Page 1: G Wireless Router
Multi-Function 802.11g Wireless Router 802.11g/802.11b Wireless Access Point Broadband Internet Access 4-Port Switching Hub User's Guide... -
Page 2: Table Of Contents
Table of Contents CHAPTER 1 INTRODUCTION ..................... 1 Wireless Router Features ....................1 Package Contents ......................3 Physical Details........................4 CHAPTER 2 INSTALLATION....................6 Requirements........................6 Procedure ........................... 6 CHAPTER 3 SETUP ........................ 8 Overview ..........................8 Configuration Program ....................9 Setup Wizard ........................ - Page 3 APPENDIX A TROUBLESHOOTING ................78 Overview .......................... 78 General Problems ......................78 Internet Access......................... 78 Wireless Access ........................ 79 APPENDIX B ABOUT WIRELESS LANS................80 Modes ..........................80 BSS/ESS..........................80 Channels........................... 81 WEP..........................81 Wireless LAN Configuration..................81 APPENDIX C SPECIFICATIONS ..................82 Multi-Function Wireless Router ..................
-
Page 4: Chapter 1 Introduction
Chapter 1 Introduction This Chapter provides an overview of the Wireless Router's features and ca- pabilities. Congratulations on the purchase of your new Wireless Router. The Wireless Router is a multi- function device providing the following services: • Shared Broadband Internet Access for all LAN users. -
Page 5: Advanced Internet Functions
Wireless Router User Guide Advanced Internet Functions • Communication Applications. Support for Internet communication applications, such as interactive Games, Telephony, and Conferencing applications, which are often difficult to use when behind a Firewall, is included. • Special Internet Applications. Applications which use non-standard connections or port numbers are normally blocked by the Firewall. -
Page 6: Package Contents
Introduction • Configuration File Upload/Download. Save (download) the configuration data from the Wireless Router to your PC, and restore (upload) a previously-saved configuration file to the Wireless Router. • Remote Management. The Wireless Router can be managed from any PC on your LAN. -
Page 7: Physical Details
Wireless Router User Guide Physical Details Front-mounted LEDs Figure 2: Front Panel Power LED On - Power on. Off - No power. Status (Red) On - Error condition. Off - Normal operation. Blinking - This LED blinks during start up, and during a Firmware Up- grade. -
Page 8: Rear Panel
Introduction Rear Panel Figure 3: Rear Panel Connect the supplied power adapter here. Power port 10/100BaseT Use standard LAN cables (RJ45 connectors) to connect your PCs to LAN connections these ports. If required, any port can be connected to another hub. Any LAN port will automatically function as an "Uplink"... -
Page 9: Chapter 2 Installation
Chapter 2 Installation This Chapter covers the physical installation of the Wireless Router. Requirements • Network cables. Use standard 10/100BaseT network (UTP) cables with RJ45 connectors. • TCP/IP protocol must be installed on all PCs. • For Internet Access, an Internet Access account with an ISP, and either of a DSL or Cable modem (for WAN port usage) •... -
Page 10: Check The Leds
Installation For best Wireless reception and performance, the Wireless Router should be positioned in a central location with mini- mum obstructions between the Wireless Router and the PCs. Also, if using multiple Access Points, adjacent Access Points should use different Channels. 2. -
Page 11: Chapter 3 Setup
Chapter 3 Setup This Chapter provides Setup details of the Wireless Router. Overview This chapter describes the setup procedure for: • Internet Access • LAN configuration • Wireless setup • Assigning a Password to protect the configuration data. PCs on your local LAN may also require configuration. For details, see Chapter 4 - PC Con- figuration. -
Page 12: Configuration Program
Setup Configuration Program The Wireless Router contains an HTTP server. This enables you to connect to it, and configure it, using your Web Browser. Your Browser must support JavaScript. The configuration program has been tested on the following browsers: • Netscape V4.08 or later •... - Page 13 Wireless Router User Guide If you can't connect If the Wireless Router does not respond, check the following: • The Wireless Router is properly installed, LAN connection is OK, and it is powered ON. You can test the connection by using the "Ping" command: •...
-
Page 14: Setup Wizard
Setup Setup Wizard The first time you connect to the Wireless Router, the Setup Wizard will run automatically. (The Setup Wizard will also run if the Wireless Router's default setting are restored.) 1. Step through the Wizard until finished. • You need to know the type of Internet connection service used by your ISP. - Page 15 Wireless Router User Guide • PPTP PPTP is mainly used in Server IP Address. Europe. • User name and password. You connect to the ISP only • IP Address allocated to when required. The IP address you, if Static (Fixed). is usually allocated automati- cally, but may be Static (Fixed).
