Page 1: User Manual
BODY FAT SCALE BODY WATER, BMI (BODY MASS INDEX) WITH DAILY CALORIE REQUIREMENT MODEL #D410 USER MANUAL... -
Page 2: Table Of Contents
Table of Contents INTRODUCTION .........................2 NOTES ON SAFETY ......................2 INTENDED USE ........................3 PRECAUTION NOTICE .......................3 IMPORTANT NOTICE TO USERS ..................3 PRODUCT DESCRIPTION ....................4 FRONT VIEW......................4 LCD DISPLAY ......................5 FUNCTION KEYS ....................5 BACK VIEW ......................5 ITEMS INCLUDED IN THE PACKAGE ..............6 PREPARATION BEFORE USE .....................6 OPERATION ........................8 CLOCK AND TEMPERATURE SETTING ..............8... -
Page 3: Notes On Safety
INSTRUCTION MANUAL The DETECTO body fat scale is designed and manufactured in a facility certified ISO 9001 Quality, ISO 14001 Environment, OHSAS 18001 Health and Safety Management Systems and ISO 13485 Medical Devices Quality Management System. The scale uses the method of Bioelectrical Impedance Analysis (BIA) to estimate body fat, total body water, bone mass and muscle mass. -
Page 4: Intended Use
INTENDED USE This scale is intended to measure body weight and impedance and estimate percentage of body fat and body water, muscal mass using BIA (Bioelectrical Impedance Analysis). It is intended for use by healthy children 10-17years old and healthy adults with active, moderately active, to inactive lifestyles for body composition assessment in the home environment. -
Page 5: Function Keys
1. Normal Mode 2. Athlete Mode 3. Male Icon 4. Female Icon 5. Body Mass Index 6. Body Fat % 7. Total Body Water % 8. Daily Calorie Battery Compartment FUNCTION KEYS BACK VIEW & (Scale Unit) • Change value of Height, Age and toggle between Male and Female;... -
Page 6: Preparation Before Use
PREPARATION BEFORE USE 1. Insert the Battery TIPS Open the battery cover on the back of the scale unit.Insert 3 pieces AAA alkaline batteries (not included). 1. Replace batteries in the scale unit, Open the battery cover on the back of the wireless remote display when Lo is unit. -
Page 7: Operation
1. Fix the Wall Mounting Bracket a. Drill two holes on the wall with the distance in between two holes is 58mm (Fig.1) Make sure the height of the holes is between 140cm and 180cm from floor (Fig.2). Hole on the wall 58mm Wall plug M3 x 25 screw... -
Page 8: Clock And Temperature Setting
CLOCK AND TEMPERATURE SETTING 1.12 / 24 Hour Format and Fahrenheit/Celsius Selection In Clock Mode, press [ ] key to toggle between different hour (Fig.3) and temperature format (Fig.3) 2. TIME SETTING a. Press and hold [ ] button for 2 seconds to enter time setting mode, the hour digits will blink (Fig.4). -
Page 9: Body Fat And Total Body Water Estimating Operation
BODY FAT AND TOTAL BODY WATER ESTIMATING OPERATION WITH USER MEMORY A few steps must be followed before estimating body fat and total body water. PROGRAM PERSONAL DATA Input the user’s height, age, gender and normal or athlete mode. Once the information is memorized, it will only need to be reentered if there is a change to the data. - Page 10 6. Measuring Step on the scale with bare feet and stand still while the weight is being measured. Then the screen displays the weight for 2 seconds (Fig.13). (Fig.13) 7. Stay on the scale during the whole computation process. Then the scale starts to compute your body composition. The screen displays the measurement pattern while computing (Fig.14).
-
Page 11: Problem Solving
PROBLEM SOLVING AND QUESTIONS 1. No weight is displayed? Check if the scale is powered up and started up. If not, please refer to the section “Preparation Before Use”. 2. Why does the display read “Lo” or “bAtt”? Battery is running low. When “Lo” displays, replace batteries in scale unit;... -
Page 12: Product Specifications
PRODUCT SPECIFICATIONS 1. High precision STRAIN GAUGE technology for weight measurement 2. Bioelectrical Impedance Analysis (BIA) technology for body fat and body waterpercentage, bone and muscle mass estimations 3. Provides Daily Calorie Requirement (DCR) and BMI information 4. Wireless infrared remote display unit with clock and temperature feature 5. - Page 13 Standard for Men (Source: University of Illinois Medical Center, Chicago, USA) Rating 20-29 30-39 40-49 50-59 <13 <14 <16 <17 <18 Optimal 14-20 15-21 17-23 18-24 19-25 Moderate 21-23 22-24 24-26 25-27 26-28 High > 23 >24 >26 >27 >28 Standard for Women (Source: University of Illinois Medical Center, Chicago, USA) Rating...
- Page 14 The estimated %TBW may vary according to your hydration level, that is, how much water you have drunk or how much you have sweated immediately prior to the estimation. For better accuracy, avoid fluctuation in hydration level prior to the estimation. The accuracy of the scale in estimating TBW will also decrease with individuals suffering from diseases that tend to accumulate water in the body.
- Page 15 9. What's Calorie Predictor? The Calorie Predictor function estimates the number of calories required based on your body composition and user entered personal data. This tool can be used as a guide when setting daily calorie goals during weight loss and exercise programs. 10.
- Page 16 This product is designed for personal use only. DETECTO, a division of Lava Lite LLC reserves the right to nullify the Warranty Agreement should the product be used in a commercial environment. This warranty is void if the product has been tampered with, misused, abused or modified.
