- Page 1 Z-710 Instruction Manual SAVE THIS MANUAL- KEEP IT HANDY FOR QUICK REFERENCE READ INSTRUCTIONS BEFORE USING...
-
Page 3: Table Of Contents
TABLE OF CONTENTS • Important Safety Instructions..................4 • Z-710 Manual Juicer Part Description.................5 • Z-710 Assembly and Operation...................6 • Disassembling the Z-710................... 7 • Cleaning the Z-710....................7 • Troubleshooting......................8 • When You Need Service....................9 • Warranty........................10 • Product Specification....................1 2... -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS 1. Please read all instructions carefully. 2. Avoid contact with its moving parts while the Z-Star 710 is in operation. 3. Close supervision is necessary when any appliances are used by or near children. 4. Use only included accessories. Do not put any articles such as spoons, forks or knives into the Feeding Chute. -
Page 5: Z-710 Manual Juicer Part Description
Z-710 MANUAL JUICER PART DESCRIPTION 1. Screen Locking Cap 10. Juice Container 2. Juicing Screen 11. Table Clamp 3. Auger 12. Fettuccini Nozzle 4. Auger Housing/Feeding Chute 13. Spagetti Nozzle 5. Funnel 14. Juicing Nozzle 6. Auger Housing Retaining Ring 15. -
Page 6: Z-710 Assembly And Operation
Z-710 MANUAL JUICER ASSEMBLY AND OPERATION 1. Place the base of the Z-710 at the edge of a counter or table top. 2. Fit the teeth of the Table Clamp into the groove in the Base of the Z-710. Secure the juicer to the counter or table top by tightening the screw. -
Page 7: Disassembling The Z-710
DISASSEMBLING THE Z-710 MANUAL JUICER 1. Separate the Screen Locking Cap and Nozzle from the unit by turning clockwise. 2. Pull to remove the assembled Screen. 3. Turn the Auger Housing Retaining Ring counter-clockwise to separate it from the base. 4. -
Page 8: Troubleshooting
TROUBLESHOOTING SOLUTION SYMPTOM Loud Noise • Make sure the Z-710 is on a level flat surface. • Materials may need to be cut into smaller Difficulty feeding foods into the lengthwise pieces. machine Auger Housing does not fit onto • Check to see if there are any foreign materials inside. the base •... -
Page 9: When You Need Service
TEL: 714-879-7150, TOLL FREE: 888-254-7336, FAX: 714-879-7140 EMAIL: service@tribest.com WEBSITE: www.tribest.com • Call to obtain a Return Authorization Number to send your Z-Star Z-710 or part back to the service center. Explain the problem you are experiencing. • Pack your Z-710 or part securely in its original shipping box. Make sure all necessary parts are enclosed. -
Page 10: Warranty
WARRANTY We warrant to you, the end-user customer who has properly registered after purchasing the Z-Star ® Z-710 Juice Extractor for a valuable consideration, that the plastic juicing parts and metal clamp parts will be free from defects in materials and workmanship for a period of 1 year from the date of purchase. - Page 11 WE MAKE NO OTHER EXPRESS OR IMPLIED WARRANTY OR CONDITION WHETHER WRITTEN OR ORAL TO THE EXTENT ALLOWED BY LOCAL LAW, ANY IMPLIED WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE OR IMPLIED WARRANTY OR CONDITION OF MERCHANTABILITY IS LIMITED TO ONE (1) YEAR. In the event that such limitation or exclusion on the duration of an implied warranty is not allowed in the state or county wherein you reside, the above limitation or exclusion will not apply.
-
Page 12: Product Specification
13.2in (335mm) x 12.6in (320mm) x 4.9in (125mm) WEIGHT 6.8lbs (3.1kg) © 2013 Tribest Corp. No copies, transmission, or translation into other languages of this manual by any means without written permission of Tribest Corp. is allowed. All rights are reserved. - Page 13 NOTES...
- Page 14 NOTES...
- Page 15 NOTES...
- Page 16 Tribest Corporation P.O. Box 4089, Cerritos, CA 90703 toll free: 888-254-7336 | fax: 714-879-7140 www.tribest.com | service@tribest.com ©2013 Tribest Corporation v.20130501...