-
Page 16: Home Screen
Setup Home Screen After finishing the Setup Wizard, you will see the Home screen. When you connect in future, you will see this screen when you connect. An example screen is shown below. Figure 5: Home Screen Navigation & Data Input •... -
Page 17: Lan Screen
Wireless Router User Guide LAN Screen Use the LAN link on the main menu to reach the LAN screen An example screen is shown below. Figure 6: LAN Screen Data - LAN Screen TCP/IP IP Address IP address for the Wireless Router, as seen from the local LAN. Use the default value unless the address is already in use or your LAN is using a different IP address range. -
Page 18: What Dhcp Does
Setup DHCP What DHCP Does A DHCP (Dynamic Host Configuration Protocol) Server allocates a valid IP address to a DHCP Client (PC or device) upon request. • The client request is made when the client device starts up (boots). • The DHCP Server provides the Gateway and DNS addresses to the client, as well as allocating an IP Address. -
Page 19: Wireless Screen
Wireless Router User Guide Wireless Screen The Wireless Router's settings must match the other Wireless stations. Note that the Wireless Router will automatically accept both 802.11b and 802.11g connections, and no configuration is required for this feature. To change the Wireless Router's default settings for the Wireless Access Point feature, use the Wireless link on the main menu to reach the Wireless screen. -
Page 20: Access Point
Setup Options Mode Select the desired mode: • g & b - Both 802.11.g and 802.11b Wireless stations will be able to use the Wireless Router. • g only - Only 802.11g Wireless stations can use the Wireless Router. • b only - Only 802.11b connections are available. - Page 21 Wireless Router User Guide WEP Screen This screen is accessed by clicking the "Configure WEP" button on the Wireless screen. Figure 8: WEP Screen Data - WEP Screen WEP Data Encryption WEP Data Select the option to match other Wireless Stations: Encryption •...
- Page 22 Setup Key Value Enter the key value or values you wish to use. The Default Key is required, the other keys are optional. Other stations must have the same key. If desired, you can generate a key from a phrase, instead of entering Passphrase the key value directly.
-
Page 23: Password Screen
Wireless Router User Guide Password Screen The password screen allows you to assign a password to the Wireless Router. Figure 9: Password Screen Once you have assigned a password to the Wireless Router (on the Password screen above) you will be prompted for the password when you connect, as shown below. (If no password has been set, this dialog will not appear.) Figure 10: Password Dialog •... -
Page 24: Chapter 4 Pc Configuration
Chapter 4 PC Configuration This Chapter details the PC Configuration required on the local ("Internal") LAN. Overview For each PC, the following may need to be configured: • TCP/IP network settings • Internet Access configuration • Wireless configuration Windows Clients This section describes how to configure Windows clients for Internet access via the Wireless Router. - Page 25 Wireless Router User Guide Checking TCP/IP Settings - Windows 9x/ME: 1. Select Control Panel - Network. You should see a screen like the following: Figure 11: Network Configuration 2. Select the TCP/IP protocol for your network card. 3. Click on the Properties button. You should then see a screen like the following. Figure 12: IP Address (Win 95) Ensure your TCP/IP settings are correct, as follows: Using DHCP...
- Page 26 PC Configuration • On the Gateway tab, enter the Wireless Router's IP address in the New Gateway field and click Add, as shown below. Your LAN administrator can advise you of the IP Address they assigned to the Wireless Router. Figure 13: Gateway Tab (Win 95/98) •...
- Page 27 Wireless Router User Guide Checking TCP/IP Settings - Windows NT4.0 1. Select Control Panel - Network, and, on the Protocols tab, select the TCP/IP protocol, as shown below. Figure 15: Windows NT4.0 - TCP/IP 2. Click the Properties button to see a screen like the one below.
-
Page 28: Specify An Ip Address
PC Configuration Figure 16: Windows NT4.0 - IP Address 3. Select the network card for your LAN. 4. Select the appropriate radio button - Obtain an IP address from a DHCP Server or Specify an IP Address, as explained below. Obtain an IP address from a DHCP Server This is the default Windows setting. - Page 29 Wireless Router User Guide Figure 17 - Windows NT4.0 - Add Gateway 2. The DNS should be set to the address provided by your ISP, as follows: • Click the DNS tab. • On the DNS screen, shown below, click the Add button (under DNS Service Search Order), and enter the DNS provided by your ISP.
