- Page 1 Installation Manual LCD-9151-201-x 15.1" Flat Panel LCD Monitor Document # 540334 a DeCrane Aircraft Company 7300 Industry Drive, North Little Rock, AR 72117 Phone: 501-955-2929 Fax: 501-955-2988 www.audiointl.com...
-
Page 2: Reference Documents
18-20 PROPRIETARY NOTICE: Despite any other copyright notice, this document and information disclosed herein contains confidential, proprietary designs owned by Audio International, Inc. Neither this document nor the data contained herein shall be reproduced, used, or disclosed to anyone without the written authorization of Audio International, Inc. -
Page 3: Table Of Contents
Audio International, Inc. LCD-9151-201-x Installation Manual Table of Contents Section Description Page General Information ……………………………………………. Introduction ……………………………………………………….. Purpose of the Equipment ………………………………………. Optional Equipment ……………. .………………………………. Application ……………………………………………………….. Installation ……………………………………………………….. Prior to Installation ……………………………………………….. Unpacking and Inspection ………………………………………. Cautions & Warnings …………………………………………….. -
Page 4: General Information
Purpose of the Equipment Audio International’s LCD-9151-201-x is a 15.1" flat panel LCD monitor with Composite NTSC, PAL, and SECAM video, PC Graphic capabilities, and Serial Digital interface capabilities. It provides a 1024 x 768 (XGA) resolution display. -
Page 5: Application
Audio International, Inc. LCD-9151-201-x Installation Manual Application Introduction The LCD-9151-201-x is a flat panel LCD monitor with Composite video, PC Graphic capabilities, and Serial Digital interface capabilities. If any one of these formats is applied to their respective inputs, the monitor will display that format. -
Page 6: Installation
Audio International, Inc. LCD-9151-201-x Installation Manual SP-LCD6 is an external switch utilized for monitor set-up. The switch, which must be ordered separately, provides configuration control via AI’s proprietary RS-485 digital data bus communication or may be configured directly to the P2 connector. - Page 7 Audio International, Inc. LCD-9151-201-x Installation Manual 3.1.3 If the adjustment switch (SP-LCD6) is to be mounted in the aircraft, the following should be considered; the pigtail is 24 inches (60.96 cm) in length ±1 inch (2.54 cm) and has 6-32 x 0.75 inch mounting studs.
-
Page 8: Unpacking And Inspection
3.2.2 If damage has occurred during shipping, a claim should be filed with Audio International WITHIN 24 hours and a Return Request Authorization Number shall be obtained from AI by contacting the Repair Department at 501.801.0640. -
Page 9: Wiring Requirements
(6) inches between the lines. 3.4.2 Power Wires Audio International recommends that the chassis be electrically bonded to the airframe structure by a conductive mounting point with <0.1 Ω resistance using <50 Ω impedance cable. Aluminum... -
Page 10: Electrical Characteristics
Audio International, Inc. LCD-9151-201-x Installation Manual 3.4.4 RS-485 Connections RS-485 connections shall be twisted shielded cable with the shield properly grounded at the source (ideal practice) and floating at the load end. If shield cannot be grounded at the source, then ground at the load end with the source end floating. - Page 11 Audio International, Inc. LCD-9151-201-x Installation Manual 3.5.2 Electrical Specifications, SP-LCD6: Electrical 80 mA at +28 VDC, Power maximum Switch Backlighting Green Mounting Studs 6-32 x 0.75 inches long 3.5.3 The LCD-9151-201-x utilizes three (3) connectors. P1 is a 13-pin connector that provides power input, ground, video input, monitor on/off control and monitor status.
-
Page 12: Mating Connector Information
Audio International, Inc. LCD-9151-201-x Installation Manual 3.5.6 The SP-LCD6 utilizes one (1) 9-pin connector that mates with P2 of the LCD-9151-201-x. This connector provides +28 VDC power input, ground, data bus connections, and data bus configuration ID connections. Mating Connector Information All wiring harnesses to the unit shall be supplied and fabricated by the installing agency. -
Page 13: Pinout Assignment Descriptions
Audio International, Inc. LCD-9151-201-x Installation Manual Pinout Assignment Descriptions 3.7.1 Pinout assignment for the LCD-9151-201-x is as follows: Pin # Description +28VDC Power Input Ground Reserved Monitor Status Gnd Output Monitor On/Off Gnd Input SE Video Enable SE Video Common... -
Page 14: Sp-Lcd6 Configuration Overview
SP-LCD6 Configuration Overview Configuration is typically accomplished via an SP-LCD6 attached to the D-Subminiature connector on the monitor. Audio International reserves the right to add, delete, or alter functions from the setup menus without advance notification to the user. To access the Main Menu, press the “MENU 1”... -
Page 15: Instructions For Continued Airworthiness
Audio International, Inc. LCD-9151-201-x Installation Manual A typical Monitor Setup Menu consists of the following modes: 1. “OSD TIMEOUT”- Timeout period until monitor defaults out of menu mode. 2. “BACKLIGHT”- Backlighting intensity. 3. “FACTORY PRESET”- All modes may be reset to the default factory setting. Select either “YES”... -
Page 16: Cleaning Method
Use a twin pack cleaning system that employs a wet pad pre-moistened with an Isopropyl Alcohol based cleaner/anti-static solution and a lint-free drying cloth. Audio International, Inc. recommends using “Kleen & Dry” RR1205 manufactured by READ RIGHT, Nanuet, NY 10954. -
Page 17: General Troubleshooting Procedures
Audio International, Inc. LCD-9151-201-x Installation Manual General Troubleshooting Procedures • Verify power to the unit by rechecking +28 VDC power is applied to the proper pins on the unit. Use a voltmeter to verify correct level. • Remove power from the unit for at least one (1) minute and reapply power. -
Page 18: Specifications
Audio International, Inc. LCD-9151-201-x Installation Manual Specifications Unit Specifications for LCD-9151-201-x: Physical Specifications – LCD-9151-201-x Screen Size 15.1 (38.4 cm) diagonal Weight Approx. 5.86 lb / 2.66 kg Dimensions 13.31" x 1.50" x 10.21" (l x w x h) 33.81 cm x 3.81 cm x 25.93 cm Unit Specifications for SP-LCD6: Physical Specifications –... -
Page 19: Reference Drawings
Audio International, Inc. LCD-9151-201-x Installation Manual Reference Drawings LCD-9151-201-x The following diagrams show the unit dimensions, mounting locations, and connector locations for the LCD-9151-201-x. Document # 540334, Rev IR1, 10/2006 Page 18 of 20... - Page 20 Audio International, Inc. LCD-9151-201-x Installation Manual Document # 540334, Rev IR1, 10/2006 Page 19 of 20...
-
Page 21: Sp-Lcd6
Audio International, Inc. LCD-9151-201-x Installation Manual External Menu Switch The following diagrams show the unit dimensions and connector locations for the external menu selection switch, SP-LCD6. Document # 540334, Rev IR1, 10/2006 Page 20 of 20...
