  • Page 1: User Manual

    USER MANUAL with SmartS™ English-New Zealand + UK...

  • Page 2: Disposal Of Electrical And Electronic Equipment

    Back-On-Track, Drive-Away, Turn-by-Turn and Smart are either registered trademarks or trademarks of Brunswick New Technologies Asia Pte Limited and are used under licence by Navman New Zealand. All rights reserved. Microsoft Windows 98 SE, ME, 2000 and XP SP1, Microsoft Internet Explorer and ActiveSync are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.

  • Page 3: Table Of Contents

    Contents Box Contents ... 5 1. Introduction ... 7 2. iCN Features ... 8 3. Starting your iCN ... 12 4. Setting your Destination ... 15 By Address ... 18 By POI ... 21 5. Using the 2D Map Screen to Plan a Route ... 23 6.

  • Page 4: Important Safety Information

    Failure to adhere to these instructions may lead to death, serious injury, or property damage. Navman disclaims all liability for use of the iCN that causes or contributes to death, injury, or property damage or that violates any law. Navman is not responsible for the accuracy of any traffic-related information supplied by other parties and disclaims all liability for any accident,...

  • Page 5: Box Contents

    Thank you for purchasing your Navman iCN 530. We hope you enjoy your new GPS transferable navigation system. This user manual will help you Drive-Away™ with your iCN, straight out of the box. Navman welcomes your feedback. To contact us or visit our website, see Support Information on page 68. Box Contents Mounting Bracket...
  • Page 6 iCN 530 | User Manual...

  • Page 7: Introduction

    GPS satellites orbit the earth at around 20,200 kilometres (12,000 miles). While a GPS receiver can detect signals from up to 12 satellites at any time, only three signals are needed to provide a position or “GPS fix” (latitude and longitude) for vehicle navigation systems.

  • Page 8: Icn Features

    iCN 530 | User Manual 2. iCN Features We recommend that you familiarise yourself with the iCN’s basic operations, such as using the stylus and Volume control. Front Components Component Touch Screen Charge Indicator Infrared Receiver Fuel Park Menu Page Description Displays maps and menu options.

  • Page 9: Bottom Components

    Bottom Components Component Description Reset Resets the iCN; press using the stylus. Hot Shoe Plate Connection plate for the P1 or T1 mount. Must be set to ON ( | )for normal use. Switching to OFF (O) will turn Battery Switch the battery off, saving battery power.

  • Page 10: Back Components

    iCN 530 | User Manual Back Components Component External Antenna Socket Speaker Top Components Component Power Stylus Description Connection socket for GPS mMCX External Antenna (not included). Protected by rubber cover. Outputs voice commands and warnings. Use the Volume control to adjust.

  • Page 11: Charging The Battery

    Stylus The stylus is your input device. Pull the stylus out of the slot and extend it for ease of use. Store it in the slot when not in use. • Tap the screen with the stylus to select. • Tap and drag the screen with the stylus to navigate the 2D Map and 3D Map screens. Internal Battery The iCN has an internal battery that when fully charged should power the iCN for 4 hours.

  • Page 12: Starting Your Icn

    iCN 530 | User Manual 3. Starting your iCN Before you begin, check if your vehicle is fitted with a heat-reflective or heated windscreen. If so, you will need to purchase an external antenna for your iCN to receive GPS signals. Step One: Position the iCN in your Vehicle Follow the safety notice on page 7 to ensure that the iCN does not obstruct the driver’s view, or interfere with the operation of vehicle airbags and safety devices.

  • Page 13: Main Menu Screen

    Step Four: Warning Screen 1. Read the warning message. 2. To confirm that you have read and understood the message, tap Accept The first Tutorial screen will display. Step Five: Tutorial Screens 1. Read the Tutorial screen. • To prevent the Tutorial from displaying on startup, select the Do not show Tutorial on startup check box.
  • Page 14 iCN 530 | User Manual To Turn your iCN Off When your iCN is off, it enters a suspended state and the system stops operating. When you turn your iCN on, it returns to the screen you were last viewing. 1.

