Carrier 58HDV040 Product Data

58HDV
Direct Vent 4---Way Multipoise
Condensing Gas Furnace
95% Downflow / Horizontal Orientations
93.5% Upflow Orientation
95% Variable Speed
Two- -Stage Heating
Furnace
FLEXIBILITY
S Supports two- -stage cooling units
S Dual Certified venting (1 or 2 pipe), Direct Vent Furnace
S 40in (1016mm) high with wider cabinets, for ease of installation
S Factory shipped for natural gas, with Propane Gas conversion
kits available
S Four- -way multipoise installation
S Vent pipe can be run horizontally or vertically
S Internal condensate drain system
SERVICE
S Self diagnostics
S Entire blower assembly removable
COMFORT
S Adjustable timed blower heating Off delay
S Adjustable timed blower cooling On/Off delay
S Thermal lined, one piece steel cabinet for noise reduction
S Insulated blower compartment
S 24 and 115VAC humidifier terminals
S Electronic air cleaner terminal
S Dehumidification option
EFFICIENCY
S 95% AFUE
S Two- -stage operation
S ECM Variable speed DC motor
S Two- -stage Induced draft blower
S In- -shot burners
S California NOx approved
Model
Number
Inches
40 x 19
58HDV040
40 x 19
58HDV060
40 x 22
58HDV080
40 x 24
58HDV100
Product Data
UPFLOW/DOWNFLOW/HORIZONTAL (NATURAL GAS)
Dimensions H x W x D
Millimeters
1
/ x 29 1016 x 486 x 737
8
1
/ x 29 1016 x 486 x 737
8
3
/ x 29 1016 x 578 x 737
4
1
/ x 29 1016 x 522 x 737
2
QUALITY
S Stainless steel heat exchanger
S Stainless steel secondary heat exchanger
S High temperature limit control prevents overheating
S Direct ignition with Silicon Nitride igniton
S Flame roll- -out sensors standard
S External filter rack with permanent filters
!
UNIT OPERATION HAZARD
Failure to follow this warning could result in personal injury,
death or property damage.
This furnace is not designed for use in mobile homes, trailers,
or recreational vehicles.
As an ENERGY STAR
Partner, Carrier Corp.
has determined that this
product meets the
ENERGY STAR
guidelines for energy
efficiency.
Input Efficiency
(MBTUH) AFUE
40 95
60 95
80 95
100 95
1
WARNING
ama
CERTIFIED
Cooling Capacity
@ .5 in wc (125 Pa)
Lbs
1.5 - - 3.0 TON 150
1.5 - - 3.5 TON 168
3 - - 5.0 TON 187
3 - - 5.0 TON 203
Weight
Kg
68
76
85
92