- Page 30 PC Configuration Figure 18: Windows NT4.0 - DNS...
- Page 31 Wireless Router User Guide Checking TCP/IP Settings - Windows 2000: 1. Select Control Panel - Network and Dial-up Connection. 2. Right - click the Local Area Connection icon and select Properties. You should see a screen like the following: Figure 19: Network Configuration (Win 2000) 3.
- Page 32 PC Configuration Figure 20: TCP/IP Properties (Win 2000) 5. Ensure your TCP/IP settings are correct, as described below. Using DHCP To use DHCP, select the radio button Obtain an IP Address automatically. This is the default Windows setting. Using this is recommended. By default, the Wireless Router will act as a DHCP Server.
- Page 33 Wireless Router User Guide Checking TCP/IP Settings - Windows XP 1. Select Control Panel - Network Connection. 2. Right click the Local Area Connection and choose Properties. You should see a screen like the following: Figure 21: Network Configuration (Windows XP) 3.
- Page 34 PC Configuration Figure 22: TCP/IP Properties (Windows XP) 5. Ensure your TCP/IP settings are correct. Using DHCP To use DHCP, select the radio button Obtain an IP Address automatically. This is the default Windows setting. Using this is recommended. By default, the Wireless Router will act as a DHCP Server.
- Page 35 Wireless Router User Guide Internet Access To configure your PCs to use the Wireless Router for Internet access: • Ensure that the DSL modem, Cable modem, or other permanent connection is functional. • Use the following procedure to configure your Browser to access the Internet via the LAN, rather than by a Dial-up connection.
-
Page 36: Macintosh Clients
PC Configuration Macintosh Clients From your Macintosh, you can access the Internet via the Wireless Router. The procedure is as follows. 1. Open the TCP/IP Control Panel. 2. Select Ethernet from the Connect via pop-up menu. 3. Select Using DHCP Server from the Configure pop-up menu. The DHCP Client ID field can be left blank. -
Page 37: Wireless Station Configuration
Wireless Router User Guide Wireless Station Configuration This section applies to all Wireless stations wishing to use the Wireless Router's Access Point, regardless of the operating system which is used on the client. To use the Wireless Access Point in the Wireless Router, each Wireless Station must have compatible settings, as follows: Mode The mode must be set to Infrastructure. -
Page 38: Chapter 5 Operation And Status
Chapter 5 Operation and Status This Chapter details the operation of the Wireless Router and the status screens. Operation Once both the Wireless Router and the PCs are configured, operation is automatic. However, there are some situations where additional Internet configuration may be required: •... - Page 39 Wireless Router User Guide Data - Status Screen Internet This indicates the current connection method, as set in the Setup Connection Method Wizard or WAN Port screen. This shows the status of the connection from the Wireless Router Broadband Modem to the Broadband Modem.
-
Page 40: Connection Status - Pppoe
Operation and Status Connection Status - PPPoE If using PPPoE (PPP over Ethernet), a screen like the following example will be displayed when the "Connection Details" button is clicked. Figure 24: PPPoE Status Screen Data - PPPoE Screen Connection The hardware address of this device, as seen by remote devices Physical Address on the Internet. - Page 41 Wireless Router User Guide Buttons Connect If not connected, establish a connection to your ISP. Disconnect If connected to your ISP, hang up the connection. Delete all data currently in the Log. This will make it easier to Clear Log read new messages.
-
Page 42: Connection Status - Pptp
Operation and Status Connection Status - PPTP If using PPTP (Peer-to-Peer Tunneling Protocol), a screen like the following example will be displayed when the "Connection Details" button is clicked. Figure 25: PPTP Status Screen Data - PPTP Screen Connection Physical Address The hardware address of this device, as seen by remote devices on the Internet. -
Page 43: Connection Status - Telstra Big Pond
Wireless Router User Guide Disconnect If connected to your ISP, hang up the connection. Delete all data currently in the Log. This will make it easier to read Clear Log new messages. Update the data on screen. Refresh Connection Status - Telstra Big Pond An example screen is shown below. -
Page 44: Connection Details - Singtel Ras
Operation and Status Connection Log • The Connection Log shows status messages relating to the Connection Log existing connection. • The Clear Log button will restart the Log, while the Refresh button will update the messages shown on screen. Buttons If not connected, establish a connection to Telstra Big Pond. -
Page 45: Connection Details - Fixed/Dynamic Ip Address
Wireless Router User Guide Network Mask The Network Mask associated with the IP Address above. The IP Address of the remote Gateway or Router associated with the Default Gateway IP Address above. The IP Address of the Domain Name Server which is currently used. DNS IP Address DHCP Client This will show "Enabled"... - Page 46 Operation and Status Data - Fixed/Dynamic IP address Screen Internet The hardware address of this device, as seen by remote devices on Physical Address the Internet. (This is different to the hardware address seen by devices on the local LAN.) The IP Address of this device, as seen by Internet users.
