Check Your Package Contents

Installing the DKVM-2K
Make sure that all your computers are turned OFF before installing the DKVM-
2K to avoid mouse and keyboard errors when booting up your computers.
A. Attach your monitor's
VGA connector to the
console port of the
DKVM-2K.
The following steps below apply to both the computers that you are using with your DKVM-2K.
D. Attach the DKVM-2K's
monitor cable to the
VGA port located on
the back of your
computer case.
Quick Installation Guide
DKVM-2K
2-Port PS/2 KVM Switch
B. Attach your PS/2
keyboard connector
to the DKVM-2K
keyboard port.
E. Attach the DKVM-2K's
keyboard cable to the
PS/2 keyboard port
located on the back of
your computer case.
DKVM-2K PS/2 KVM switch
with attached cables
1
C. Attach your PS/2
mouse connector to
the DKVM-2K mouse
port.
F. Attach the DKVM-2K's
mouse cable to the
PS/2 mouse port
located on the back of
your computer case.
