Access Your Gateway - SAGEMCOM F@ST 4350eAC Quick Installation Manual

4.

Access your gateway

LAN connection
To connect your PC using the LAN network, follow these steps:
1. Make sure that the Ethernet LAN cable is connected between any Yellow port on the gateway and the LAN
port of the PC.
2. When the connection is made, go to the section GATEWAY SUPERVISION, page 8.
Wi-Fi connection
Connection with WPS
Note
If your device do not have Wi-Fi (WPS), please use the connection without WPS
method.
To connect your PC using the Wi-Fi wireless network (WPS), follow these steps:
1. Set the PC to WPS association mode, refer to the PC user manual.
2. Set gateway to WPS association mode by pressing the WPS
3. When the pairing is made, go to the section GATEWAY SUPERVISION, page 8.
Connection without WPS
Important
Before you continue installing your gateway, you must first configure your
computer's wireless manager.
1. Launch your computer's wireless manager.
2. Launch a network search to detect the wireless networks.
3. Select the wireless gateway's network in the list and enter the encryption key (WPA).
Note
The name of the network (SSID) and the encryption key are marked on the label of
the gateway.
1. Once you have filled in the Wi-Fi parameters, validate to continue.
2. When the pairing is made, go to the section GATEWAY SUPERVISION, page 8.
Access your gateway user interface
The gateway configuration page allows you to view, configure and customize the gateway's settings.
1. Once the connection is established (LAN or Wi-Fi) to the gateway, you can access the embedded website.
2. Open a web browser and enter the address: http://192.168.0.1. or http://myrouter.
You can access to the gateway's parameters.
3. To modify parameters, you need enter the username (default admin) and password (refer to the sticker at the
bottom on the gateway), then click on Login.
button on the front panel.
- 7 -
F@ST 4350eAC