  • Page 15: Setting Your Destination

    4. Setting your Destination For your safety, enter destination information before you start a journey. Do not operate the iCN while driving. Select a destination using the Destination, Keyboard and Preview screens, which used together form a destination wizard. This section describes how to use each of these screens and provides two case studies to help guide you through setting your destination.

  • Page 16: Preview Screen

    iCN 530 | User Manual Figure 3. Number/Symbol Keyboard As you select each character, the first two results will display. Tap • To select a character or a search result, tap the character or search result. • To delete a character, press ESC or tap <<; hold ESC to delete the line. •...

  • Page 17: Address Search Rules

    Address Search Rules The following rules apply when searching for a destination in Europe: Street names with dates or numbers If a street name contains a date or a number, search by the first number: Example 1: If searching for “Faubourg du 13 Juillet 1920”, search by “13”. Example 2: If searching for “Avenue du 14 Avril 1914”, search by “14”.

  • Page 18: By Address

    iCN 530 | User Manual Setting your Destination by Address Step One: Open the Destination screen a. From the Main Menu, tap Go To. b. From the Go To screen, tap Address or POI. The Destination screen will display. Important Note: The first time you are setting your destination, the Select country screen will display instead of the Destination screen.
  • Page 19 b. Use the Keyboard screen to find the area of your destination. For information on using the Keyboard screen, see pages 15-16. The Destination screen will display. Step Four: Find the Street of Destination a. From the Destination screen, tap Find street. The Keyboard screen will display.
  • Page 20 iCN 530 | User Manual Step Five: Find the House Number of Destination a. From the Destination screen, tap Enter house number. The Keyboard screen will display. Note: If the Enter house number option is not displayed, house numbers are not available for your selected street.

  • Page 21: Setting Your Destination By Poi

    Setting your Destination by POI A POI is a named site, feature, landmark or public venue which can be displayed as an icon on the map. POIs are grouped by type, such as parks and museums. Step One: Open the Destination screen a.
  • Page 22 iCN 530 | User Manual c. Use the Keyboard screen to find the POI. For information on using the Keyboard screen, see pages 15-16. The Preview screen will display. d. Complete one of the following: • To calculate the route and open the 3D Map screen, tap Go. The 3D Map screen will display.

  • Page 23: Using The 2D Map Screen To Plan A Route

    5. Using the 2D Map screen to Plan a Route You can plan a route directly from the 2D Map screen using the Pop-up menu. 1. From the Main Menu, tap Map. The 2D Map screen will display. • Move around the 2D Map screen using the stylus. •...

  • Page 24: Multi-Stop Trips

    iCN 530 | User Manual 6. Multi-stop Trips You can use the Multi-stop Trip screen to set multiple destination points for your trip. Your route will be calculated to go via each of these points in the specified order. Destination points can be added via the Multi-stop Trip screen or by selecting Show Details from the pop-up menu on the 2D Map screen, then Add to Trip.
  • Page 25 Step Two: Select the Country of your Destination Point a. If the destination point is in a different country to the previous destination point, tap Change country. The Select country screen will display. b. Select a country from the list. The Destination screen will display.
  • Page 26 iCN 530 | User Manual Step Four: Find the Street of your Destination Point a. From the Destination screen, tap Find street. The Keyboard screen will display. b. Use the Keyboard screen to find the street of your destination point. For information on using the Keyboard screen, see pages 15-16.

  • Page 27: Destination Point

    Step Five: Find the House Number of your Destination Point a. From the Destination screen, tap Enter house number. The Keyboard screen will display. Note: If the Enter house number option is not displayed, house numbers are not available for your selected street. Select Go to centre of street to display the Preview screen. Go to step c.

  • Page 28: Skipping A Destination Point

    iCN 530 | User Manual d. Complete one of the following: Note: Destination points added, updated or deleted after a multi-stop trip has commenced will not affect the current route. If you want to ... add another destination point Note: Destination points added after a multi-stop trip has commenced will not be included in the current route.