-
Page 47: Chapter 6 Advanced Features
Chapter 6 Advanced Features This Chapter explains when and how to use the Wireless Router's "Advanced" Features. Overview The following advanced features are provided. • Advanced Internet • Communication Applications • Special Applications • • URL filter • Access Control •... -
Page 48: Advanced Internet Screen
Advanced Features Advanced Internet Screen This screen allows configuration of all advanced features relating to Internet access. • Communication Applications • Special Applications • • URL filter An example screen is shown below. Figure 30: Internet Screen Communication Applications Most applications are supported transparently by the Wireless Router. But sometimes it is not clear which PC should receive an incoming connection. -
Page 49: Special Applications
Wireless Router User Guide Special Applications If you use Internet applications which use non-standard connections or port numbers, you may find that they do not function correctly because they are blocked by the Wireless Router's firewall. In this case, you can define the application as a "Special Application". Special Applications Screen This screen can be reached by clicking the Special Applications button on the Internet screen. - Page 50 Advanced Features Data - Special Applications Screen Use this to Enable or Disable this Special Application as required. Checkbox Enter a descriptive name to identify this Special Application. Name • Type - Select the protocol (TCP or UDP) used when you receive data Incoming from the special application or service.
-
Page 51: Url Filter
Wireless Router User Guide URL Filter The URL Filter allows you to block access to undesirable Web site • To use this feature, you must define "filter strings". If the "filter string" appears in a requested URL, the request is blocked. •... -
Page 52: Access Control
Advanced Features Access Control This feature is accessed by the Access Control link on the Advanced menu. Overview The Access Control feature allows administrators to restrict the level of Internet Access avail- able to PCs on your LAN. With the default settings, everyone has unrestricted Internet access. To use this feature: 1. - Page 53 Wireless Router User Guide Data - Access Control Screen Group Select the desired Group. The screen will update to display the Group settings for the selected Group. Groups are named "Default", "Group 1", "Group 2", "Group 3" and "Group 4", and cannot be re- named.
-
Page 54: Group Members Screen
Advanced Features Edit Service List If you wish to define additional Services, or manage the Service list, click this button to open the "Services" screen. Save Save the data on screen. Reverse any changes made since the last "Save". Cancel View Log Click this to open a sub-window where you can view the "Access Control"... - Page 55 Wireless Router User Guide Default Schedule Screen This screen is displayed when the Define Schedule button on the Access Control screen is clicked. • This schedule can be (optionally) applied to any Access Control Group. • Blocking will be performed during the scheduled time (between the "Start" and "Finish" times.) •...
