CERTIFIED UNDER CANADIAN AND AMERICAN NATIONAL STANDARDS, CSA 2.22, AND ANSI Z21.50 RESPECTIVELY FOR VENTED GAS FIREPLACES.
INSTALLATION AND OPERATION INSTRUCTIONS FOR
WARNING: If the information in these instructions is not followed exactly, a fire or
explosion may result causing property damage, personal injury or death.
Do not store or use gasoline or other flammable vapours and liquids in the vicinity of
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your building.
Installation and service must be performed by a qualified installer, service
GAS - INSERTS
GAS-FIRED VENTED FIREPLACE
NATURAL GAS MODEL
PROPANE GAS MODEL
CERTIFIED FOR CANADA AND UNITED STATES USING ANSI / CSA METHODS
FOR YOUR SAFETY
this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
• Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier,
call the fire department.
agency or the gas supplier.
GI 3600 - N
GI 3600 - P
1
W415-0061 / B / 01.11.05

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GI 3600-N and is the answer not in the manual?

Questions and answers

bob lloyd
May 11, 2025

ON MY napoleon gas fireplaces THE FLAME KEEPS GOING OUT AFER A FEW SECONDS AFTER I TURN IT ON

0
1 comments:
Mr. Anderson
May 20, 2025

Possible causes for the flame going out after a few seconds on a Napoleon GI 3600-N gas fireplace include:

- The pilot flame is not large enough or not engulfing the thermopile.
- The thermopile connection is dirty or shorting.
- The thermopile or valve is faulty.
- The remote wall switch wire is too long or has too much resistance.
- The thermostat or switch is faulty.
- The vent is blocked, re-circulating, or disconnected.
- The gas line is not purged properly.
- The propane tank is empty.
- The pilot flame needs adjustment or the pilot head needs repositioning.

This answer is automatically generated

0

Related Manuals for Napoleon GI 3600-N

Summary of Contents for Napoleon GI 3600-N

  • Page 1 CERTIFIED UNDER CANADIAN AND AMERICAN NATIONAL STANDARDS, CSA 2.22, AND ANSI Z21.50 RESPECTIVELY FOR VENTED GAS FIREPLACES. INSTALLATION AND OPERATION INSTRUCTIONS FOR GAS-FIRED VENTED FIREPLACE NATURAL GAS MODEL PROPANE GAS MODEL CERTIFIED FOR CANADA AND UNITED STATES USING ANSI / CSA METHODS WARNING: If the information in these instructions is not followed exactly, a fire or explosion may result causing property damage, personal injury or death.
