  • Page 1 EV3151 & EV3151A Box IP Camera Installation Guide – Version 6.2...

  • Page 2: About This Guide

    Information contained in this document may be superseded by updates. No representation or warranty is given and no liability is assumed by Etrovision Technology with respect to the accuracy or use of the information, or infringement of patents or other intellectual property rights.

  • Page 3: Table Of Contents

    Video Server Outer View ................5 1.10 Physical Connections .................. 5 EV3151 ....................... 5 EV3151A ..................... 6 USING THE EV3151 FOR THE FIRST TIME ........7 Initial Requirements..................7 Software Requirements................7 Install EtroScan™ ..................7 Physical IP Camera Connections ..............8 Connect to the Network................
  • Page 4 Missing root Password ................21 CAMERA LED INDICATORS ............23 ADDITIONAL INFORMATION ............24...

  • Page 5: Product Overview

    1 PRODUCT OVERVIEW 1.1 Introduction This manual covers the EV3151 and EV3151A models. For simplicity, “EV3151” will be used to refer to both models unless there is a need to differentiate between the two models. 1.2 Product Specifications EV3151 Model...

  • Page 6: Ev3151A

    Microsoft Internet Explorer 6.0, or Above Web Browser Password Protection Security 0 ºC ~ 40 ºC (32 ºF ~ 104 ºF) Temperature Operating Environment 20% ~ 80% RH Humidity Power Adapter, USB Cable, Mini-Din Cable, CD-ROM Supplied Accessories (User Manual, Free Bundle NVR) EV3151A Model EV3151A...

  • Page 7: Ev3151 & Ev3151A Differences

    0 ºC ~ 40 ºC (32 ºF ~ 104 ºF) Temperature Operating Environment 20% ~ 80% RH Humidity Power Adapter, USB Cable,Mini-Din Cable Supplied Accessories CD-ROM (User Manual, Free Bundle NVR) 1.3 EV3151 & EV3151A Differences Features EV3151 EV3151A Video In Audio I/O Digital I/O Wireless USB Port 1.4 Dual Streaming Capabilities...

  • Page 8: Resolution

    176x120 720x576 352x288 176x144 1.6 Package Checklist The EV3151 packaging will include the following materials.  EV3151/EV3151A Video Server x 1  Power Adapter x 1  USB Cable x 1  Mini DIN Cable x 1  Product CD x 1 1.7 Product CD...

  • Page 9: Video Server Outer View

    1.9 Video Server Outer View 1.10 Physical Connections EV3151 1. 12V DC Power Input 2. RJ-45 Network Cable Port 3. EtroLink™ USB Config Port 4. BNC Video In 5. RS-485 PTZ Port 6. Power LED...

  • Page 10: Ev3151A

    EV3151A 1. Audio I/O 2. BNC Video In 3. mini DIN port 4. Power LED 5. EtroLink™ USB Config Port 6. WiFi USB Port 7. RJ-45 Network Cable Port 8. 12V DC Input...

  • Page 11: Using The Ev3151 For The First Time

    CD that accompanies the EV3151. Please refer to the EtroStation™ documentation for installation instructions. Download from Etrovision’s Website EtroScan™ can also be downloaded from Etrovision’s website. It is available in the Software Tools section of the Download area, http://www.etrovision.com/Download_list.aspx?no=5. After downloading the archived file, extract the contents and run Setup.exe to...

  • Page 12: Physical Ip Camera Connections

    IP camera. Connect CCTV to Video Server Use the BNC Video In port to connect the camera with the EV3151. Connect PTZ (EV3151 Only) For PTZ functionality, connect the PTZ device to the EV3151 RS-485 PTZ port.

  • Page 13: Factory Ip Address

    Factory IP Address Below are the initial factory IP address settings for the IP camera: IP Address 192.168.1.2 Subnet Mask 255.255.255.0 Gateway 192.168.1.1 Using EtroScan™ EtroScan™ allows users to easily find an IP camera and configure the settings. Select EtroScan™ from the start menu to start.
  • Page 14 Press the Scan button to list the IP and MAC address list for IP cameras on the network. A new IP camera will display the factory IP address, 192.168.1.2. However, if multiple new devices are present on the network, then multiple instances of 192.168.1.2 will be listed.

