Audio international AI-LCD68-01-xx Installation And Operation Manual

Ai-lcd68-01 series 6.8" lcd monitor w/arm

Advertisement

Quick Links

Installation and Operation

Manual
AI-LCD68-01-xx
6.8" LCD Monitor w/Arm
Document # 540300
a DeCrane Aircraft Company
7300 Industry Drive, North Little Rock, AR 72117
Phone: 501-955-2929 Fax: 501-955-2988
www.audiointl.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AI-LCD68-01-xx and is the answer not in the manual?

Questions and answers

Summary of Contents for Audio international AI-LCD68-01-xx

  • Page 1: Installation And Operation

    Installation and Operation Manual AI-LCD68-01-xx 6.8" LCD Monitor w/Arm Document # 540300 a DeCrane Aircraft Company 7300 Industry Drive, North Little Rock, AR 72117 Phone: 501-955-2929 Fax: 501-955-2988 www.audiointl.com...
  • Page 2: Reference Documents

    AI-LCD68-01-13 Reference Drawing PROPRIETARY NOTICE: Despite any other copyright notice, this document and information disclosed herein contains confidential, proprietary designs owned by Audio International, Inc. Neither this document nor the data contained herein shall be reproduced, used, or disclosed to anyone without the written authorization of Audio International, Inc.
  • Page 3: Table Of Contents

    Audio International, Inc. AI-LCD68-01-xx Installation and Operation Manual Table of Contents Section Description Page General Information ……………………………………………. Introduction ……………………………………………………….. Purpose of the Equipment ………………………………………. Operation Features………………………………………………. Optional Equipment ……………. .…………………………….. Application ……………………………………………………….. Installation ……………………………………………………….. Prior to Installation ……………………………………………….. Unpacking and Inspection ……………………………………….
  • Page 4: General Information

    This manual contains information for the proper installation of the Audio International, Inc. (AI) 6.8" LCD Monitor with Arm Assembly, Model No: AI-LCD68-01-xx. The “-xx” suffix in the model number designates the type of connector utilized by the plug-in arm; “-02” utilizes the Cannon MS3126F12-10P connector and “-13”...
  • Page 5: Optional Equipment

    • Utilizes a versatile arm mount to give user maximum viewing options • Easy to mount and connect Optional Equipment Audio International, Inc. offers a comprehensive family of source equipment and cabin speaker systems. These modules can provide excellent additions for any cabin environment.
  • Page 6: Installation

    Some of the items to be considered include: 3.1.1 The AI-LCD68-01-xx shall be installed to conform to the standards designated by the customer, installing agency, and existing conditions as to the unit location and type of installation.
  • Page 7: Cautions & Warnings

    Cautions and Warnings 3.3.1 It is important to do a pin-to-pin power and ground check on all connectors. Audio International recommends using an Electrical Meter set to read Ohms or an Audible Continuity Tester to confirm that the pins are connected via wiring. Ensure that power and ground are applied only where specified.
  • Page 8: Electrical Characteristics

    Use of individual wires rather than proper coaxial cable connections through production breaks is unacceptable, and will cause significant and detrimental noise introduction to the video signal supplied to the AI-LCD68-01-xx. Electrical Characteristics 3.5.1 Electrical Specifications, AI-LCD68-01-xx:...
  • Page 9: Physical Characteristics

    Audio International, Inc. AI-LCD68-01-xx Installation and Operation Manual 3.5.2 Power protection via internal thermal fuses and thermal current limiting. 3.5.3 Video inputs cannot be paralleled to two (2) monitors. Call AI Systems Engineering Department for video installation assistance. Physical Characteristics 3.6.1 Monitor utilizes plug-in shaft with key-way for “one-way alignment”...
  • Page 10: Pinout Assignment Descriptions

    Audio International, Inc. AI-LCD68-01-xx Installation and Operation Manual Pinout Assignment Descriptions 3.8.1 Pinout assignment for the AI-LCD68-01-02 base (AI-BSE65-04-x) is as follows: Pin # Description POWER GROUND RESERVED +28VDC POWER INPUT RESERVED RESERVED RESERVED VIDEO - VIDEO + RESERVED RESERVED 3.8.2 Pinout assignment for the AI-LCD68-01-13 base (AI-BSE65-02-x )
  • Page 11: Operation

    Audio International, Inc. AI-LCD68-01-xx Installation and Operation Manual Operation Arm Mobility The arm assembly possesses three (3) axis points of articulation as shown below. Note the tension adjust positions for the rotation axes as well as the Release Button used when tilting monitor forward or backward (70˚...
  • Page 12: Troubleshooting Guide

    5.1.3 Ensure video can be seen on monitor. Cleaning Method AI-LCD68-01-xx should be cleaned at least once every three (3) months or when excessive dust or dirt becomes apparent. Use a twin pack cleaning system that employs a wet pad pre-moistened with an Isopropyl Alcohol based cleaner/anti-static solution and a lint-free drying cloth.
  • Page 13: General Troubleshooting Procedures

    Instructions for Continued Airworthiness No periodic scheduled maintenance or calibration is required for continued airworthiness of the AI-LCD68-01-xx, 6.8" Monitor Plug In. If the unit fails to perform to specifications, it must be removed and serviced by a qualified service facility.
  • Page 14: Specifications

    Audio International, Inc. AI-LCD68-01-xx Installation and Operation Manual Specifications Unit Specifications for AI-LCD68-01-xx: Physical Specifications – AI-LCD68-01-xx Screen Size 6.8" (56 cm) Diagonal Monitor Dimensions 7.0" x 1.4" x 6.1" (l x w x h) 17.8 cm x 3.56 cm x 15.5 cm...
  • Page 15: Reference Drawings

    Audio International, Inc. AI-LCD68-01-xx Installation and Operation Manual Reference Drawings AI-LCD68-01-02 The following diagrams show the unit dimensions and connector locations for the AI-LCD68-01-02. "Monitor Face" labels indicate side with viewing screen. Document # 540260, Rev IR, 11/2004 Page 14 of 15...
  • Page 16: Ai-Lcd68-01-13

    Audio International, Inc. AI-LCD68-01-xx Installation and Operation Manual AI-LCD68-01-13 The following diagrams show the unit dimensions and connector locations for the AI-LCD68-01-13. Document # 540260, Rev IR, 11/2004 Page 15 of 15...

This manual is also suitable for:

Ai-lcd68-01-02Ai-lcd68-01-13