  • Page 29: Viewing Your Route

    7. Viewing your Route Once a route has been calculated, you can view it in several ways. Press 2D Map Screen The 2D Map screen is always oriented North and shows your current position (if a GPS fix is active) and surrounding street names.

  • Page 30: D Map Screen

    iCN 530 | User Manual 3D Map Screen The 3D Map screen displays when a route is calculated, oriented to the travelling direction with an adjustable horizon. It is not possible to plan a route directly from this screen. To view the 3D Map screen when a route has been calculated, press •...

  • Page 31: Next Turn Screen

    Next Turn Screen The Next Turn screen displays information that you need for the next turn, the direction of the turn and the distance to the turn. A route must have been calculated for this screen to be able to display. Access to this screen is controlled by the Display preferences screen.

  • Page 32: Route Information Screen

    iCN 530 | User Manual Route Information Screen The Route Information screen provides information about your current route and lets you skip a trip destination point or cancel a route. The screen is only available from the Main Menu when you are navigating a route: Main Menu ...

  • Page 33: The 2D Map Screen Pop-Up Menu

    8. The 2D Map Screen Pop-up Menu The Pop-up menu allows you to access navigational functions from the 2D Map screen. To display the Pop-up menu, complete the following: 1. From the Main Menu, tap Map. The 2D Map screen will display. •...

  • Page 34: Avoiding An Area

    iCN 530 | User Manual 9. Avoiding an Area You can calculate a route that avoids a specified area on the map. For example, you may want to avoid an area that frequently experiences traffic problems. Up to ten Avoid Areas can be added. Avoid Areas are displayed as shaded areas.

  • Page 35: Route Demonstrator

    10. Route Demonstrator The Route Demonstrator allows you to: • Preview a route. • Plan and view a route without a GPS fix, such as when you are inside a building. Step One: Activate Route Demonstrator 1. From the Main Menu screen, tap Preferences. 2.
  • Page 36 iCN 530 | User Manual To Disable Route Demonstrator 1. Press to display the Main Menu screen. 2. From the Main Menu screen, tap Preferences. 3. From the Preferences screen, tap Routing. The Routing screen will display. 4. Press twice. 5.

  • Page 37: Favourites And My Home

    11. Favourites and My Home You can save up to 200 destinations as Favourites, one of which can be saved as My Home. My Home can be any designated Favourite, but we recommend that it is your home or other common destination. You can save a Favourite from the Preview screen after searching for an address, or from the Pop-up Menu on the 2D Map screen.

  • Page 38: Saving A Favourite From The 2D Map Screen

    iCN 530 | User Manual 4. Complete one of the following: • To save as My Home, tap Save as My Home. The Favourite is saved as My Home. The Go To screen will display. • To save as a favourite, tap Save as Favourite. The Favourite is saved.

  • Page 39: Editing The Name Of The Favourite

    6. To change the name of the Favourite, select the Name box. The Enter text screen will display. • To select a character, tap the character. • To delete a character, press ESC or tap <<; hold ESC to delete the line. •...

  • Page 40: Deleting A Favourite

    iCN 530 | User Manual 4. Tap the Name box. The Enter text screen will display. • To select a character, tap the character. • To delete a character, press ESC or tap <<; hold ESC to delete the line. •...

  • Page 41: Navigating To A Favourite

    Navigating to a Favourite 1. From the Main Menu, tap Go To. 2. From the Go To screen, tap Favourites. The Favourite screen will display. 3. Select a Favourite. The Preview Favourite screen will display. 4. Tap Go. The route is calculated and displayed on the 3D Map screen. Navigating to My Home 1.