  • Page 15: Change Network Setting Via Etroscan

    To identify a specific IP camera, use the MAC address which is located on the bottom of the camera. Below is an example of the label displaying the MAC address. Change Network Setting via EtroScan™ There are two ways to modify the network settings. 1.

  • Page 16: Access The Ip Camera Web Interface

    After altering the IP camera network settings, click Apply. A prompt for the administrator authentication will be displayed: The default password for the administrator account (root) is pass. Enter the default password and click OK to confirm the changes. After applying the new network settings, the IP camera will reboot; this process takes about 45 seconds.
  • Page 17 Press OK button to access to the Live View web page. Usernames and passwords are case sensitive. The administrator password should be changed after installation is complete. Please refer to the User Manual for more information. Upon login, the error “ActiveX control failed to load (OCX)” may be encountered. The error indicates the browser requires adding certain ActiveX controls for the viewer to work.
  • Page 18 Clicking on the add-on message will bring up options; choose Run Add-on to add. A confirmation message box will be displayed; choose Run. Wait for the add-on to complete and the page to attempt reloading. Most likely other ActiveX controls will be required. Repeat the above procedure of adding ActiveX controls until the no other add-on requests are displayed and the Live View page loads without error.

  • Page 19: Etrolink™ Configuration Port

    3 ETROLINK™ CONFIGURATION PORT The EtroLink™ USB Configuration Port provides an alternate method of configuration. The EtroLink™ USB Configuration allows configuration using a Quick Config Wizard which requires no software installation. 3.1 OS Requirements The PC which will access the IP camera using the EtroLink™ USB port requires the following to run the EtroLink™...

  • Page 20: Quick Config Login

    The Quick Config login screen will be displayed. Quick Config Login Unless the password has already been modified, use the default administrator login is: root Password: pass NOTE: restoring factory settings will restore default login password. Click the Login button; the Status page will then be available.

  • Page 21: Quick Wizard - Network

    Quick Wizard - Network The Quick Wizard button is used to configure network and DDNS settings. Clicking Quick Wizard will display Step 1. Step 1 The network configuration options include “Static IP”, “DHCP”, and “PPPoE”. Select an option and click Next. Step 2 Selecting “Static IP”...
  • Page 22 Selecting “DHCP” and Next: Selecting “PPPoE” and Next: Enter all the relevant network settings, and click Next. Step 3 Regardless of network connection type, step 3 and 4 are the same.

  • Page 23: Manually Starting The Quick Config Wizard

    1. Connect the IP camera and PC using the mini USB cable. 2. Wait a moment for the PC to recognize the IP camera as a new drive. 3. Using Windows Explorer, find the IP camera represented as a new drive. The Etrovision logo should help identify the specific drive.

  • Page 24: Factory Default

    4. Highlight the drive (i.e. E:) to view he contents. 5. Find the “ClickMeFirst” HTML file, and double click. The Quick Config utility will be initiated using Internet Explorer. 3.3 Factory Default The factory default settings can be restored using the Quick Config Wizard. Restoring factory settings will result in the loss of the current IP camera’s configuration.
  • Page 25 3.4 Missing root Password If the root password has been forgotten, then factory settings will need to be restored using the EtroLink™ USB port. At the Quick Config login screen, use CTRL+ALT+F to restore factory settings. Type CTRL+ALT+F: Click OK Click OK The following message shows that the operation is complete.
  • Page 26 Click OK The video server/camera will now be configured with the default 192.168.1.2 IP address, and the default username/password of root/pass. Use EtroScan or the Web UI to manually reconfigure the device, or a backup configuration can be restored if available.

  • Page 27: Camera Led Indicators

    4 CAMERA LED INDICATORS The IP camera back (or combo cable if an outdoor or dome camera) has 3 LED indicators which display the camera state or activities.  Red: the power LED  Green: network connection LED  Orange: network transmission LED The table below highlights various camera states and corresponding Power LED indicators.

  • Page 28: Additional Information

    5 ADDITIONAL INFORMATION For more information on the EV3151 and EV3151AVideo Server, please see the firmware User’s Manual. These manuals are available on the product CD, or they can be downloaded from the Etrovision website, www.etrovision.com. In addition, the latest firmware releases and other product documentation are...
