Spare Parts Listing - Breville BBL550 Service Manual

Spare Parts Listing
NO CANADA
01 BPBBL55001
02 BPBBL55002
03 BPBBL55003
03DK BPBBL55003DK
03A BPBBL55003A
03D BPBBL55003D
13 BPBBL55013
13A BPBBL55013A
13D BPBBL55013D
14 BPBBL55014
14A BPBBL55014A
14D BPBBL55014D
26 BPBBL55026
27 N/A
27.1 BPBBL50027.1
28 BPBBL55028
29 BPBBL55029
34 BPBBL55034
36 BPBBL55036
37 BPBBL55037
38 BPBBL55038
40 BPBBL55040
43 BPBBL55043
44 BPBBL55044
45 BPBBL55045
46 BPBBL55046
47 BPBBL55047
47.1 BPBBL55047.1
49 BPBBL55049
52 BPBBL55052
53 BPBBL55053
57 BPBBL55057
57C BPBBL55057C
58 BPBBL55058
59 BPBBL55059
63 BPBBL55063
64 BPBBL55064
66 N/A
66.1 N/A
66.2 BPBBL55066.2
67 BPBBL55067
67.1 BPBBL55067.1
68 BPBBL55068
70 BPBBL55070
72 BPBBL55072
90 BPBBL55090
90A BPBBL55090A
90C BPBBL55090C
95 BPBBL55095
3 May 2011
Note: Substitute Items applies CAN/US/AU/NZ
US AU/NZ
BBL550XL/01 BBL550/01
BBL550XL/02 BBL550/02
BBL550XL/03 BBL550/03
BBL550XL/03DK N/A
BBL550XL/03A BBL550/03A
BBL550XL/03D N/A
BBL550XL/13 BBL550/13
BBL550XL/13A BBL550/13A
BBL550XL/13D N/A
BBL550XL/14 BBL550/14
BBL550XL/14A BBL550/14A
BBL550XL/14D N/A
BBL550XL/26 BBL550/26
N/A BBL550/27
BBL550XL/27.1 N/A
BBL550XL/28 BBL550/28
BBL550XL/29 BBL550/29
BBL550XL/34 BBL550/34
BBL550XL/36 BBL550/36
BBL550XL/37 BBL550/37
BBL550XL/38 BBL550/38
BBL550XL/40 BBL550/40
BBL550XL/43 BBL550/43
BBL550XL/44 BBL550/44
BBL550XL/45 BBL550/45
BBL550XL/46 BBL550/46
BBL550XL/47 BBL550/47
BBL550XL/47.1 N/A
BBL550XL/49 BBL550/49
BBL550XL/52 BBL550/52
BBL550XL/53 BBL550/53
BBL550XL/57 BBL550/57
BBL550XL/57C BBL550/57C
BBL550XL/58 BBL550/58
BBL550XL/59 BBL550/59
BBL550XL/63 BBL550/63
BBL550XL/64 BBL550/64
N/A BBL550/66
N/A BBL550/66.1
BBL550XL/66.2 N/A
BBL550XL/67 BBL550/67
BBL550XL/67.1 BBL550/67.1
BBL550XL/68 BBL550/68
BBL550XL/70 BBL550/70
BBL550XL/72 BBL550/72
BBL550XL/90 BBL550/90
BBL550XL/90A BBL550/90A
BBL550XL/90C BBL550/90C
BBL550XL/95 BBL550/95
DESCRIPTION
INNER LID ‐ MEASURE CUP
OUTER LID ‐ WITH RING PULL
GLASS JUG KIT INCL SEAL & BLADE
GLASS JUG KIT INCL SEAL & BLADE
GLASS JUG ASSY WITHOUT BLADES
GLASS JUG ASSY WITHOUT BLADES
SEAL RING FOR BLADE ASSY
SEAL RING FOR BLADE ASSY
SEAL RING FOR BLADE ASSY
BLADE ASSY
BLADE ASSY – SCREW TYPE
BLADE ASSY – WITH TWO TABS
NUT COVER
DRIVE COUPLING INCL NUT+COVER
DRIVE COUPLING INCL NUT+COVER‐ NORTH
AMERICAN ONLY
UPPER HOUSING
MICROSWITCH
DRAIN GUIDE
HOUSING WRAP ‐ BRUSHED S STEEL
CONTROL PANEL LABEL
MIDDLE HOUSING ‐ BLACK
BOTTOM HOUSING‐BRUSHED SS WRAP
CONTROL PANEL FRAME
PULSE BUTTON
SPEED BUTTONS
POWER STOP BUTTON
PCB ASSEMBLY
CURRENT FUSE
PCB HOLDER
MOTOR FRAME
RUBBER CUSHION
MOTOR ASSEMBLY
MOTOR ASSEMBLY – WITH MOTOR PROTECTION
COOLING CHAMBER FOR MOTOR
EMC BOARD
REAR MOTOR MOUNTING PLATE
BASE
RUBBER FEET ‐ RIGHT FRONT
RUBBER FEET ‐ LEFT FRONT
RUBBER FEET FRONT – 1 PIECE
RUBBER FEET‐ RIGHT REAR
RUBBER FEET ‐ LEFT REAT
COOLING FAN
FAN COVER
POWER CORD
INSTRUCTION BOOK
INSTRUCTION BOOK
INSTRUCTION BOOK – NEW VERS
BLENDER SPANNER
SUBS. ITEM
BBL600/01
BBL600/05
BBL600/06
BBL600/06CK
BBL600/06A
BBL600/06C
BBL600/13
BBL600/13A
BBL600/13C
BBL600/14
BBL600/14A
BBL600/14C
BBL550/27
BBL550/27.1
BBL600/35
BBL600/46
BBL600/55
BBL600/58
BBL600/64
BBL600/66
BBL600/59
BBL800/85
800BLXL/85
