
548 2400 509 RES 121K OHM 1/2W 1%
548 2400 530 RES 200K OHM 1/2W 1%
548 2400 547 RES 301K OHM 1/2W 1%
548 2400 562 RES 432K OHM 1/2W 1%
548 2400 566 RES 475K OHM 1/2W 1%
548 2400 585 RES 750K OHM 1/2W 1%
548 2400 601 RES 1MEG OHM 1/2W 1%
548 2400 612 RES 1.3MEG OHM 1/2W 1%
604 0866 000 SW, PB SNAP ACTION SPDT
604 1089 000 SW, TGL SPDT PC MOUNT
610 0980 000 HDR 20C 2ROW RT ANG
610 0986 000 HDR 40C 2ROW RT ANG
610 0987 000 HDR 40C 2 ROW STRAIGHT
610 0999 000 HDR, 10 PIN, PC BD
610 1112 000 HDR 4C 2R STRT NP
612 1184 000 SHUNT JUMPER 0.1" CENTERS
843 5400 091 SCH, CONTROLLER
843 5400 093 PWB, CONTROLLER
HARRIS P/N DESCRIPTION
358 1928 000 JUMPER 1/4 LG 1/8H
358 2177 000 SPACER, LED MOUNT .380 LG
358 2827 000 SPACER, LED MOUNT .25 LG
380 0125 000 XSTR, NPN 2N4401 ESD
382 0309 000 IC, SN74LS08N ESD
382 0452 000 IC, LM311/CA311 ESD
382 0556 000 IC, 74LS00N ESD
382 0557 000 IC, 74LS02 ESD
382 0558 000 IC, 74LS04N TTL INV ESD
382 0580 000 IC, 74LS32 ESD
382 0594 000 IC TL074ACN ESD
382 0648 000 IC, LM339A ESD
382 0768 000 IC, 74HC00 ESD
382 0769 000 IC 74HC02 ESD
Rev.Y1: 5/24/1999
Table 7-11. LED BOARD - 992 8072 002
WARNING: Disconnect primary power prior to servicing.
1.0 EA R070
4.0 EA R042 R049 R057 R058
3.0 EA R064 R092 R104
2.0 EA R091 R094
3.0 EA R035 R036 R066
2.0 EA R047 R074
2.0 EA R067 R068
5.0 EA R063 R088 R089 R090 R096
2.0 EA R073 R086
5.0 EA R040 R048 R062 R075 R076
1.0 EA R033
1.0 EA R038
1.0 EA R065
6.0 EA R021 R029 R031 R041 R043 R059
2.0 EA R072 R085
1.0 EA R019
2.0 EA R028 R030
1.0 EA R020
1.0 EA R006
1.0 EA R016
1.0 EA R046
1.0 EA R032
1.0 EA S001
1.0 EA S002
1.0 EA J005
3.0 EA J002 J007 J008
2.0 EA J001 J003
2.0 EA J004 J006
4.0 EA JP003 JP004 JP005 JP006
4.0 EA P001 P002 P003 P004
0.0 EA
1.0 EA
QTY/UM REF. SYMBOLS/EXPLANATIONS
6.0 EA JP001 JP002 JP003 JP004 JP005 JP006
2.0 EA #DS019 #DS020
26.0 EA #DS001 #DS002 #DS003 #DS004 #DS005
#DS006 #DS007 #DS008 #DS009 #DS010
#DS011 #DS012 #DS013 #DS014 #DS015
#DS016 #DS017 #DS018 #DS021 #DS022
#DS023 #DS024 #DS025 #DS026 #DS027
#DS028
1.0 EA Q001
2.0 EA U038 U059
1.0 EA U043
1.0 EA U062
1.0 EA U060
6.0 EA U017 U033 U036 U047 U054 U058
1.0 EA U037
3.0 EA U001 U027 U057
5.0 EA U002 U005 U061 U067 U068
2.0 EA U008 U063
1.0 EA U003
888-2297-002
Section VII - Parts List
7-17
