Napoleon BGD42P Installation And Operation Instructions Manual
Vented gas fireplace heater
Hide thumbs
Also See for BGD42P:
- Installation and operating instructions manual (100 pages) ,
- Installation and operation instructions manual (28 pages) ,
- Installation and operating instructions manual (52 pages)
Table of Contents
Advertisement
Quick Links
INSTALLER: THESE INSTRUCTIONS MUST BE CONVEYED TO AND REMAIN WITH THE HOMEOWNER.
CERTIFIED UNDER CANADIAN AND AMERICAN NATIONAL STANDARDS, CSA 2.33, ANSI Z21.88 FOR VENTED GAS FIREPLACE HEATERS
DIRECT VENT MILLIVOLT SYSTEM
CERTIFIED FOR CANADA AND UNITED STATES USING ANSI / CSA METHODS
WARNING: If the information in these instructions is not followed exactly, a fire or
explosion may result causing property damage, personal injury or death.
Do not store or use gasoline or other flammable vapours and liquids in the vicinity
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your build-
ing.
Installation and service must be performed by a qualified installer, service agency
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON L4M 4Y8 Canada • (705)721-1212 • fax(705)722-6031
INSTALLATION AND OPERATION INSTRUCTIONS FOR
VENTED GAS FIREPLACE HEATER
NATURAL GAS MODEL
PROPANE GAS MODEL
FOR YOUR SAFETY
of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
or the gas supplier.
www.napoleonfireplaces.com • ask@napoleon.on.ca
BGD42N
BGD42P
• Immediately call your gas supplier from
a neighbour's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier,
call the fire department.
1
W415-0381 / E / 02.09.06
