ENGLISH
Congratulations on the purchase of your Conceptronic 4-ports Broadband Router.
The enclosed Hardware Installation Guide gives you a step-by-step explanation of how to install the
Conceptronic C100BRS4H.
When problems occur, we advise you to go to our support-site (go to
'Support' Here you will find the Frequently Asked Questions Database.
When you have other questions about your product and you cannot find it at our webiste, then contact us by e-
mail:
support@conceptronic.net
For more information about Conceptronic products, please visit the Conceptronic Web Site:
www.conceptronic.net
1. Introduction
We thank you for the purchase of the Conceptronic C100BRS4H. With the C100BRS4H you can sue one Internet connection
with several Computers at one time. With the C100BRS4H you will expand your new network or existing network with a 4
ports switch, router and firewall.
Please read this manual for hardware installation and configuring your device.
1.1 Overview of the most important characteristics
•
Sharing the Internet with several PC's
•
4 network ports (10/100 Mbps)
•
Firewall to protect your network
•
The Conceptronic C100BRS4 can be easily installed through your web browser without the need of installing extra
software.
•
Support for all major Operating Systems and Networks
•
Support for DHCP server / client. Easy and user friendly configuration
1.2 Specifications
Support for:
•
Static & Dynamic IP, PPPoE, PPtP (most of the time used for ADSL and Cable Modem connections)
•
VPN (Virtual Private Network) PPPtP client, Ipsec & PPtP passthrough
•
DHCP Server/Client
•
NAT firewall protection (there will be no direct internet access to your local computers)
•
Address Mapping and Virtual Servers (Route Internet traffic to special servers or computers)
•
IP Packet Access Control
•
Hacker Attack Protection
•
Monitoring functions for DHCP client logging. Security Log and see the connection status of the device
1.3 Minimum System Requirements
One wireless system you want to connect wireless to your wired network.
Web Browser (Microsoft Explorer® or Netscape® or Mozilla® etc.)
TCP/IP is necessary for using and configuring the Conceptronic C100BRS4H broadband router
1.4 Package Contents
C100BRS4H broadband router
AC/DC 12V – 500mA
RJ-45 Network Cable (Cat5e)
CD-ROM (Manual)
Hardware Installation Guide
Conceptronic C100BRS4H
Quick Installation Guide
1
www.conceptronic.net
and click
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Conceptronic C100BRS4H
Summary of Contents for Conceptronic C100BRS4H
-
Page 1: Quick Installation Guide
We thank you for the purchase of the Conceptronic C100BRS4H. With the C100BRS4H you can sue one Internet connection with several Computers at one time. With the C100BRS4H you will expand your new network or existing network with a 4 ports switch, router and firewall. -
Page 2: Explanation Of Controls
8 - 1 WAN port (RJ-45) 9 - Reset Button With the delivered RJ-45 Network cable you can connect your ADSL or Cable modem to your Conceptronic C100BRS4H Reset button The reset button is meant to restore all settings to factory defaults. -
Page 3: Installation
ENGLISH Factory reset or Restart might be helpful to get the C100BRS4H broadband router back to function normally. Warning If you upgrade firmware into the broadband router do not try to Factory reset, Software reset or power off the device. - Page 4 ENGLISH If your computer is using an own IP address, please write down the settings before changing these. If your computer is configured to use DHCP do not modify anything. When you are creating a new network, you can use 192.168.2.x as IP range for your network. All computers in your network will get automatically the correct IP.
-
Page 5: Quick Setup
ENGLISH Select the section (Quick Setup Wizard, General Setup, Status Information and Tools) you wish to configure and proceed to the corresponding chapter. Use the selections on the web management’s top right hand page to navigate around the web- based management User Interface. 2.2 Quick Setup The Quick Setup section is designed to get you using the broadband router as quick as possible. - Page 6 ENGLISH Step 1) Time Zone The Time Zone allows your router to base its time on the settings configured here, this will affect functions such as Log entries and Firewall settings. Parameter Description Set Time Zone Select the time zone of the country you are currently in. The router will set its time based on your selection.
-
Page 7: Step 2) Broadband Type
ENGLISH Step 2) Broadband Type In this section you have to select one of four types of connections that you will be using to connect your broadband router’s WAN port to your ISP (see screen below). Note: Different ISP’s require different methods of connecting to the Internet, please check with your ISP as to the type of connection it requires. -
Page 8: Cable Modem
ENGLISH Cable Modem Choose Cable Modem if the ISP will automatically give you an IP address. Some ISP’s may also require that you fill in additional information such as Host Name and MAC address (see screen below). Note: The Host Name and MAC address section is optional and you can skip this section if your ISP does not require these settings for you to connect to the Internet. -
Page 9: Parameters & Description
ENGLISH Fixed-IP xDSL Select Fixed-IP xDSL if your ISP has given you a specific IP address for you to use. Your ISP should provide all the information required in this section. Parameters & Description This is the IP address that your ISP has given you. Gateway IP This is the ISP’s IP address gateway this is the ISP’s DNS server IP address... - Page 10 ENGLISH PPPoE Select PPPoE if your ISP requires the PPPoE protocol to connect you to the Internet. Your ISP should provide all the information required in this section. Parameter Description User Name Enter the User Name provided by your ISP for the PPPoE connection Password Enter the Password provided by your ISP for the PPPoE connection Service Name...
- Page 11 ENGLISH Idle Time You can specify an idle time threshold (minutes) for the WAN port. This means if no packets have been sent (no one using the Internet) during this specified period, the router will automatically disconnect the connection with your ISP. Note: This “idle timeout”...
- Page 12 ENGLISH Parameter Description Obtain an IP address The ISP requires you to obtain an IP address by DHCP automatically before connecting to the PPTP server. Use the following IP address The ISP give you a static IP to be used to connect to the PPTP server. IP Address This is the IP address that your ISP has given you to establish a PPTP connection.
