Page 1: Installation Manual
INSTALLATION MANUAL WATER SOFTENER SYSTEMS MODELS AQUA-LOGIC 0.75, AQUA-LOGIC 1.00, AQUA-LOGIC 1.50, AQUA-LOGIC 2.00 Water Doctors Water Co. a Division of HMI Water Specialists 8201 Old Central Ave. NE Minneapolis, MN 55432 Office 952-928-3737 Fax 763-535-1805 www.waterdrs.com... -
Page 2: Table Of Contents
Water Softener Table of Contents IMPORTANT SAFETY INFORMATION – READ ALL ..................3 INSTRUCTIONS BEFORE USING .......................... 3 SOFTENER ANATOMY ............................4 SPECIFICATIONS ..............................5 ................................5 EEDWATER ..................................5 OWER ................................5 NSTALLATION & E ..........................5 APACITY FFICIENCY SETUP .................................. -
Page 3: Important Safety Information - Read All
Use only lead-free solder and flux for sweat-solder connections, as required by state and federal codes. Handle all components of the WATER DOCTORS system with care. Do not drop, drag or turn components upside down. Be sure the floor under the water softening system is clean and level. -
Page 4: Softener Anatomy
Water Softener Softener Anatomy Figure 1 1…………… Valve 2…………… Bypass 3…………… Resin Tank 4…………… Distributor 5…………… Resin 6…………… Salt/Brine Tank Lid 7…………… Salt/BrineTank 8…………… Faceplate/Controls Not Shown Brine Valve Assembly Page 4 of 18... -
Page 5: Specifications
The Efficiency was determined in accordance with NSF/ANSI 44 This unit conforms to NSF/ANSI-44 for specific performance claims as verified and substantiated by test data. Refer to NSF Compliance Data Insert for further information. Contact for additional copies. WATER DOCTORS Page 5 of 18... -
Page 6: Setup
Always connect the WATER DOCTORS system to the main water supply pipe before the water heater. Install the WATER DOCTORS system where it will not be subject to temperatures outside of the limits stated in the Specification section or to direct sunlight. -
Page 7: Installation
Water Softener Installation 1. Turn off gas or electric supply to the water heater. 2. Turn off the water supply to pipes to be cut and drain the house water pipes. 3. Open both hot and cold faucets. 4. Move the softener assembly into installation position. ... - Page 8 Water Softener 8. Connect and route the valve drain hose. Use the provided drain hose to attach to the valve drain fitting. To keep water pressure from blowing the hose off, use a hose clamp to secure. 9. Locate the other end of the hose at a suitable drain. ...
- Page 9 Use Step 10 to install rigid drain pipe. 10. To adapt a rigid drain pipe to the WATER DOCTORS system, do not attach barbed hose fitting to valve. Instead, plumb rigid tubing directly to the 1/2" male NPT drain fitting.
- Page 10 Water Softener 20. Turn ON the gas or electric supply to the water heater. 21. Remove the brine tank cover and add salt into the tank. Use pellet or coarse solar salt with a purity of 99.5% or higher. DO NOT use granular, and ice cream-making salts, or salt with iron removing additives. Keep the cabinet cover closed unless servicing or refilling with salt.
-
Page 11: Control Start-Up Procedures
– rated drain flow during regeneration – 3.5 gpm Control Service Manual: 5800 LXT/SXT Downflow Brining Service Manual For replacement copies of this manual please contact WATER DOCTORS. Softener Operation As water enters the softener, it passes over a resin bed in a special tank. The resin consists of tiny beads of a plastic called styrene. -
Page 12: Service
The WATER DOCTORS system is designed to remove minerals like calcium and magnesium from household water. WATER DOCTORS recommends periodic resin bed cleaning if your iron rating is high. Clean the bed at least every six months, or more if iron appears in the soft water between cleanings. -
Page 13: Troubleshooting
Water Softener Troubleshooting 1. Softener Fails To Regenerate. A. Electrical service to unit has been A. Assure permanent electrical service (check fuse, interrupted. plug, pull chain or switch). B. Timer programming bad (improper B. Check programming and reset as needed. programming). - Page 14 B. Brine concentration and/or quantity. B. Keep brine tank full of salt at all times. Clean it yearly. Salt may be bridged. If using a salt grid plate ensure refill water is over it. C. Resin fouling. Future fouling. WATER DOCTORS C. Call , find out how to confirm it, clean the resin and prevent.
-
Page 15: Water Softener System Parts List
Water Softener Water Softener System Parts List Figure 5 Page 15 of 18... - Page 16 Water Softener Item No. Part No. Description CH19211-1 Brine Tank CH15013-2 4" Brine Well Varies by size Tank w/ base 60795-00 Distributor Assembly 60014/60002-34 2310 Safety Brine Valve Assembly/Air Check CH16371-60 3/8” Brine Line Tube 10329 Fitting, Tube, .375 Nut, Brass 10330 3/8”...
- Page 17 Water Softener add warranty Tested and Certified by the WQA against NSF/ANSI Standard 44 & 372 & CSA B483.1 Page 17 of 18...
- Page 18 BR43398 Rev B 1/06/14...