-
Page 56: Services Screen
Advanced Features Services Screen This screen is displayed when the Edit Service List button on the Access Control screen is clicked. Figure 36: Access Control - Services Data - Services Screen Available Services This lists all the available services. Available Services "Delete"... -
Page 57: Access Control Log
Wireless Router User Guide Cancel Clear the " Add New Service " area, ready for entering data for a new Service. Access Control Log To check the operation of the Access Control feature, an Access Control Log is provided. Click the View Log button on the Access Control screen to view this log. This log shows attempted Internet accesses which have been blocked by the Access Control function. -
Page 58: Remote Management
Advanced Features Remote Management This feature allows you to manage the Wireless Router via the Internet. Figure 37: Remote Management Screen Data - Remote Management Screen Remote Management Enable to allow management via the Internet. If Disabled, this device Enable Remote will ignore management connection attempts from the Internet. -
Page 59: Virtual Servers
Wireless Router User Guide Virtual Servers This feature allows you to make Servers on your LAN accessible to Internet users. Normally, Internet users would not be able to access a server on your LAN because: • Your Server does not have a valid external IP Address. •... -
Page 60: Virtual Servers Screen
Advanced Features Virtual Servers Screen The Virtual Servers screen is reached by the Virtual Servers link on the Advanced screen. An example screen is shown below. Figure 39: Virtual Servers Screen This screen lists a number of pre-defined Servers, and allows you to define your own Servers. Details of the selected Server are shown in the "Properties"... -
Page 61: Defining Your Own Virtual Servers
Wireless Router User Guide Buttons Defaults This will delete any Servers you have defined, and set the pre- defined Servers to use their default port numbers. Disable All This will cause the "Enable" setting of all Virtual Servers to be set OFF. -
Page 62: Dynamic Dns (Domain Name Server)
Advanced Features Connecting to the Virtual Servers Once configured, anyone on the Internet can connect to your Virtual Servers. They must use the Internet IP Address (the IP Address allocated to you by your ISP). e.g. http://203.70.212.52 ftp://203.70.212.52 It is more convenient if you are using a Fixed IP Address from your ISP, rather than Dynamic. However, you can use the Dynamic DNS feature, described in the following section, to allow users to connect to your Virtual Servers using a URL, rather than an IP Address. -
Page 63: Dynamic Dns Screen
Wireless Router User Guide Dynamic DNS Screen Select Advanced on the main menu, then Dynamic DNS, to see a screen like the following: Figure 40: DDNS Screen Data - Dynamic DNS Screen DDNS Service • DDNS Service You must sign up first to create a new account before using the service. -
Page 64: Upgrade Firmware
Advanced Features Upgrade Firmware The firmware (software) in the Wireless Router can be upgraded using your Web Browser. You must first download the upgrade file, then select Upgrade on the Advanced menu. You will see a screen like the following. Figure 41: Upgrade Firmware Screen To perform the Firmware Upgrade: 1. -
Page 65: Chapter 7 Advanced Configuration
Chapter 7 Advanced Configuration This Chapter explains the settings available via the Advanced configuration section of the "Advanced" menu. Overview Normally, it is not necessary to use these screens, or change any settings. These screens and settings are provided to deal with non-standard situations, or to provide additional options for advanced users. -
Page 66: Pc Database
Advanced Administration PC Database The PC Database is used whenever you need to select a PC (e.g. for the "DMZ" PC). It elimi- nates the need to enter IP addresses. Also, you do not need to use fixed IP addresses on your LAN. - Page 67 Wireless Router User Guide Data - PC Database Screen Known PCs This lists all current entries. Data displayed is name (IP Address) type. The "type" indicates whether the PC is connected to the LAN. Name If adding a new PC to the list, enter its name here. It is best if this matches the PC's "hostname".
- Page 68 Advanced Administration PC Database (Admin) This screen is displayed if the "Advanced Administration" button on the PC Database is clicked. It provides more control than the standard PC Database screen. Figure 43: PC Database (Admin) Data - PC Database ( Admin) Screen Known PCs This lists all current entries.
- Page 69 Wireless Router User Guide IP Address Select the appropriate option: • Automatic - The PC is set to be a DHCP client (Windows: "Ob- tain an IP address automatically"). The Wireless Router will allocate an IP address to this PC when requested to do so. The IP address could change, but normally won't.
-
Page 70: Options
Advanced Administration Options This screen allows advanced users to enter or change a number of settings. For normal opera- tion, there is no need to use this screen or change any settings. An example Options screen is shown below. Figure 44: Options Screen Data - Options Screen Backup DNS IP Address... - Page 71 Wireless Router User Guide • If checked, then UPnP users can disable Internet access via this Allow Internet device. access to be • If Disabled, UPnP users can NOT disable Internet access via this disabled device. But currently, this restriction only applies to users running Windows XP, who access the Properties via UPnP.
-
Page 72: Security
Advanced Administration Security This screen allows you to set Firewall and other security-related options. Figure 45: Security Screen Data - Security Screen Firewall If enabled, DoS (Denial of Service) attacks will be detected and Enable DoS blocked. The default is enabled. It is strongly recommended that this Firewall setting be left enabled. - Page 73 Wireless Router User Guide The IPSec protocol is used to establish a secure connection, and is Allow IPsec widely used by VPN (Virtual Private Networking) programs. • If checked, IPSec connections are allowed. • If not checked, IPSec connections are blocked. PPTP (Point to Point Tunneling Protocol) is widely used by VPN Allow PPTP (Virtual Private Networking) programs.
