INSTALLER: THESE INSTRUCTIONS MUST BE CONVEYED TO AND REMAIN WITH THE HOMEOWNER.
CERTIFIED UNDER CANADIAN AND AMERICAN NATIONAL STANDARDS, CSA 2.33, ANSI Z21.88 FOR VENTED GAS FIREPLACE HEATERS
INSTALLATION AND OPERATION INSTRUCTIONS FOR
GAS-ZERO CLEARANCE WHEN INSTALLED WITH GI-700 KIT (FLUSH FRONT & LOUVRES)
WITHOUT GI-700 KIT INSTALL RECESSED INTO A WOODBURNING NON-COMBUSTIBLE FIREPLACE
WARNING: If the information in these instructions is not followed exactly, a fire or
explosion may result causing property damage, personal injury or death.
Do not store or use gasoline or other flammable vapours and liquids in the vicinity
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your building.
Installation and service must be performed by a qualified installer, service
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON L4M 4Y8 Canada • (705)721-1212 • fax(705)722-6031
GAS INSERT
GAS-FIRED VENTED ROOM HEATER
NATURAL GAS MODEL
PROPANE GAS MODEL
CERTIFICATION LABEL AFFIXED TO UNDERSIDE OF FRESH AIR DAMPER
FOR YOUR SAFETY
of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
agency or the gas supplier.
www.napoleonfireplaces.com • ask@napoleon.on.ca
GI3016-N
GI3016-P
• Immediately call your gas supplier from
a neighbor's phone. Follow the gas sup-
plier's instructions.
• If you cannot reach your gas supplier,
call the fire department.
1
W415-0171 / D / 01.06.04
Advertisement
Table of Contents
Related Manuals for Napoleon GI3016-P
Summary of Contents for Napoleon GI3016-P
-
Page 1: For Your Safety
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON L4M 4Y8 Canada • (705)721-1212 • fax(705)722-6031 www.napoleonfireplaces.com • ask@napoleon.on.ca GAS INSERT GI3016-N GI3016-P FOR YOUR SAFETY • Immediately call your gas supplier from a neighbor's phone. Follow the gas sup- plier's instructions. -
Page 2: Table Of Contents
PG 2-5 INTRODUCTION Warranty General Instructions Mantle Clearance General Information Care of Glass, Enamelled & Plated Parts INSTALLATION Gas Installation Spill Switch Venting Action Check FINISHING Brick Panel Installation Log Placement/Charcoal Embers Glass, Flashing Kit, Logo Placement, Louvre, Inset & Bay Kit Installation PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE •... -
Page 3: Warranty
NAPOLEON gas fireplaces are manufactured under the strict Standard of the world recognized ISO 9001 : 2000 Quality Assurance Certificate. NAPOLEON products are designed with superior components and materials, assembled by trained craftsmen who take great pride in their work. The burner and valve assembly are leak and test-fired at a quality test station. -
Page 4: General Instructions
GENERAL INSTRUCTIONS Installation practices vary from region to region and it is important to know the specifics that apply to your area, for example: in Massachusetts State: • The fireplace damper must be removed or welded in the open position prior to installation of a fireplace insert or gas log. •... -
Page 5: Installation
CARE OF GLASS, ENAMELLED AND PLATED PARTS Do not use abrasive cleaners to clean these parts. Buff lightly with a clean dry cloth. Porcelain enamelled compo- nents must be handled with care. The baked-on finish is glasslike. If struck, it will chip! Touch-up paint is available through your Napoleon dealer. -
Page 6: Spill Switch
SPILL SWITCH This is a thermally activated switch, attached to the back of the unit and extending up into the dilution draft hood, which senses the change in temperature and shuts down the gas valve in the event of a severe downdraft of air or a blocked or disconnected vent. - Page 7 PHAZER logs and charcoal embers, exclusive to Napo- leon Fireplaces, provide a unique and realistic glowing effect that is different in every installation. Take the time to carefully position the charcoal embers for a maximum glow- ing effect. 1. Place the front log onto the main burner, pushing it as close as possible to the burner ports without blocking/covering them.
- Page 8 FLUSH GLASS FRONT KIT, GI-FF Attach the lower glass bracket. Seat the glass inside the bracket and using two screws attach the upper glass bracket, as shown. FLASHING SURROUND KITS, GI-900 / GI-909 Assemble the flashing and mount to the inside of the outer shell using 4 securing screws (supplied with the louvre kit).
- Page 9 ORNAMENTAL FLUSH INSETS, GI-OI Assemble the flashing and mount to the inside of the outer shell using 4 securing screws and spacers (supplied) as shown. Hook the ornamental inlays over the spacers. FIGURES 15 LOWER UPPER BAY GLASS FRONT, GI-BF With the bay chassis on a flat surface, insert the front glass (bottom first)
-
Page 10: Operation / Maintenance
OPERATION / MAINTENANCE OPERATING INSTRUCTIONS When lit for the first time, the stove will emit a slight odour for a few hours. This is a normal temporary condition caused by the curing of the logs and the "burn-in" of inter- nal paints and lubricants used in the manufacturing proc- ess and will not occur again. -
Page 11: Maintenance
TURN OFF THE GAS AND ELECTRICAL POWER BEFORE SERVICING THE FIREPLACE. CAUTION: Label all wires prior to disconnection when serv- icing controls. Wiring errors can cause improper and dan- gerous operation. Verify proper operation after servicing. This insert and its venting system should be inspected before use and at least annually by a qualified service per- son. -
Page 12: Replacements
Contact your dealer for questions concerning prices and availability of replacement parts. Normally all parts can be ordered through your Napoleon dealer or distributor. REPLACEMENT PARTS # PART NO.DESCRIPTION GZ-551 REPLACEMENT BLOWER W725-0036 NATURAL GAS VALVE C/W ADJUSTABLE REGULATOR W725-0037 PROPANE GAS VALVE C/W ADJUSTABLE REGULATOR W455-0004 #36 DMS NATURAL GAS BURNER ORIFICE... - Page 13 W415-0171 / D / 01.06.04...
-
Page 14: Trouble Shooting Guide
TROUBLE SHOOTING GUIDE EFORE ATTEMPTING TO TROUBLESHOOT SYMPTOM PROBLEM Pilot goes out when the A - System is not correctly gas knob is released. purged. B - Out of propane gas. C - Pilot flame is not large enough D - Pilot flame is not engulfing the thermopile. - Page 15 SYMPTOM PROBLEM Main burner goes out; A - Refer to "Main burner goes out; pilot stays on" pilot goes out. B - Chimney down-drafting C - Chimney is blocked D - Liner disconnected from in- sert. E - Faulty spill switch. Carbon is being de- Air shutter has become blocked posited on glass, logs...
- Page 16 Wolf Steel Fireplace Service History This fireplace must be serviced annually depending on usage. Service Technician Date Dealer Name Service Performed Special Concerns Name...
