Page 1: Installation Manual
INSTALLATION MANUAL WATER SOFTENER SYSTEMS MODELS SYNC-TECH 1.50, SYNC-TECH 2.00, SYNC-TECH 3.00, SYNC-TECH 4.00 Water Doctors Water Co. a Division of HMI Water Specialists 8201 Old Central Ave. NE Minneapolis, MN 55432 Office 952-928-3737 Fax 763-535-1805 www.waterdrs.com... -
Page 2: Table Of Contents
Water Softener Table of Contents IMPORTANT SAFETY INFORMATION – READ ALL ..................3 INSTRUCTIONS BEFORE USING .......................... 3 SOFTENER ANATOMY ............................4 SPECIFICATIONS ..............................5 ................................5 EEDWATER ..................................5 OWER ................................5 NSTALLATION & E ..........................5 APACITY FFICIENCY SETUP .................................. -
Page 3: Important Safety Information - Read All
Use only lead-free solder and flux for sweat-solder connections, as required by state and federal codes. Handle all components of the Water Doctors system with care. Do not drop, drag or turn components upside down. Be sure the floor under the water softening system is clean and level. -
Page 4: Softener Anatomy
Water Softener Softener Anatomy Figure 1 1…………… Valve 2…………… Bypass 3…………… Resin Tank 4…………… Distributor 5…………… Resin Not Shown Brine Valve Assembly 7…………… Brine Tank Lid 8…………… Brine Tank 9…………… Faceplate/Controls Page 4 of 18... -
Page 5: Specifications
The Efficiency was determined in accordance with NSF/ANSI 44 This unit conforms to ANSI/NSF-44 for specific performance claims as verified and substantiated by test data. Refer to NSF Compliance Data Water Doctors Insert for further information. Contact for additional copies. -
Page 6: Setup
Always connect the Water Doctors system to the main water supply pipe before the water heater. Install the Water Doctors system where it will not be subject to temperatures outside of the limits stated in the Specification section or to direct sunlight. -
Page 7: Installation
Water Softener Installation 1. Turn off gas or electric supply to the water heater. 2. Turn off the water supply to pipes to be cut and drain the house water pipes. 3. Open both hot and cold faucets. 4. Move the softener assembly into installation position. ... - Page 8 Water Softener 8. Connect and route the valve drain hose. Use the provided drain hose to attach to the valve drain fitting. To keep water pressure from blowing the hose off, use a hose clamp to secure. 9. Locate the other end of the hose at a suitable drain. ...
- Page 9 Use Step 10 to install rigid drain pipe. 10. To adapt a rigid drain pipe to the Water Doctors system, do not attach barbed hose fitting to valve. Instead, plumb rigid tubing directly to the 1/2" male NPT drain fitting.
- Page 10 Water Softener NOTE: If water appears cloudy or has salty taste, allow it to run for several more minutes, or until clear. 17. Close all water faucets. 18. Check plumbing work for leaks and fix immediately if any are found. 19.
-
Page 11: Control Start-Up Procedures
- maximum flow during regeneration -3.5 gpm Control Service Manual - Model 9000/9100 Service Manual For replacement copies of these manuals please contact Water Doctors. Softener Operation As water enters the softener, it passes over a resin bed in a special tank. The resin consists of tiny beads of a plastic called styrene. -
Page 12: Service
The Water Doctors system is designed to remove minerals like calcium and magnesium from household water. Water Doctors recommends periodic resin bed cleaning if your iron rating is high. Clean the bed at least every six months, or more if iron appears in the soft water between cleanings. -
Page 13: Troubleshooting
Water Softener Troubleshooting 1. Softener Fails To Regenerate. A. Electrical service to unit has been A. Assure permanent electrical service (check fuse, interrupted. plug, pull chain or switch). B. Timer programming bad (improper B. Check programming and reset as needed. programming). - Page 14 Salt may be bridged. If using a salt grid plate ensure refill water is over it. C. Resin fouling. Future fouling. C. Call Water Doctors , find out how to confirm it, clean the resin and prevent. D. Poor distribution, channeling D.
-
Page 15: Water Softener System Parts List
Water Softener Water Softener System Parts List Figure 5 Page 15 of 18... - Page 16 Water Softener Item No. Part No. Description CH32842 Brine Tank CH15013-2 4" Brine Well 60795-00 Distributor Assembly 60002-3460014 Air Check/Brine Valve Assembly CH16371-60 Brine Line Tube 10329 Fitting, Tube, .375 Nut, Brass 10330 Fitting, Sleeve, .375, Delrin 10332 Fitting, Insert, .375 Varies by supplier Resin: Purolite C100E General Technologies C108DQ –Na, Indion 225 NaF...
-
Page 17: And Csa-B483.1
Water Softener Tested and Certified by the WQA to NSF/ANSI Standard 44 & 372 for softener performance & lead free compliance and CSA-B483.1 Page 17 of 18... - Page 18 P/N 40999 Rev D 11/7/13...