-
Page 74: Logs
Advanced Administration Logs The Logs record various types of activity on the Wireless Router. This data is useful for troubleshooting, but enabling all logs will generate a large amount of data and adversely affect performance. Since only a limited amount of log data can be stored in the Wireless Router, log data can also be E-mailed to your PC. - Page 75 Wireless Router User Guide E-mail Logs You can choose to have the logs E-mailed to you, by enabling either or both checkboxes. If enabled, the Log will sent to the specified E-mail address. The interval between E-mails is deter- mined by the "Send" setting. Select the desired option for sending the log by E-mail.
-
Page 76: Mac Address
Advanced Administration MAC Address The MAC (hardware) address is a low-level network identifier. It may be called "MAC Ad- dress", "Hardware Address", or "Physical Address". On a PC, this address is associated with the Network card or adapter. The address on the MAC Address screen is the address on the Internet (WAN port) interface, and has no effect on the LAN interface. -
Page 77: Routing
Wireless Router User Guide Routing Overview • If you don't have other Routers or Gateways on your LAN, you can ignore the "Routing" page completely. • If the Wireless Router is only acting as a Gateway for the local LAN segment, ignore the "Routing"... -
Page 78: Static Routing
Advanced Administration Figure 48: Routing Screen Data - Routing Screen Check this to enable the RIP (Routing Information Protocol) feature Enable RIP of the Wireless Router. The Wireless Router supports RIP 1 only. Static Routing Static Routing This list shows all entries in the Routing Table. Table Entries •... -
Page 79: Configuring Other Routers On Your Lan
Wireless Router User Guide Buttons Save Save the RIP setting. This has no effect on the Static Routing Table. Add a new entry to the Static Routing table, using the data shown in the "Properties" area on screen. The entry selected in the list is ignored, and has no effect. - Page 80 Advanced Administration Static Routing - Example Router A (192.168.1.80) (192.168.0.100) Segment 1 Segment 0 (192.168.1.xx) (192.168.0.xx) Wireless Router B Gateway (192.168.2.70) (192.168.1.90) (192.168.0.1) Segment 2 (192.168.2.xx) Figure 49: Routing Example For the Wireless Router's Routing Table For the LAN shown above, with 2 routers and 3 LAN segments, the Wireless Router requires 2 entries as follows.
-
Page 81: Appendix A Troubleshooting
Appendix A Troubleshooting This Appendix covers the most likely problems and their solutions. Overview This chapter covers some common problems that may be encountered while using the Wireless Router and some possible solutions to them. If you follow the suggested steps and the Wireless Router still does not function properly, contact your dealer for further advice. -
Page 82: Wireless Access
Appendix A - Troubleshooting Solution 2: The Wireless Router processes the data passing through it, so it is not transparent. Use the Special Applications feature to allow the use of Internet applications which do not function correctly. If this does solve the problem you can use the DMZ function. This should work with almost every application, but: •... -
Page 83: Appendix B About Wireless Lans
Appendix B About Wireless LANs This Appendix provides some background information about using Wireless LANs (WLANs). Modes Wireless LANs can work in either of two (2) modes: • Ad-hoc • Infrastructure Ad-hoc Mode Ad-hoc mode does not require an Access Point or a wired (Ethernet) LAN. Wireless Sta- tions (e.g. -
Page 84: Channels
Appendix A - Troubleshooting Channels The Wireless Channel sets the radio frequency used for communication. • Access Points use a fixed Channel. You can select the Channel used. This allows you to choose a Channel which provides the least interference and best performance. In the USA and Canada, 11 channel are available. -
Page 85: Appendix C Specifications
Appendix C Specifications Multi-Function Wireless Router Model Wireless Router Dimensions 141mm(W) * 100mm(D) * 27mm(H) Operating Temperature 0° C to 40° C Storage Temperature -10° C to 70° C Network Protocol: TCP/IP Network Interface: 5 Ethernet: 4 * 10/100BaseT (RJ45) LAN connection 1 * 10/100BaseT (RJ45) for WAN LEDs Power Adapter... -
Page 86: Regulatory Approvals
Appendix B - Specifications Regulatory Approvals CE Standards This product complies with the 99/5/EEC directives, including the following safety and EMC standards: • EN300328-2 • EN301489-1/-17 • EN60950 CE Marking Warning This is a Class B product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures.
