LED FUNCTION
LED
INDICATOR
OPERATION
BATTERY
PACK
Without
Power
battery pack
Hot battery
Evaluate
pack
Cold
Evaluate
battery pack
Deeply
Evaluate
discharged
Defective Defective
• If defective, try to repeat the conditions a second time by removing and reinstalling the
battery pack. If the LED status repeats a second time, try charging a different battery.
• If a different battery charges normally, dispose of the defective pack (see Maintenance
section).
• If a different battery also indicates "Defective," the charger may be defective.
Fast
Charging
charging
Full —
RED GREEN
LED LED
ON OFF
Flashing OFF
Flashing OFF
Flashing OFF
Flashing Flashing
ON Flashing
OFF ON
8
ACTION
Ready to charge battery pack.
When battery pack reaches cooled
temperature, charger begins fast
charge mode.
When battery pack reaches warmed
temperature, charger begins fast
charge mode.
Charger pre-charges battery until
normal voltage is reached, then
begins fast charge mode.
Battery pack or charger is
defective.
—
Fast charging is complete;
charger maintains charge mode.
Fig. 4