  • Page 42: Preferences

    iCN 530 | User Manual 12. Preferences You can modify the following preferences to suit your needs. Volume 1. Rotate the Volume Control up or down to hear a sound test. 2. Rotate the Volume Control up or down and hold to display the volume bar. •...
  • Page 43 Route Demonstrator to play repeatedly enable Smart Demonstration to be played enable Track Recording (only to be used if required by Navman Customer Support) 4. Tap Save. The Main Menu screen will display. iCN 530 | User Manual Then...
  • Page 44 iCN 530 | User Manual Map Preferences — Display Settings 1. From the Main Menu, tap Preferences. 2. From the Preferences screen, tap Maps. 3. From the Maps screen, tap Display. The first of two Display screens will display. Press 4.
  • Page 45 If you want to... display topographical information on the 2D Map and 3D Map screens display grid lines on the 2D Map and 3D Map screens display a north-pointing compass on the 2D Map and 3D Map screens display “no entry” icons on “no entry” roads on the 2D Map and 3D Map screens 5.
  • Page 46 iCN 530 | User Manual Alerts Preferences — Active POIs The Active POI settings allow you to set warning chimes and visual warnings for custom POIs that will activate within a chosen radius of your location. For example, a warning chime will sound or a visual warning will display when an active POI is within 150 ft of, but not necessarily on, your route.
  • Page 47 Alerts Preferences - Speed and GPS Signals The Safety settings allow you to set safety-related warnings. 1. From the Preferences menu, tap Safety Alerts. The Safety Alerts screen will display. 2. On the Safety Alerts screen, tap Safety. The Safety screen will display. 3.
  • Page 48 iCN 530 | User Manual My Data Preferences - My Points of Interest (My POI) Custom Points of Interest (POIs) are installed from the Smart Desktop POI Editor (see pages 61- 63), and listed on the My POIs screen. 1. From the Main Menu, tap Preferences. 2.

  • Page 49: Gps Status

    GPS Status Signals are transmitted by Global Positioning System (GPS) satellites orbiting the Earth. The Satellite Signal Strengths screen provides a visual representation of the information being received. Latitude and longitude are displayed, along with a north-pointing compass, the heading in degrees and ground speed.

  • Page 50: Language Preferences

    iCN 530 | User Manual Measurement Preferences 1. From the Main Menu screen, tap Preferences. The Preferences screen will display. 2. From the Preferences screen, tap More Preferences. The second Preferences screen will display. 3. On the second Preferences screen, select Measurements. The Measurements screen will display.
  • Page 51 Hardware Preferences - Screen 1. From the Main Menu screen, tap Preferences. The Preferences screen will display. 2. From the Preferences screen, tap More Preferences. The second Preferences screen will display. 3. On the second Preferences screen, tap Hardware. The Hardware screen will display 4.
  • Page 52 iCN 530 | User Manual Hardware Preferences - Volume 1. From the Main Menu screen, tap Preferences. The Preferences screen will display. 2. From the Preferences screen, tap More Preferences. The second Preferences screen will display. 3. On the second Preferences screen, tap Hardware. The Hardware screen will display.
  • Page 53 Hardware Preferences - Power Status 1. From the Main Menu screen, tap Preferences. The Preferences screen will display. 2. From the Preferences screen, tap More Preferences. The second Preferences screen will display. 3. On the second Preferences screen, tap Hardware. The Hardware screen will display.

  • Page 54: Startup Preferences

    iCN 530 | User Manual 5. Complete the following: If you want to... change the time to elapse before entering suspended state when connected to an external power source change the time to elapse before entering suspended state when using battery power 6.

  • Page 55: Smart Desktop

    13. Smart Desktop Smart Desktop is used to install maps to your iCN, obtain software updates, manage Custom Points of Interest (POIs) and install Basemaps. Microsoft ActiveSync ® Microsoft ActiveSync is used to establish a connection between your iCN and your computer. ActiveSync 3.7.1 will be installed on your computer (if it is not already installed) as part of the installation of Smart...
  • Page 56 You are now ready to install maps to your iCN. To Open Smart Desktop Once Smart Desktop has been installed, you can access it from the Start menu: Start  Programs  Navman  Smart for iCN530 Uninstalling Smart Desktop from your Computer We recommend that you use the Add or Remove Programs feature in your Windows Control Panel: 1.

  • Page 57: Updating Your Icn

    14. Updating your iCN Updating your Version of Smart We recommended that you regularly use Smart Desktop to check the Navman website for Smart software updates: 1. If you connect to the Internet via a dial-up connection, connect to the Internet now.

