remote key & key blade

key blade

Used to lock/unlock the glove compartment or
the driver's door if the vehicle has no electrical
current.
Insert the key blade to mechanically open the
trunk.

cold start

note
after cold starts, your engine will idle at a
higher speed for a short time.

turn sIgnals

lane-change sequence, three flashes.
A
Full turn sequence.
B
locks the doors, trunk, cabin storage
compartments, ski hatch, and arms
the alarm. If the car is locked with the
remote key while the power retractable
hard top is down, the double locking
feature activates after approximately
30 seconds. The doors can then not be
opened from inside the car.
Unlocks the doors, trunk, cabin storage
compartments, ski hatch, and disarms
the alarm
.
a
Unlocks (but does not open ) the trunk.
approach lighting illuminates lights in
door mirrors, cabin, footwells, license
plates. Turn signals and parking lights
illuminate.
"Panic" alarm.
– Press and hold to sound the alarm.
Turn off alarm with unlock button.
automatic relock occurs if no door/trunk is opened within 2
a.
minutes after unlock.
autostart
depress the clutch and/or brake pedal. Turn
the key/keyless drive start control to posi-
tion III and release it. The engine will start
automatically.

steerIng wheel adjustment

warnIng
Never adjust the steering wheel while
driving.

Advertisement

Table of Contents
loading

Related Manuals for Volvo 2010 c70

Summary of Contents for Volvo 2010 c70

  • Page 1: Turn Signals

    remote key & key blade locks the doors, trunk, cabin storage compartments, ski hatch, and arms the alarm. If the car is locked with the remote key while the power retractable hard top is down, the double locking feature activates after approximately 30 seconds.

  • Page 2: Storage Spaces/12-Volt Socket/Aux/Usb Connector

    lIghtIng panel automatic headlights. High beam flash only. Parking lights. Headlights: turn off when ignition is switched off, high/low beams. display & instrument panel lighting. Front fog lights. Rear fog light (driver’s side only). High beam flash. Toggle between high/low beams, home safe lighting.

  • Page 3: Audio System

    audIo system RadIo Turn to select a radio station. Search for the next strong station. Search for stations with left/right arrows. Store up to 20 stations by pressing and holding one of the preset buttons 0–9 in Fm1 and 0–9 in Fm2, until the stored sta- tion is confirmed in the display.

  • Page 4: Wipers And Rain Sensor

    electronIc clImate control (ecc)* aUToMaTIC CoNTRol MaNUal CoNTRol In auto mode, eCC controls all functions blower speed. automatically and makes driving more pleasant defroster to quickly defog on the wind- with optimal air quality. shield and side windows. Press auto to maintain automatic cabin Recirculation temperature, balanced airflow and other settings.

  • Page 5: Trip Computer And Odometer

    trIp computer and odometer low fuel level indicator When the symbol illuminates, refuel as soon as possible. Fuel gauge. The fuel filler door is on the right, as indi- cated by the arrow. Information display (trip computer infor- mation, messages, clock and ambient Press to display or erase a message.

  • Page 6: Operating The Power Retractable Hard Top

    operatIng the power retract- trunk dIvIder able hard top 6.5 ft 2.0 m 8 in 0.2 m The trunk divider limits the amount of cargo in the trunk to leave space for the power retractable hard top. PRePaRaTIoN Raise the divider when loading the trunk. There should be no objects on the parcel Close the divider completely (3) before shelf, roof, or trunk lid.

  • Page 7: Entering The Rear Seat

    adjustIng the Front seat enterIng the rear seat MaNUal SeaT moving the seat forward Remove the seat belt from the guide (a). Pull up the handle (b) and fold the backrest forward until it locks in position. Move the seat forward (C). moving the seat rearward Move the seat rearward until it reaches the desired position (d).

  • Page 8: Quick Guide

    C70 quick guide welcome to the global FamIly oF volvo owners! Getting to know your new vehicle is an exciting experience. This Quick Guide provides a brief overview of the most common features and functions in your Volvo. However, for the most up-to-date and detailed descriptions and instructions, as well as important warnings and other information not included in this folder, please refer to your owner’s Manual.
