2.2.4

Installation in the vehicle

Mounting the
holder...
Installation and quick-start guide
Attention: The mounted holder must not impede the driver's
attention on the traffic. If this is not possible, mount the holder
somewhere else so that safe driving is granted.
1. Attach the cradle of the device to the swan-neck mount.
Notice: Take notice of the inscription on the swan-neck
mount. The arrow with the inscription close must show in
snap-on direction. The connection must snap on audibly.
2. Place the suction cup on the windscreen. Press the lever
firmly to the windscreen before switching it.
3. Insert the device into its holder. First place the bottom of the
device correctly, then push it backwards until it snaps into the
clip.
4. Insert the chinch jack
respective socket at the bottom of the device.
5. Insert the power jack
User's manual BLUE Edition
of the power supply cable into the
into the cigarette lighter.
- 14 -