  • Page 58: Installing Maps Using Smart Desktop

    3. Click the map you want to install to your iCN. Note: You may need to install multiple maps to cover the desired geographical area. 4. You will be prompted to enter or update your contact details so Navman can advise you when updates are released.
  • Page 59 Removing Maps from your iCN 1. Open Smart Desktop: Start  Programs  Navman  Smart for iCN530 2. Open the Maps on iCN section: iCN tab  Maps on iCN. 3. Click the map to be removed and select Remove from iCN from the pop-up menu.

  • Page 60: Smart Desktop Advanced Features

    iCN 530 | User Manual 16. Smart Desktop Advanced Features This section details advanced features of Smart Desktop. If you have not installed Smart Desktop, see pages 55-56. To Find a City or Town 1. From the Map menu, click Find City. The Find City window will open.
  • Page 61 Map Layers To conserve space on your iCN and memory card, you can choose map layers to install. The layers you can choose from are: • Points of Interest (POIs) • Bodies of water and parks • Land contours (topography). To access the Map Layers section: Desktop tab ...
  • Page 62 iCN 530 | User Manual 2. Add a POI to the POI File. • On the POI Editor window Edit menu, click New. The POI Details window will open. • Type a description for the POI in the Description box. •...
  • Page 63 3. Modify the POI settings as required: If you want to... activate the POI enable a visual warning when the POI is in close proximity enable a warning chime when the POI is in close proximity change the units used to measure distance for this POI select the distance from the POI at which the visual warning should...
  • Page 64 iCN 530 | User Manual Backups You can save backups of all iCN Preferences and Favourites to your computer. To Back up your Preferences, Favourites and My Home 1. On the Smart Desktop File menu, click Backup. The Backup window will display. 2.

  • Page 65: Appendix: Street Types

    Appendix: Street Types Note: Belgium and Switzerland each list street types and their abbreviations in three languages. Country Austria Belgium (Dutch) Belgium (French) Belgium (German) Finland France Street Type BOULEVARD CHAUSSEE PLATZ STRASSE BAAN BERG DREEF LAAN MARKT PARK PLEIN SQUARE STEENWEG STRAAT...
  • Page 66 iCN 530 | User Manual Country Germany Ireland Italy Luxembourg Netherlands Street Type BOULEVARD CHAUSSEE PLATZ STRASSE AVENUE BOULEVARD CENTRE CRESCENT PLACE ROAD ROUTE SQUARE STREET YARD CONTRADA CORSO FRAZIONE LARGO PIAZZA PIAZZALE STRADA STATALE SUPERSTRADA VIALE ALLÉE AVENUE BOULEVARD CHAUSSÉE DOMAINE FAUBOURG...
  • Page 67 Country Norway Portugal Spain Switzerland (German) Switzerland (French) Switzerland (Italian) United Kingdom Street Type GATA GATE PLASSEN VEGEN AVENIDA BAIRRO CALÇADA CAMINHO ESTRADA LARGO LARGUINHO PRAÇA QUARTO QUARTA QUINTA SÃO SANTA SANTO AVENIDA CALLE CALLEJÓN CAMINO CARRETERA GLORIETA PASEO PLAZA RAMBLA RONDA BOULEVARD...

  • Page 68: Support Information

    PO Box. 68-155 Newton Auckland New Zealand Support: http://support.navman.com Website: http://www.navman.com NAVMAN DISCLAIM ALL LIABILITY FOR ANY USE OF THIS PRODUCT IN A WAY THAT MAY CAUSE ACCIDENTS, DAMAGE OR VIOLATE THE LAW. Support for Europe: Navman Europe Limited 4G Gatwick House...

  • Page 69: Important Safety Information

    Only use the iCN internal battery with the Navman iCN unit. Failure to adhere to these instructions may lead to death, serious injury, or property damage. Navman disclaims all liability for use of the iCN that causes or contributes to death, injury, or property damage or that violates any law.
  • Page 70 iCN 530 | User Manual...
  • Page 72 MN000550B-G...

This manual is also suitable for:

Icn 530
